- Page 1 SATELLITE TV OPERATION / TECHNICAL MANUAL 22 Sep. 2014...
- Page 2 Eagle Manual...
-
Page 3: Table Of Contents
Eagle Manual ndex ndex ndex ndex Warnings ....... Mount Definitions ......Controller Views ....... Configuration and Software Versions ....... Menus and Operations ....... Connector Wiring Diagram ....... Raising the ODU Using a 12 VDC Source ....... SWM DirecTV Block Diagram ....... -
Page 4: Warnings
90% of all problems are a result of incorrect CONNECTIVITY or CONFIGURATION. Mount Installation Warning Your Eagle mount utilizes a GPS system for acquisition. Calculations for skew and elevation are based on a level surface (+or- 3 Degrees, Right, Left, Forward and Back). Failure to level the mount to these specifications during installation can equate to poor performance. -
Page 5: Mount Definitions
Items included with the system and are not shown. 1 ea LNB Landing Plate Control Cable, 25' 1 ea Clam Shell 1 ea Connector, green, 12 pin 1 ea Power Supply, 12 VDC 7 amp 1 ea RE-1000 User Guide 1 ea EAGLE Controller... -
Page 6: Controller Views
Eagle Manual ontroller Views ontroller Views ontroller ontroller Views Views FRONT VIEW Definitions and Usage CONTROLLER (IDU) FIND Directs the system to "FIND" Satellites. Navigates through the menu and selects a particular function. STOW Directs the system to "STOW" the mount and prepare it for travel Navigates through the menu and selects a particular function. - Page 7 Eagle Manual REAR VIEW Definitions and Usage CONTROLLER (IDU) To REC To LNB CONNECTIONS POWER 12 VDC 7 amp (power supply provided). CONTROL CABLE CONNECTION: Termination of the 12 wires of the control cable to the controller takes place here.
-
Page 8: Configuration And Software Versions
Eagle Manual onfigurations and Software V onfigurations and Software Version ersion onfigurations onfigurations and Software V and Software V ersion ersion Each of the Program Providers will require different software EAGLE EAGLE EAGLE EAGLE SHAW Direct = 107.3, 107.3, 111.1 Satellites... -
Page 9: Menus And Operations
Eagle Manual enu Options enu Options enu Options enu Options Menus and Operation Your controller is menu driven. By selecting a particular menu you can perform many functions besides just "SEARCHING for satellite". TO SEARCH Press the Power button •... - Page 10 Updating and Maintaining Software The software can be maintained by use of a USB Flash Drive. Call RF Mogul for the software for your application. Make sure that it is placed in the "root • directory" and that no other .hex file is in that directory.
-
Page 11: Connector Wiring Diagram
Eagle Manual onnector Wiring Diagram onnector Wiring Diagram onnector Wiring Diagram onnector Wiring Diagram Wiring the 12 Pin Controller Connector RAISING THE ODU USING A 12 VDC SOURCE TO RAISE THE MOUNT WITH A BATTERY Touch the following wires from the control cable directly to a drill battery or any 12 VDC source and it will result in movement of the ODU. -
Page 12: Swm Directv Block Diagram
Eagle Manual Block Diagram Block Diagram Block Diagram Block Diagram Note: The SWM LNB has 8 channels available. Each DVR takes 2 channels (one coax). A non DVR uses one channel (one IDU Receiver line coax). You may use any... -
Page 13: Foot Print And Clearances
Eagle Manual ootprint and Clearances ootprint and Clearances ootprint and Clearances ootprint and Clearances 39 Inches 8 1/2 Inches 13 1/2 Inches Distance for installing LNB Landing Plate Rotational clearance from center rotation point is 18 inches when dish is elevated and rotating. -
Page 14: Returning Parts To The Factory
Parts returned to the factory must contain a Return Material Authorization (RMA) which will be provided by the RF Mogul Technical Support Department at the time of troubleshooting. This will ensure proper accountability of returned equipment or parts. Make sure that the following information is contained on your shipment.
