- Page 1 POE-FSH8PW 8 port 24V Passive POE Web Smart Switch User’s Manual...
- Page 2 OvisLink Corp. has made the best effort to ensure the accuracy of the information in this user’s guide. However, we are not liable for the inaccuracies or errors in this guide. Please use with caution. All information is subject to change without notice All Trademarks are properties of their respective holders. AirLive POE-FSH8PW User’s Manual...
-
Page 3: Fcc Statement
IMPORTANT NOTE FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. AirLive POE-FSH8PW User’s Manual... -
Page 4: Table Of Contents
4.4 Administrator ..................21 4.5 Authentication Configuration (Administrator menu)......21 4.6 System IP Configuration (Administrator menu) ........22 4.7 System Status ..................22 4.8 Load default setting (Administrator menu) ........23 4.9 Firmware Update (Administrator menu) ...........23 4.10 Reboot Device (Administrator menu) ..........23 AirLive POE-FSH8PW User’s Manual... - Page 5 4.25 Class of Service (QoS Setting) ............39 4.26 Security ....................40 4.27 MAC Address Binding (QoS Setting) ..........40 4.28 TCP/UDP Filter (QoS Setting)............41 4.29 Backup/Recovery ................42 4.30 Miscellaneous ..................43 4.31 Logout ....................44 Appendix A: Product Specifications ............45 Appendix B: Troubleshooting ..............48 AirLive POE-FSH8PW User’s Manual...
-
Page 6: Introduction
1. Introduction Introduction 1.1 Overview The POE-FSH8PW is a Power Control Passive POE Switch. It was designed for easy installation and high performance in an environment where traffic is on the network and the number of users increases continuously. It consists of 8 Passive PoE (24V DC) ports. That can solve the limitation of the power outlet location and offer the system designer a flexible solution to locate the network device everywhere. -
Page 7: Guide To The Chapters
IP Address and Password information are in the Quick Setup section. Chapter 2: Detail installation instruction including how to make Cat. 5 Cable Chapter 3: LED indicators Chapter 4: Detail information on Web management including how to setup remote management. AirLive POE-FSH8PW User’s Manual... -
Page 8: Quick Setup
Please do not enable the PoE function on the ports that are not connected to the passive PoE devices. Enabling PoE power on a port that is connected with PC or switch can cause damage or fire hazard. AirLive POE-FSH8PW User’s Manual... -
Page 9: Installation Steps
1. Introduction Power-On the switch The POE-FSH8PW Switch has a built-in power supply to operate with 100 ~ 240V AC, 50 ~ 60Hz power source. The AC power cord connector is located at the rear of the unit and the On/Off switch is next to the connector. - Page 10 Step 7: Turn on the port number where you connect the device. (See Figure C) Step 8: If you want to install the switch on the 19" rack, please install the mounting kit (optional). Step 9: Please see Chapter 4 for further configurations. AirLive POE-FSH8PW User’s Manual...
-
Page 11: Installation Of The Switch
IP address, password, and LED table for user’s reference. 2.1 Unpack the Package Before you begin the installation of POE-FSH8PW Management Switch, make sure that you have all the necessary accessories that come with your package. Follow the steps below to unpack your package contents: 1. -
Page 12: Hardware Overview
These ports also support the automatic MDI/MDIX crossover detection function, providing true “plug and play” capability. Just plug-in the network cable to the hub directly. Reset: The Reset button is to reset all the setting back to the factory default. AirLive POE-FSH8PW User’s Manual... -
Page 13: Installation Site Preparation
2.3 Installation Site Preparation You can mount POE-FSH8PW Passive PoE Switch either on desktop or on a 19-inch rack. If you plan to mount the switch on desktop, please choose a steady, level surface in a well-ventilated area that is free from excessive dust. In any case, the installation site chosen for your switch has to comply with the following requirements: The surface where you want to mount the switch must be able to sustain at least 1.5kg. -
Page 14: Rack Mounting
Leave at least 10cm(4 inch) of space around the switch to allow heating dissipation 2.4 Rack Mounting The POE-FSH8PW PoE Switch can be mounted on a standard size 19-inch rack, which can in turn be placed in a wiring closet with other equipments. -
Page 15: Desktop Installation
2.5 Desktop Installation The POE-FSH8PW PoE Switch has four rubber pads attached on each corner of its underside. These pads serve as cushioning against vibration and prevent the switch from sliding off its position. They also allow adequate ventilation space when you place the switch on top of another device. -
Page 16: Cabling Requirements
10/100 BASE-T cabling architecture, the cable distance should be within 100m. The following table summarizes the cable requirement for 10/100BASE-TX connection: 10BASE-T 100 ohm Category 3, 4, 5 UTP/STP cable 100BASE-TX 100 ohm Category 5 UTP/STP cable AirLive POE-FSH8PW User’s Manual... -
Page 17: Connecting To Power
100 meters 2.7 Connecting to Power POE-FSH8PW PoE Switch features a universal auto-select power supply unit, which allows a power connection to a wide range of input voltages from 100 to 240VAC @ 50 ~ 60Hz. To establish its power connection, simply plug the female end of the power cord into the power connector on the rear of the switch and the male end of the power cord into a suitable power outlet. - Page 18 2. Installation of the Switch Step 1. Turn on the POE-FSH8PW PoE Switch. Step 2. Press and hold the reset button continuously for10 seconds and release the reset button. Step 3. The switch will reboot for 5 seconds and the configuration of switch will back to the default setting.
-
Page 19: Led Indicators
3. LED Indicators LED Indicators Before connecting any network device to POE-FSH8PW 802.3af PoE Switch, you should take a few minutes to look over this chapter and get familiar with the front panel LED indicators of your Switch. 3.1 Comprehensive LEDs 3.2 LED Table... -
Page 20: Web Management
4. Web Management Web Management The POE-FSH8PW PoE Switch can be configured by web based interface, including administrator, port management, VLAN setting, per port counter, trunk setting, QoS setting, security filter, configuration/ backup/recovery, miscellaneous, log out, and so on. The device based smart switch supports main stream browsers, such as IE 6.0~7.0, Firefox... - Page 21 If there is no network status icon on the task bar, please go to the “Start -> Settings -> Network -> Local Connection” of the task bar’s Start menu. Step 2. Clock on the “property” icon. Step 3. Double click on the “Internet Protocol (TCP/IP) AirLive POE-FSH8PW User’s Manual...
-
Page 22: Remote Management
*Note1: If IP address of the switch is lost, please reset the switch to factory default value and access the switch via the default IP address. *Note2: The POE-FSH8PW has DHCP client ability. This allows DHCP server (or router) to assign IP automatically. However, we do not recommend turning on the DHCP client because the DHCP server assign the IP randomly. - Page 23 Then the Cable provider will assign the switch with a IP and Gateway. Please contact with your ISP for further information about your IP address. When the configuration is finished, the Remote PC can access the switch by typing the switch’s IP address on the web browser. AirLive POE-FSH8PW User’s Manual...
-
Page 24: Connect Through Broadband Router
If your router require enter the beginning and ending Port (from PortX to PortX), enter 80 for both. Now the Remote PC will be able to access your switch by entering “201.100.1.5” in the Web browser’s address field. AirLive POE-FSH8PW User’s Manual... -
Page 25: Get Into The Web Management
The switch’s image on the upper portion of the screen gives the quick overview of the port connection status. When a port is plugged in, the switch’s image will show a “plug” on the corresponding port. Click on a port will show the quick port status. AirLive POE-FSH8PW User’s Manual... -
Page 26: Administrator
In the following sessions, we will talk in detail about the management functions under the Administrator menu. 4.5 Authentication Configuration (Administrator menu) This page shows authentication configuration information. User can set new Username and Password in this page. AirLive POE-FSH8PW User’s Manual... -
Page 27: System Ip Configuration (Administrator Menu)
This page is used to check the status of switch, including Switch MAC address and software version. The comment field allows the network administrator to input an easy-to-remember nickname for this switch. The legal characters are “a~z” and “A~Z”, “_”,“-“, “+”, “0 ~9”, excluding special character. AirLive POE-FSH8PW User’s Manual... -
Page 28: Load Default Setting (Administrator Menu)
After pressing Update button, the old web code will be erased. Then you can select the image file and press “update” button to update the firmware you need. 4.10 Reboot Device (Administrator menu) Click Confirm button to reboot the device. AirLive POE-FSH8PW User’s Manual... -
Page 29: Port Management
In the following sessions, we will talk in detail about the management functions under the Port Management menu. 4.12 Port Configuration (Port Management menu) In Port Configuration, you can set and view the operation mode for each port. AirLive POE-FSH8PW User’s Manual... - Page 30 Addr. Learning: When the Auto-Negotiation column is set as Disable, users have to set this column as Enable or Disable. Select Port No.: Tick the check boxes beside the port numbers being set. Click Update to have the configuration take effect. Current Status: Displays current port status. AirLive POE-FSH8PW User’s Manual...
-
Page 31: Port Mirroring (Port Management Menu)
This means all packets received at port 1 ~port 4 will be copied to port 5, port 6, port 7 and port 8.Care should be taken that the more source ports and destination ports is set, the lower network throughput is available for normal traffic. AirLive POE-FSH8PW User’s Manual... -
Page 32: Bandwidth Control (Port Management Menu)
This page allows the setting of the bandwidth for each port. The TX rate and Rx rate can be filled with the number ranging from 1 to 255. This number should be multiplied by the selected bandwidth resolution to get the actual bandwidth. (a) Low bandwidth for TX AirLive POE-FSH8PW User’s Manual... - Page 33 “low”. The real bandwidth comes from the formula of 32Kbps*10, 32Kbps*20 , 32Kbps*30 and 32Kbps*40 respectively. After the “update” button is executed, the real bandwidth will show up in TX fields. (b) High bandwidth for TX AirLive POE-FSH8PW User’s Manual...
- Page 34 Speed base is set to “low”. The real bandwidth comes from the formula of 32Kbps*50, 32Kbps*60, 32Kbps*70 and 32Kbps*80 respectively After the “update” button is executed, the real bandwidth will show up in RX fields. (d) High bandwidth for RX AirLive POE-FSH8PW User’s Manual...
-
Page 35: Broadcast Storm Control (Port Management)
The switch implements a broadcast storm control mechanism. Tick the check boxes to have them beginning to drop incoming broadcast packets if the received broadcast packet counts reach the threshold defined. Each port’s broadcast storm protection function can be AirLive POE-FSH8PW User’s Manual... -
Page 36: Poe (Port Management Menu)
Click Update to have the configuration take effect. 4.16 POE (Port Management menu) User could know per PoE port out power status in this page and also enable or disable per port. AirLive POE-FSH8PW User’s Manual... -
Page 37: Vlan Setting
After switching to Tag Based VLAN Mode, the screen will change. On this screen you can now define and configure your Up- and Downlink ports. These are important since here the handover between the switches of your network takes place. AirLive POE-FSH8PW User’s Manual... -
Page 38: Vlan Member (Vlan Setting)
The ports need to be made member of your VLAN groups. This is for Tag Based and Port Based VLAN Mode. The screen here looks different whether you run Tag Based or Port Based Mode. VLAN Member in Port Based Mode AirLive POE-FSH8PW User’s Manual... - Page 39 In Tag Based Mode you need to define and configure your VLAN groups. Since you want the handover to other switches take place smoothly, the VLAN IDs (Numbers) need to be like on the rest of your network. On other switches you may have the chance to configure AirLive POE-FSH8PW User’s Manual...
-
Page 40: Multi To 1 Setting (Vlan Setting)
”VLAN member setting “. When VLAN member setting is updated, multi-to-1 setting will be void and vice versa. The “disable port” means the port which will be excluded in this setting. All ports excluded in this setting are treated as the same VLAN group. AirLive POE-FSH8PW User’s Manual... -
Page 41: Per Port Counter
Clear: Press “clear” will clear all counters. 4.22 Trunk Setting Port trunk allows multiple links to be bundled together and act as a single physical link for increased throughput. It provides load balancing, and redundancy of links in a switched AirLive POE-FSH8PW User’s Manual... -
Page 42: Qos Setting
QoS (Quality of Service) refers to mechanisms in the network software that make the actual determination of which packets have priority. CoS refers to feature sets, or groups of services, that are assigned to users based on company policy. If a feature set includes AirLive POE-FSH8PW User’s Manual... -
Page 43: Priority Mode (Qos Setting)
WRR mode: There are 4 priority queues for Weighted-and-round-robin (WRR) mode. When this mode is selected, the traffic will be forwarded according to the number set in each queue. AirLive POE-FSH8PW User’s Manual... -
Page 44: Class Of Service (Qos Setting)
The operating theory for all 4 CoS types can be illustrated by the following figure and table. TCP/UDP CoS is a global setting for all ports and has no connection with the physical port. Other CoS types have a connection with the physical port. AirLive POE-FSH8PW User’s Manual... -
Page 45: Security
Binding: Enable or disable the binding function. Click Update to have the configuration take effect. Note: Setting the multicast address to these fields is not allowed. A warning message will show up if you do so. AirLive POE-FSH8PW User’s Manual... -
Page 46: Tcp/Udp Filter (Qos Setting)
The ” deny” function makes the switch drop the selected protocol and forward other protocols. The protocol is checked at the selected secure WAN port. And it should be set at the server side. AirLive POE-FSH8PW User’s Manual... -
Page 47: Backup/Recovery
The user can save configuration file to a specified file. If the user wants to recover the original configuration, which is saved at the specified path, just enter the password and then press the “upload” button. Finally the original configuration of the switch will be recovered. AirLive POE-FSH8PW User’s Manual... -
Page 48: Miscellaneous
VLAN. IGMP Snooping: When this function is enabled, the switch will execute IGMP snooping version 1 and version 2 without the intervention of CPU. The IGMP report and leave packets are automatically handled by the switch. AirLive POE-FSH8PW User’s Manual... -
Page 49: Logout
4. Web Management 4.31 Logout The administrator has write access for all parameters governing the onboard agent. User should therefore assign a new administrator password as soon as possible, and store it in a safe place. AirLive POE-FSH8PW User’s Manual... -
Page 50: Appendix A: Product Specifications
Power Output 8 Ports at Full 15.4 Watt Output Supported Power Pin: 4,5,7,8 Data Pin: 1,2,3,6 Power 130 Watts (Max) Consumption Dimensions 266 × 160 × 44 mm (L x W x H) Weight 1.6 kg AirLive POE-FSH8PW User’s Manual... - Page 51 PoE : Act / Status Indicators Per Unit: Power Power Input 100~240V/AC, 50~60Hz 48V/DC per Port Output – 15.4W Max per Port – Power Output 24Watt Max Per Port Power 250 Watts (Max) Consumption supply 15.4Watts Power AirLive POE-FSH8PW User’s Manual...
- Page 52 Dimensions 445 × 220 × 45 mm (L x W x H) Weight 2.54 kg Operating 0 to 60℃ Temperature Storage -20 to 90℃ Temperature Humidity 10 to 90% RH (non-condensing) Certifications FCC Class A, CE AirLive POE-FSH8PW User’s Manual...
-
Page 53: Appendix B: Troubleshooting
When you forgot your IP or password, please use the reset button for the factory default setting? Please take the following steps to reset the Web Smart Switch back to the original default: AirLive POE-FSH8PW User’s Manual... - Page 54 Appendix: B: Troubleshooting Step 1. Turn on the POE-FSH8PW 802.3af PoE Switch Step 2. Press and hold the reset button continuously for 5 seconds and release the reset button. Step 3. The switch will reboot for 20 seconds and the configuration of switch will back to the default setting Key in the user ID and the password to pass the authentication;...
