Ratings And Dimensions - Slant/Fin EUTECTIC EC-16-1.25 Installation And Operating Instructions Manual

2
Figure 1: Dimensions
Supply Pipe Mounted
Tridicator
TABLE 1: Ratings and Dimensions
AHRI
BURNER
CAPACITY
BOILER
OIL INPUT † §
MODEL
GPH
NO.
EC-13P 0.65
EC-13-0.7 0.70
EC-14P 0.80 112,000
EC-14-0.9 0.90 126,000
EC-15P 1.00 140,000
EC-15-1.1 1.10 154,000
EC-16P 1.15 161,000
EC-16-1.25 1.25 175,000
Maximum operating pressure 60 psi.
All boilers hydrostatically tested — A.S.M.E.
* For forced hot water heating systems where the boiler and all piping are
located within the area to be heated, the boiler may be selected on the basis
of D.O.E. capacity output. The net AHRI output ratings shown are based on
an allowance for piping and pickup of 1.15 (water). D.O.E. capacity output is
divided by the allowance to obtain net rating. The Slant/Fin Technical Service
department should be consulted before selecting a boiler for unusual piping
and pickup requirements such as intermittent system operation, extensive
piping, etc.
† Ratings apply to the use of light oil at 140,000 Btu per gallon and apply only
when burner models listed on pages 13 and 17 of this manual are used, and
1-1/4 threaded
supply
D.O.E. AHRI
HEATING WATER
CAPACITY NET
MBH * RATING
BTUH
WATER MBH *
91,000 79 69
98,000 85 74
98 85
109 95
123 107
134 117
141 123
152 132
A
AHRI
CHIMNEY SIZE
APPROX.
OVERALL
I.D. ROUND
LENGTH
X HEIGHT
AFUE %
"A"
(in x ft)
6 x 15 87 36
6 x 15 86 36
6 x 15 87 41
6 x 15 86 41
6 x 15 87 46
6 x 15 86 46
6 x 15 87 51
6 x 15 86 51
are properly adjusted to produce 13% CO 2 .
§ Boiler models have two firing rates. The boiler is factory shipped at the lower
firing rate. To obtain the higher firing rate, refer to the boiler installation
instructions for the appropriate field adjustments.
# All dimensions subject to normal manufacturing tolerance.
NOTE: All boilers under 300,000 Btuh (87.9 kw) input are tested and rated for
capacity under the U.S. Department of Energy (D.O.E.) Test Procedures for
Boilers.
EUTE TI
Panel Mounted
Tridicator Temperature
Sensor Well
DIMENSIONS (inches) #
BOILER BOILER FLUE
LENGTH LENGTH DIA.
"B" "C" "D"
22-1/4 27 5
22-1/4 27 5
27-1/4 32 5
27-1/4 32 5
32-1/4 37 5
32-1/4 37 5
37-1/4 42 6
37-1/4 42 6
E -10
Panel Mounted
Tridicator Pressure
Sensor Well
Relief valve 3/4''
Flue outlet øD
1-1/4 threaded
return pipe
Drain outlet
DISTANCE FLUE
BETWEEN OUTLET
LENGTH
LEGS
"E" "F"
11-13/16 2
11-13/16 2
16-13/16 2
16-13/16 2
21-13/16 2
21-13/16 2
26-13/16 4
26-13/16 4
