Summary of Contents for RF Mogul Eagle
- Page 1 SATELLITE TV MANUAL 4 December 2013...
- Page 2 Eagle Manual...
-
Page 3: Table Of Contents
Eagle Manual ndex Warning ....... Mount Definitions ......Controller View ....... Configuration and Software Versions ....... Menu Options ....... Connector Wiring Diagram ....... Raising the ODU Using a 12 VDC Source ....... vGPS (DirecTV) Block Diagram ....... Foot Print and Clearances ....... -
Page 4: Warning
Eagle Manual WARNING Make all electrical and coax connections from the controller to the mount and LNB's BEFORE applying power to, or connecting the satellite receiver to the controller Note: When the controller is turned OFF it will still pass voltage from the receiver to the LNB if the receiver is plugged in to 110 AC. -
Page 5: Mount Definitions
Clam Shell Items included with the system and not shown. 1 ea LNB Landing Plate Control Cable, 25' 1 ea Connector, green, 12 pin 1 ea Power Supply, 12 VDC 7 amp 1 ea RE-1000 User Guide 1 ea EAGLE Controller... -
Page 6: Controller View
Eagle Manual ontroller Views FRONTAL VIEW Definitions and Usage CONTROLLER (IDU) FIND Directs the system to "FIND" Satellites Navigates through the menu and selects a particular function STOW Directs the system to "STOW" the mount and prepare it for travel... - Page 7 Eagle Manual REAR VIEW Definitions and Usage CONTROLLER (IDU) To REC To LNB CONNECTIONS POWER 12 VDC 7 amp (power supply provided) CONTROL CABLE CONNECTION: Termination of the 12 wires of the control cable to the controller takes place here.
-
Page 8: Configuration And Software Versions
Eagle Manual onfigurations and Software Version Each of the Program Providers will require different software SHAW Direct = 107.3, 107.3, 111.1 Satellites (For Canadian Use Only) EAGLE DirecTV SWM = 99, 101, 103 or 99,101,103,110 and 119 Satellites EAGLE Dish Network = 110, 119, 129 Satellites... -
Page 9: Menu Options
Eagle Manual enu Options Select menu options by Pressing the POWER or RETURN button once to turn ON the controller. At that time you may press SEARCH (UP arrow) to begin the search routine or STOW (DOWN arrow) to return the mount to its stowed or travel position. -
Page 10: Connector Wiring Diagram
Eagle Manual onnector Wiring Diagram Wiring the 12 Pin Controller Connector RAISING THE ODU USING A 12 VDC SOURCE TO RAISE THE MOUNT WITH A BATTERY Touch the following wires from the control cable directly to a drill battery or any 12 VDC source and it will result in movement... -
Page 11: Vgps (Directv) Block Diagram
Eagle Manual vGPS Block Diagram The longer right angle connector coax is attached to the switch in the position The DiSEqC switch is rotated slightly to vGPS "S2" marked and is routed allow attachment of the coax cable that to the vGPS. -
Page 12: Foot Print And Clearances
Eagle Manual ootprint and Clearances 39 Inches 8 1/2 Inches Rotational clearance from center rotation point is 18 inches when dish is elevated and rotating. This is a safety zone. 36 Inches CONTROLLER 10" Wide 6" Deep 2" high... -
Page 13: Operation
Eagle Manual peration POWER Pressing the POWER button once will turn the power ON or by holding the button depressed for 3 seconds will turn the power OFF. FIND(UP ARROW) After the power is turned ON pressing the FIND button once will instruct the mount to begin its searching routine and locate the satellites according to the configuration software. -
Page 14: Lcd Display
Eagle Manual Displays The LCD Display is designed to let you know the status of the mount as to its function at any given time. It will also display messages according to its directive to specific functions. Symptoms as to a operational malfunction will also be displayed. This information will be helpful when describing your systems malfunction to your installing dealer or a service technician. -
Page 15: Service Messages
Eagle Manual ervice messages Service messages will be displayed on the LCD screen should a condition occur that a person should be alerted to. If a condition should occur the following Service Messages will be displayed:... -
Page 16: Returning Parts To The Factory
Parts returned to the factory must contain a Return Material Authorization (RMA) which will be provided by the RF Mogul Technical Support Department at the time of troubleshooting. This will ensure proper accountability of returned equipment or parts. Make sure that the following information is contained on your shipment. - Page 17 Eagle Manual...
