Page 1: Receipt Printer
USER’S MANUAL Receipt Printer BTP-R580Ⅱ Shandong New Beiyang Information Technology Co., Ltd... - Page 2 SNBC has been approved by the following certifications: ISO9001 Quality Control System ISO14001 Environmental Management System OHSAS18001 Occupational Health and Safety Management System IECQ QC080000 Hazardous Substance Process Management System BTP-R580Ⅱ has been approved by the following certifications of environmental protection: - 1 -...
-
Page 3: Safety Instructions
BTP-R580Ⅱ User’s Manual Safety instructions Before installing and using the printer, please read the following items carefully: Safety warning 1． Warning Do not touch the cutter of the printer. Warning The print head is a thermal element and it is at a high temperature during printing or just after operation, therefore do not touch it or its peripherals for reasons of safety. -
Page 4: Table Of Contents
BTP-R580Ⅱ User’s Manual Contents Overview ........................- 1 - 1.1 Introduction......................- 1 - 1.2 Main features ......................- 1 - Specifications ......................- 2 - 2.1 Technical specifications..................- 2 - 2.2 Cutter specifications ....................- 3 - 2.3 Paper specifications ....................- 3 - 2.3.1 Parameters of continuous thermal paper ............. - Page 5 BTP-R580Ⅱ User’s Manual Routine maintenance ....................- 13 - 5.1 Clean print head and platen roller................. - 13 - 5.2 Clean sensors ...................... - 13 - 5.3 Clear paper jam ....................- 13 - Interface signal ......................- 13 - 6.1 Parallel interface ....................
-
Page 6: Overview
1 Overview 1.1 Introduction BTP-R580Ⅱ is a high performance thermal printer, which can be widely used for real-time printing applications, such as POS system, restaurant system, ATM, etc. BTP-R580II can be connected with other devices via parallel, serial, USB, Ethernet or WLAN... -
Page 7: Specifications
BTP-R580Ⅱ User’s Manual 2 Specifications 2.1 Technical specifications Item Parameter Print method Direct thermal line Print resolution 203×203DPI Print speed Max. 230mm/s Print width Max. 80mm Paper type Continuous paper, marked paper One-dimensional barcode: UPC-A, UPC-E, EAN-8, EAN-13 , Codabar,... -
Page 8: Cutter Specifications
FUJI PHOTO FILM CO., LTD 2.3.2 Parameters of marked paper BTP-R580Ⅱ can support marked paper printing and set the cutting and initial printing position accurately. Marked paper not only should meet the parameters of thermal paper roll, but also should meet the following requirements:... - Page 9 BTP-R580Ⅱ User’s Manual L1 mark height: 3mm≤L1≤13mm L2 mark length: L2≥12mm L3 mark spacing: 20mm≤L3<500mm Mark position: The mark can be set on the left, middle or right, and when it is on the left or right, only 80mm paper is available.
-
Page 10: Print And Tear-Off Position
BTP-R580Ⅱ User’s Manual 2.4 Print and tear-off position 2.4.1 Print position L1 paper cabinet width: 83.5+0/-0.5mm L2 effective print width: 80mm L3 distance from print head to left edge of paper cabinet (fixed width): 1.75±1mm L4 distance from print head to right edge of paper cabinet (fixed width): 1.75±1mm L5 left margin: The default value is 8mm. -
Page 11: Appearance And Modules
BTP-R580Ⅱ User’s Manual 3 Appearance and modules 3.1 Appearance and modules 1—paper guide 2—paper near end sensor lever 3—mark sensor 4—platen roller 5—cutter 6—cutter cover board 7—tear-off bar 8—fixed blade 9—print head 10—guard board for print head 11—roller 12—cover open lever 13—top cover... -
Page 12: Led And Buzzer
BTP-R580Ⅱ User’s Manual Print configuration sample: Pressing down the FEED button while turning on the printer, the printer will print out configuration sample, including print length, print width, print speed, etc. Enter button configuration mode: Pressing down FEED button while turning on the printer, the printer will print out configuration sample, then cut paper and enter waiting status (ERROR LED flashes). - Page 13 BTP-R580Ⅱ User’s Manual Caution: The temperature of the print head is detected by a thermal resistor. If the print head is overheating, the protective circuit will shut off the power and force the printer to stop printing; the temperature of print head when printing is stopped is 65 ℃...
-
Page 14: Printer Installation
BTP-R580Ⅱ User’s Manual 4 Printer installation 4.1 Unpacking Check if all the articles listed in the packing list are here and in good condition. If any problem, please contact SNBC or the dealer. 4.2 Printer installation 1) Printer should be installed on a flat and stable place; horizontal installation is recommended and the inclination angle should not exceed ±10°... -
Page 15: Connect Interface Cable
BTP-R580Ⅱ User’s Manual Caution: When the printer is bound to idle for a long period of time, disconnect the power cord. When the power is burned out or cannot be used for other reasons, replace it according to the following steps: 1) Press the power cover board and take it off in the direction indicated by the arrow;... -
Page 16: Install Paper Roll
BTP-R580Ⅱ User’s Manual 4.7 Install paper roll 4.7.1 Confirm paper type Paper can be installed after the connection of power cable and interface cable. But before starting printing, the paper type must be confirmed first. 4.7.2 Install/replace paper roll 1) Turn off the printer;... -
Page 17: Paper Near End Position Adjustment
BTP-R580Ⅱ User’s Manual 4.8 Paper near end position adjustment Paper roll with different core can be used by adjusting paper near end sensor lever to the corresponding level with the minimal remaining amount of paper at level 1. Level Level... -
Page 18: Routine Maintenance
BTP-R580Ⅱ User’s Manual 5 Routine maintenance Caution: Before starting routine maintenance, ensure that the printer power is turned off; Do not use solvents like gasoline or acetone; When cleaning sensors, the printer should not be powered on until the pure alcohol has completely evaporated. -
Page 19: Interface Signal
BTP-R580Ⅱ User’s Manual 6 Interface signal 6.1 Parallel interface Parallel interface can work in IEEE 1284 compatible mode or nibble mode. The interface is 36-pin socket. The Interface is defined as below: Signal Pin # Signal definition source nStrobe Data 0 (Least Significant Bit) -
Page 20: Serial Interface
BTP-R580Ⅱ User’s Manual Not defined Not defined nSelectIn 6.2 Serial interface The serial interface of the printer is compatible with RS-232, and the interface socket is DB25 female. PIN No. Signal definition PIN1 Frame ground PIN2 PIN 3 PIN 4... -
Page 21: Wlan Interface
BTP-R580Ⅱ User’s Manual LED displays network connecting status and data transmission status Support 9100 port print Support status back Support parameter configuration Support firmware online update Support printer status query and interface module maintenance based on HTTP (only supported by JK-E02 interface, not supported by JK-E04 interface). -
Page 22: Power Interface Definition
BTP-R580Ⅱ User’s Manual DHCP TFTP HTTP Wireless interface module uses wireless USB network card. For the main technical specifications, please contact your local dealer or SNBC. 6.6 Power interface definition Power interface signal definition Signal name Figure 6.6-1 Power socket 6.7 Signal definition of cash drawer interface... -
Page 23: Troubleshooting
BTP-R580Ⅱ User’s Manual 7 Troubleshooting Refer to this chapter for solution when a problem occurs. If the problem still cannot be solved, please contact your local dealer or SNBC for assistance. 7.1 Printer doesn’t work Problem Possible causes Solution Printer is not connected with... -
Page 24: Options
BTP-R580Ⅱ User’s Manual 8 Options 8.1 Kitchen printing prompt device - 19 -... -
Page 25: Power Management
Related parameters of power management are as below: Maximum default delay time of entering sleep mode is less than 5 minutes; Since the maximum default delay time is less than 5 minutes, BTP-R580Ⅱ does not open the interface of changing this time to user. -
Page 26: Appendix: Button Configuration Table
BTP-R580Ⅱ User’s Manual Appendix: Button configuration table Refer to BTP-R580II Firmware Button Configuration Table. - 21 -...
