Sirius XM RAdio SXBR1 User Manual

Music for business internet radio
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
28 Radio Margari
PUSH to Select
Jimmy Buffett
Margaritaville
Scroll
5:00 PM
SPEAKER
POWER
P1
P2
P3
P4
P5
BACK
SiriusXM Music For Business Internet Radio
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SXBR1 and is the answer not in the manual?

Questions and answers

Related Manuals for Sirius XM RAdio SXBR1

Summary of Contents for Sirius XM RAdio SXBR1

  • Page 1 28 Radio Margari PUSH to Select Jimmy Buffett Margaritaville Scroll 5:00 PM SPEAKER POWER BACK SiriusXM Music For Business Internet Radio User Guide...

  • Page 3: Table Of Contents

    Table of Contents Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Requirements: .

  • Page 4: Introduction

    Introduction Requirements: • The SiriusXM Business Radio requires connectivity to the Internet . The connection may be made a through a wired Ethernet connection (recommended), or through a wireless access point connection . • The SiriusXM Business Radio requires a SiriusXM Music for Business Internet Service subscription .
  • Page 5 Introduction • Do not store in dusty or dirty areas . Do not let any foreign matter spill into device . • Do not expose to chemicals such as benzene and thinners . Do not use liquid or aerosol cleaners . Clean with a soft cloth only and wipe lightly . • Do not try to disassemble and/or repair device yourself .

  • Page 6: What's In The Box

    Introduction What’s in the Box? BACK PUSH to Select Scroll SELECT SPEAKER POWER BACK SiriusXM Business Radio Remote Control Ethernet Stereo Mono Wireless Power Adapter Cable Audio Cable Audio Cable Antenna...

  • Page 7: Business Radio Button Functions And Connectors

    Introduction Business Radio Button Functions and Connectors Front View PUSH to Select Scroll SPEAKER POWER BACK Rear View STEREO MONO DC 5V AUX IN IMPEDANCE 12 13 1 . Channel Presets P1 - P5: Press and hold to save channels as presets; press to access presets .
  • Page 8 Introduction 6 . Scroll knob: Turn the knob to scroll through menu items . Press to select a menu item . 7 . Built-in Speaker: Speaker to monitor the audio playing . 8 . Impedance Switch: Selects the appropriate impedance: 8 ohm is the default for most audio devices and phone systems .

  • Page 9: Remote Control Button Functions

    Introduction Remote Control Button Functions 1 . Channel Preset Buttons P1 - P5: Press to access channels saved as presets . 2 . Back Button: Press to return to the previous screen; press and hold to return to the Main Screen . BACK 3 .

  • Page 10: Installation

    Installation Planning Before installing your SiriusXM Business Radio, you will need to consider the following: • How will you connect the Radio to the Internet, wired or wireless? SiriusXM strongly recommends a wired internet connection for all business installations . - If your network requires a static IP, consult a professional installer .

  • Page 11: Step 2: Connect The Radio

    Installation Please be sure to read it . Service automatically renews into the subscription Package you choose, for additional periods of the same length, and automatically bills at the then current rates, after any complimentary trial or promotional period ends, until you call us at 1-866-345-7474 to cancel . Step 2: Connect the Radio These instructions are for a wired connection to the Internet .

  • Page 12: Step 3: Enter Your Siriusxm Credentials

    Installation Mono Audio Cable . Connect the Stereo <Category List > Audio cable to the Audio Out (L) (R) (white Settings and red) connectors, or the Mono Audio Cable to the Mono Out connector (green) . 12:00 AM 6 . Set the Impedance Switch to the correct impedance for your audio system .

  • Page 13: Step 4: Set The Clock

    Installation same way as you entered your username . The password is also case sensitive . Then turn the Scroll knob until END is displayed and press the knob . 7 . After your password has been entered and successfully verified, you will be returned to the settings screen .

  • Page 14: Operation

    Operation Now Playing Screen When listening to a channel, information about the channel and what is currently playing is displayed . Channel Number Channel Name 24 Radio Margari Artist Name Jimmy Buffett Song Title Margaritaville Time 12:00 AM xL Channels Locked Front Panel Locked Dayparting On Wireless Network Signal Strength...

  • Page 15: Saving Channel Presets

    Operation World . Turn the Scroll knob to highlight < > your selection and press the knob . Rock 4 . Use the BACK button to return to the Hip-Hop/R&B previous screen as you search for a channel . 12:00 AM 5 .

  • Page 16: Dayparting

    Operation preset . The channel assigned to the preset will be 24 Radio Margari displayed . Connecting Preset 1 12:00 AM Dayparting Dayparting is a feature whereby the Radio automatically changes the channel at selected times throughout the day . Configuration of Dayparting is done through the SiriusXM website at www .siriusxm4biz .com .
  • Page 17 Operation Security can be configured to: • Block xL channels: All xL channels will be locked and cannot be tuned until the password is entered . xL channels are channels with explicit language . • Lock the front panel: No buttons can be used until the password is entered .
  • Page 18 Operation To set or change the Security options or password: 1 . Press and hold BACK to return to the Main Screen . 2 . Highlight Settings using the Scroll knob and press the knob to select . 3 . Highlight Security and press the knob . 4 .
  • Page 19 Operation Change Security: Select to change the password . If you want to remove the security for an item that you had previously secured, highlight the item and press the Scroll knob . Press and hold the BACK button to return from the Security menu and the security will have been removed .

  • Page 20: Connecting An Auxiliary Audio Source (Optional)

    Operation password . If you do not enter the password, the display screen will show Stopped to indicate that the xL channel is not playing . To unlock the Front Panel: When the front panel is locked, and you press Front panel a button or turn the Scroll knob, you will be locked.

  • Page 21: Auxiliary Input

    Operation 2 . Turn the Scroll knob to highlight Auxiliary Auxiliary input input and press the knob . The radio will now play the alternate audio source . The screen will display Auxiliary input to 12:00 AM indicate the Radio is playing the alternate audio source .

  • Page 22: Network Configuration

    Settings The settings menu is where you can configure the Radio’s settings . The settings menu is accessed by pressing and holding BACK until the Main Screen is displayed . Then highlight and select Settings using the Scroll knob . The following table describes each item in the settings menu .
  • Page 23 Settings Clock set-up Allows for configuration of the time zone for your location, the time and date, and also whether Daylight Savings Time is being observed . Refer to “Step 4: Set the Clock” on page 13 for details . Security Allows configuration of a password to lock the front panel of the Radio, and also lock xL channels .

  • Page 24: Wireless Network Configuration

    Wireless Network Configuration SiriusXM strongly recommends a wired internet connection for all business installations . To connect the Radio to a wireless network, you will need to know the wireless network name (SSID) and password/key if it is secured . For wireless networks with a hidden SSID, or those which require manual configuration, or those which have MAC address control, consult a professional installer .
  • Page 25 Wireless Network Configuration 7 . If a password/key is required, the Radio will briefly display a message indicating the type of key (WEP, WPA, etc .), and then prompt for the password/key . 8 . Enter the password/key . The password/key Network Key is case sensitive .

  • Page 26: Product Specifications

    Product Specifications System Power Requirements: 5 V DC, .7 A (max) Operating Temperature: 41° F to 95° F (5° C to 35° C) Audio Output: 1 .0 V rms (max) Business Radio Dimensions: 6 .5 in (W) x 6 .75 in (H) x 2 .75 in (D) 165 mm (W) x 171 mm (H) x 70 mm (D) Weight: 2 .5 lbs (1 .

  • Page 27: Patent And Environmental Information

    Patent and Environmental Information Patent Information It is prohibited to, and you agree that you will not, copy, decompile, disassemble, reverse engineer, hack, manipulate, or otherwise access and/or make available any technology incorporated in this product . The software is licensed solely for use within this product . The music, talk, news, entertainment, data, and other content on the Services are protected by copyright and other intellectual property laws and all ownership rights remain with the respective content and data service providers .

  • Page 28: Fcc Statement

    • Consult the dealer or an experienced radio/TV technician for help . WARNING! The FCC and FAA have not certified this Satellite Radio Receiver for use in any aircraft (neither portable nor permanent installation) . Therefore, Sirius XM Radio Inc . cannot support this type of application or installation .

  • Page 29: Copyrights And Trademarks

    AK and HI . © 2013 Sirius XM Radio Inc . “Sirius”, “XM” and all related marks and logos are trademarks of Sirius XM Radio Inc . and its subsidiaries . “BBC” and “Radio One”...
  • Page 32 Sirius XM Radio Inc . 1221 Avenue of the Americas siriusxm .com New York, NY 10020 1 .866 .345 .7474 © 2013 Sirius XM Radio Inc . SXBR1UG 130424a...
