  • Page 1 H-LCDVD800 8" PORTABLE LCD MONITOR WITH BUILT-IN DVD-RECEIVER Instruction manual 8" DVD-...

  • Page 2: Table Of Contents

    Table of contents Table of contents ..................................2 Precautions ....................................3 Description ....................................5 Disc features ....................................6 Control functions ..................................10 Remote control ...................................12 Connecting ....................................16 Basic operations..................................18 Settings .......................................27 Troubleshooting..................................34 Specifications .....................................35...

  • Page 3: Precautions

    Precautions PLEASE READ THROUGH THE MANUAL CAREFULLY BEFORE CONNECTION AND OPERATION. CAUTION RISC OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO PREVENT THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALOFIED SERVICE PERSONNEL.
  • Page 4 Caution: Use of controls or adjustments or performance of procedures other than those specified here may result in hazardous radiation exposure. The use of Optical instruments with this product will increase eye hazard. Warning: To reduce the risk of fire, electric shock or product damage, do not expose this apparatus to rain, moisture, dripping or splashing and that no objects filled with liquids, such as vase, shall be placed on the apparatus.

  • Page 5: Description

    Description Accessories Power adaptor AV cable Earphone Car power connector Remote control User manual Battery pack Accessories bag Head rest bag This unit can play the following types of discs: Disc types Symbol Contents Audio + Video AC-3 Dolby Digital Audio Audio Video-CD Audio + Video...

  • Page 6: Disc Features

    Note: This unit can t read the 8 cm discs. Support of MPEG4 Standard: playback of digital video compressed in DivX 3.11, DivX 4.0, DivX5.0, DivX 6.0. (It may not be possible to play certain DivX disc due to the configuration and characteristics of the disc or condition of the recording).
  • Page 7 Features for DVD disc Different DVD discs have different combination of features, this is because of the different design created by the order and manufacturer, the following symbols indicate some features of the DVD disc. Regional code and the video output 5.1 sound channel output system Hiding subtitle...
  • Page 8 Handling discs When holding discs, please hold it by its rim. When holding discs, be sure the label side should be upwards. Do not grasp the non-label side of the disc. Disc storage Never store disc in the place with high temperature, strong light or humidity. Put the disc back to the case after playback.
  • Page 9 About Disc Terms Title Generally, pictures or music compressed on a DVD are divided into several sections that is TITLE . Chapter The smaller section unit of picture or music in a DVD under the title, usually one title is comprised of one or more chapters and each of them is numbered for easy searching.

  • Page 10: Control Functions

    Control functions Front panel 1. LCD 2. Speakers 3. Control buttons 4. Power LED indicator 5. IR receiver 6. Discs slot Control buttons: 1. PLAY/ PAUSE/ENTER button Press it to play. When pressing during playback, pause mode is set. Press again to resume playback.
  • Page 11 4. MODE button (Same function as SETUP key on the remote control) Press MODE button to enter mode, use +/- key to adjust relevant function: BRIGHTNESS CONTRAST SATURATION RESET DEFAULT EXIT ADJUSTMENT 5. -/+ buttons When entering MODE, press it to adjust relevant function. 6.

  • Page 12: Remote Control

    Remote control 1. EJECT button Press this button to eject disc. 2. SET- button Press this button to decrease the item value for TFT adjustment item. 3. AV/DVD button Press this button to switch video source as following: DVD => EXT => DVD.
  • Page 13 11. STOP button Press this button to stop playback. 12. ANGLE button Press it to switch angle. 13. AUDIO button Press this button to switch the audio language in DVD play status, and to switch audio channel in other status. 14.
  • Page 14 25. VOL +/- button Use this button to increase/decrease the volume level. 26. SETUP button Use this button to open the on-screen setup menu. 27. PROG button Press this button to program the play sequence. 28. PBC button Press this button to enter the menu of a DVD disc or to activate and disable the PBC functions of a VCD disc. 29.
  • Page 15 Replacing the battery 1. Pull out the battery holder to remove the battery compartment. 2. Insert a new battery into the battery holder. Make sure the positive (+) side is facing upward. 3. Put the battery compartment cover back to the remote. Note: To prevent leakage of fluid from the battery, remove the battery when not using the remote control unit for a long period of time (one month or more).

  • Page 16: Connecting

    Connecting Before connecting turn off the power of the player and the TV set to be connected. Connecting to a TV set Connecting to AC-DC adapter Connect video and audio cable (RCA) according to the Connect the AC-DC adapter to AC power socket. shape and color or the video/ audio cable to the output jacks Connect the DC output of adapter to DC in of the main unit.
  • Page 17 Connecting the battery Before using the battery Please fully charge the battery unit before using it for the first time. The battery unit becomes hot after recharging, but this is not malfunction. Battery storage Please place the battery in a proper environment (15ºC-25ºC). Recharge one time every year if the battery is not used in a long time.

  • Page 18: Basic Operations

    Basic operations Region code The region code is used in DVD players and on DVD discs. To be able to play the DVD disc the regional codes on DVD player and on DVD disc must be the same. If not, the player will not play the disc. This player is developed and made in compliance with the zone codes, recorded on DVD disc, and is able to playback discs of all zones.
  • Page 19 For double-side DVDs, check each side carefully, then push the disc in securely. For CDs or one-sided DVDs, you do not have to worry about touching the label (printed) side of the disc with your fingers. Since two-sided DVDs, however, have signal recorded on both sides, so be careful not to scratch them when removing them from the player.
  • Page 20 Menu playback Compatible with DVD, SVCD or VCD2.0 discs. 1. If the disc is a DVD, ROOT MENU will appear on the screen. When a DVD disc is loaded, you can press arrow buttons to highlight the menu item you want to choose. Press ENTER or PLAY button to begin play of the highlighted item.
  • Page 21 Slow playing the disc 1. Press SLOW on the remote control unit to slow playing. Change the playing speed to1/2, 1/3, 1/4, 1/5, 1/6 and 1/7 for every pressing SLOW. 2. Press SLOW to skip frame when the unit is in pause mode. 3.
  • Page 22 2. Loading and playing SVCD discs (two pages). Press DISPLAY button once to show the first page: "Disc Type, Track * / * (the playing track / total tracks), Mute, PBC, Repeat M ode, Elapsed Time of the Playing Track" Press the button again to show the second page: "Language * / * (the serial number of playing language /the amount of optional languages) or Off, Language Type, Audio Type, Subtitle * / * (the serial number of playing subtitle / the amount of optional subtitles) or Off".
  • Page 23 Changing an angle Available for DVD discs only. Press ANGLE to show the angle icon. Press it again to select the play angle when the main unit is in play mode. If multiple camera angles are available, the Angle icon displays the current angle number and the number of angles available. Changing an audio language Available for DVD, SVCD discs only.
  • Page 24 At last, press ENTER button to start layback. For example, entering 01:23:56 will start playback one hour, twenty-three minutes and fifty-six seconds into the title. If the input number is illegal, the error information "INVALID KEY " will be displayed on the screen.
  • Page 25 Programming the playback Compatible with DVD, SVCD, VCD, CD, CD-G, DTS-CD, HD-CD, WMA, MP3/JPEG discs. The Program playback option allows you to enter the order in which you t want chapters or tracks to play, maximum to 16. Program Menu: DVD, WMA, M /JPEG discs: T is for Title, C is for Chapter for DVD disc.
  • Page 26 Note: To clear the programmed order, use arrow buttons to highlight the "Clear" item, then press ENTER. To modify the programmed order, use arrow buttons to highlight the modifying item and enter the new chapter/ track you want to program directly. Using the OSD Press OSD to show the play and disc information on the LCD when the main unit is in play mode.

  • Page 27: Settings

    Settings Press SETUP when the main unit is in play mode. The setup menu will be displayed on LCD. Use the buttons to select the icon of the desired page (System setup, Language setup, Audio setup, Karaoke setup). Use the buttons to select the desired option.
  • Page 28 TV type 4:3PS:select this item when connecting this unit to a normal TV set. 4:3LB:select this item when connecting this unit to a normal TV set. 16:9: select this item when connecting this unit to a 16:9 TV set. Note: Picture scale depends on the disc.
  • Page 29 Default setting To restore the factory setting, please select Restore and press ENTER. Language setup OSD language Select the OSD language menu. If the disc you are playing supports this language, the OSD will be in that language. Audio language Select the audio language menu.
  • Page 30 Subtitle language Select the Subtitle language menu. If the disc you are playing supports this language, the subtitle will be in that language. Menu language Select the Menu language menu. If the disc you are playing supports this language, the menu will be in that language.
  • Page 31 Downmix LT/ RT: Choose this setting, it will be sound like in a movie theatre if the original movie the disc was recorded from was encoded in the Pro Logic Dolby Digital format. STEREO: Choose this setting, when 5.1-channel sound playing, two channels of signals will be output from the left and right soundtrack;...
  • Page 32 Karaoke setup Mic setup There are two MIC settings in the MIC SETUP option: AUTO and OFF. When selecting AUTO, the player will auto detect and deal with the input voice. When selecting OFF, the player will do nothing with the MIC input. For example, when playing a VCD2.0 karaoke disc, choose AUTO to enable Auto A/D Detect Feature.
  • Page 33 Use the button to move the scroll and adjust the key.

  • Page 34: Troubleshooting

    Troubleshooting Symptom Comments Picture is disturbed when playing a DVD This player incorporates copyright Protection technology. Some discs include signal protected recorded by a VCR against copied by a VCR. Such recorded discs can not be played properly. Remote control unit not working Remote control unit is too far from the main unit or has too large angle with the remote sensor.

  • Page 35: Specifications

    Specifications Power supply DC 9 V~13.8 V Power consumption < 10 W Battery pack capacity 7.4 V/ 5400 mAh DVD player Battery pack discharge time > 3 hours Display Screen TFT-LCD color display External dimensions (L x W x H) 235 x 185 x 30 mm Video formats NTSC/PAL (including input, output and display) display...
  • Page 36 ....................................36 ................................37 ....................................39 ................................40 ................................44 ............................46 .....................................50 ..................................52 ....................................61 ............................68 ..............................69...
  • Page 38 DVD-...
  • Page 39 AC-3 Dolby Digital Video-CD (VCD) CD-DA Kodak Picture MPEG4 DivX...
  • Page 40 MPEG4: DivX 3.11, DivX 4.0, DivX5.0, DivX 6.0 DivX SVCD MPEG 2 MPEG I MPEG II DIGIT 12/8 12/8 $500 $240 $350...
  • Page 41 DVD- 5.1 - Dolby digital surround...
  • Page 43 DVD- DVD- SVCD, VCD VCD, « » PBC (SVCD,VCD) SVCD VCD, PBC ( 1.1) SVCD/VCD, PBC ( 2.0)
  • Page 44 PLAY/ PAUSE/ ENTER STOP/ ON/ OFF PREVIOUS/ NEXT 2, 4, 8, 20.
  • Page 45 MODE SETUP BRIGHTNESS: CONTRAST SATURATION RESET DEFAULT EXIT ADJUSTMENT EJECT AV IN AV IN/OUT. AV OUT AV IN/OUT. DC input ( AC/DC...
  • Page 46 EJECT SET- AV/DVD DVD=>EXT=>DVD. ROOT/MENU 10+: RETURN PLAY/ PAUSE ZOOM...
  • Page 47 SLOW STOP ANGLE AUDIO MUTE GOTO NEXT PREVIOUS MODE : Brightness=>Contrast=>Saturation=>Hue=>Reset Default=>Exit Adjustment. SET+ TITLE SUBTITLE DVD.
  • Page 48 CLEAR ENTER VOL+/- SETUP PROG REPEAT DVD: CD/ VCD: 31. P/N DIGEST FORWARD...
  • Page 49 , «+»...
  • Page 50 AC-DC AC-DC AV OUT Note: AC-DC : 12 / 1.5 A. , DVD AV IN...
  • Page 51 (15ºC-25ºC). OSD, AC/DC AC/DC...
  • Page 52 DVD- DVD- DVD- DVD: . LED Read . No disc . LED EJECT. Open . Disc loading ,...
  • Page 53 STOP, EJECT PLAY/ PAUSE, PLAY/ PAUSE MUTE, MUTE VOL +/- , STOP, » PLAY/ PAUSE, STOP...
  • Page 54 TITLE, ENTER. DVD, SVCD VCD2.0 DVD, ENTER PLAY, MENU. SVCD VCD2.0, PBC, SVCD VCD2.0, SVCD VCD2.0 MENU. ENTER PLAY, SVCD VCD2.0, MENU (PBC) RETURN. (DVD, PREVIOUS, NEXT, REV/ FORWARD REV/ FORWARD X2, X4, X8, X20...
  • Page 55 PLAY, CD, HD-CD, MP3, WMA SLOW : 1/2, 1/3, 1/4, 1/5, 1/6, 1/7. SLOW, PLAY, REPEAT, SVCD, VCD, CD, CD-G, HD-CD, DTS-CD, WMA MP3 /JPEG : OFF, TRACK repeat, DISC repeat. REPEAT, OFF, CHAPTER repeat, TITLE repeat. WMA, MP3, JPEG REPEAT, OFF, TRACK repeat, DIRECTORY repeat, DISC repeat.
  • Page 56 DVD ( DISPLAY */* ( */* ( */* ( */* ( SVCD ( */* ( , PBC, */* ( VCD. */*( , PBC, MP3/JPEG. DISPLAY */*(...
  • Page 57 SEARCH. ENTER ENTER, SEARCH, SUBTITLE, ANGLE, AUDIO, AUDIO, DVD, SVCD. L/R, SVCD : Stereo (L/R), L/L, R/R, L/L Auto A/D Detect R/R Auto A/D Detect. Stereo.
  • Page 58 CD, CD-G, DTS-CD, HD-CD, WMA Stereo (L/R), L/ L, and R/ R. L/R, (Zoom) ZOOM : Zoom1, Zoom 2, Zoom 3, Zoo 1/2, Zoom 1/3, Zoom 1/4, Zoom off. 1, 2, 3 P/ N, P/ N : NTSC, PAL60, PAL, AUTO. P/ N.
  • Page 59 ODE, +/-, DVD, SVCD, VCD, CD, CD-G,DTS-CD, HD-CD, WMA, MP3/JPEG DVD, WMA, M /JPEG DVD. SVCD, VCD, CD, CD-G, HD-CD, DTS-CD PLAY "Play" ENTER.
  • Page 60 PROGRAM, STOP, PLAY, CLEAR, ENTER, OSD,...
  • Page 61 SETUP (System setup, Language setup, Audio setup, Karaoke setup). ENTER, (System setup) (TV system) NTSC PAL60 AUTO : NTSC (Screen saver) 1 MIN: 5 MIN: 10 MIN: 30 MIN: OFF:...
  • Page 62 (TV type) 4:3PS (pan scan): 4:3LB (letter box): 16:9 (wide screen): (Password) RATING ( RATING ( PASSWORD ( 0000 ( ENTER ENTER, ENTER 000000. (Rating) NO ADULT ( ), KID SAFE ( ), VIEW ALL ( VIEW ALL VIEW ALL.
  • Page 63 (Default) RESTORE ( ENTER. (Language setup) (Audio lang)
  • Page 64 (Subtitle lang) (Menu lang) (Audio setup) (Audio out) SPDIF/OFF: SPDIF/RAW: Dolby Digital.
  • Page 65 Dolby Digital, Dolby Digital. DTS, DTS, SPDIF/RAW. SPDIF/PCM SPDIF/PCM: Dolby Digital. Dolby Digital, (Downmix) DVD- 5.1- Dolby Digital Dolby Surround. LT/RT: Dolby Digital, Dolby Pro Logic. Dolby Digital 5.1, Dolby Pro Logic, STEREO: VSS: Dolby Surround. (Dynamic range) Line out, DOWNMIX...
  • Page 66 (Down sample) 48K: DVD, 96K: DVD, 192K: DVD, (Karaoke setup) (Mic setup) : AUTO ( OFF ( AUTO, VCD2.0, AUTO, A/D Detect. OFF, "ECHO","MIC VOL","KEY" (Echo)
  • Page 67 (Mic vol) (Key)
  • Page 68 DVD CD The player crashes LOADING EJECT, DTS.
  • Page 69 DC 9 ~13,8 < 10 7.4 / 5400 > 3 235 x 185 x 30 NTSC/ PAL ( (RL=75 1.0 ± 0.2 60, PM: 75 / 75 (RL = 10 2.00 ± 2 ± 1 600 / 600...
