Figure 1: Dimensions
289mm (1-1/8)
570mm (22-7/16)
TABLE 1: Ratings and Dimensions
BOILER
MODEL OIL INPUT † §
NO.
mL/s GPH Watts BTU/H
EC-13A 0.68 0.65 26,672 91,000
EC-13B 0.74 0.70 28,724 98,000
EC-14A 0.84 0.80 32,827 112,000
EC-14B 0.95 0.90 36,931 126,000
EC-15A 1.05 1.00 41,034 140,000
EC-15B 1.16 1.10 45,137 154,000
EC-16A 1.21 1.15 47,189 161,000
EC-16B 1.32 1.25 51,293 175,000
Maximum operating pressure 414 kPa (60 psi).
All boilers hydrostatically tested — A.S.M.E.
* For forced hot water heating systems where the boiler and all piping are located
within the area to be heated, the boiler may be selected on the basis of net
capacity output. The net output ratings shown are based on an allowance for
piping and pickup of 1.15 (water). Gross capacity output is divided by the
allowance to obtain net rating. The Slant/Fin Technical Service department
should be consulted before selecting a boiler for unusual piping and pickup
requirements such as intermittent system operation, extensive piping, etc.
† Ratings apply to the use of light oil at 11 000 W/L (140,000 Btu per gallon) and
apply only when burner models listed on pages 13 and 16 of this manual are
used, and are properly adjusted to produce 13% CO
32mm (1-1/4")
threaded supply
(4) 3/8-16 studs
on ∅ 6-29/32 4
markings on ∅
176mm (6-15/16)
∅ 110mm
60mm (2-23/64)
(4-21/64) hole
∅ 130mm
(6-7/64) cut-out
79mm (11-3/8)
Note: Add 203mm (8") to B dimensions to allow for Riello burner
CHIMNEY SIZE
GROSS NET I.D. ROUND
OUTPUT* OUTPUT* I.D. ROUND
X HEIGHT
kW MBH kW MBH mm x m (in X ft.)
23 79 20 69 152 x 4.6
25 85 22 74 152 x 4.6
29 98 25 85 152 x 4.6
32 109 28 95 152 x 4.6
36 123 31 107 152 x 4.6
39 134 34 117 152 x 4.6
41 141 36 123 152 x 4.6
45 152 39 132 152 x 4.6
.
2
163mm
(6-27/64)
APPROX.
BOILER
OVERALL
LENGTH
LENGTH
"A" "B"
mm in mm
6 x 15 87 914 36 25
6 x 15 86 914 36 25
6 x 15 87 1041 41 686
6 x 15 86 1041 41 686
6 x 15 87 1168 46 819
6 x 15 86 1168 46 819
6 x 15 87 1295 51 946
6 x 15 86 1295 51 946
§ Boiler models have two firing rates. The boiler is factory shipped at the lower
firing rate. To obtain the higher firing rate, refer to the boiler installation
instructions for the appropriate field adjustments.
# All dimensions subject to normal manufacturing tolerance.
NOTE: All boilers under 87.9 kW (300,000 Btuh) input are tested and certified for
A.F.U.E. capacities.
355mm
(13-3/32)
156mm
(6-9/64")
285mm (11-7/32)
570mm (22-7/16)
. DIMENSIONS
BOILER DISTANCE BETWEEN
FLUE DIA
LENGTH
"C" "D"
in. mm in. mm (in.)
22-1/4 686 27 127 5
22-1/4 686 27 127 5
27 813 32 127 5
27 813 32 127 5
32-1/4 940 37 127 5
32-1/4 940 37 127 5
37-1/4 1067 42 152 6
37-1/4 1067 42 152 6
EUTECTIC EC-10
195mm (7-11/16)
Relief valve
19mm (3/4")
32mm (1-1/4)
threaded return
pipe
.
FLUE
OUTLET
LEGS
LENGTH
"E" "F"
mm in. mm in.
300 11-13/16 51 2
300 11-13/16 51 2
427 16-13/16 51 2
427 16-13/16 51 2
554 21-13/16 51 2
554 21-13/16 51 2
681 26-13/16 102 4
681 26-13/16 102 4
