Ratings And Dimensions; Installation Requirements; Boiler Location - Slant/Fin Intrepid TR Series Installation And Operating Instructions Manual

TR Series
RATINGS
Boiler
OIL INPUT
Model
Number
mL/s† USGPH† kW MBH kW
*
1.15 1.10 45 154 39
TR-30
1.31 1.25 51 175 44
1.68 1.60 66 224 55
TR-40
1.89 1.80 74 252 63
2.20 2.10 86 294 72
TR-50
2.47 2.35 96 329 80
Standard Working Pressure 207 kPa (30 PSI) water, 103 kPa (15 PSI) steam.
All boilers hydrostatically tested—A.S.M.E.
* ADD SUFFIX
X —Denotes no circulator and no thermostat
P —Packaged water boiler has tankless heater
PT —Packaged water boiler with tankless heater
PZ —Packaged steam boiler less tankless heater
PZT —Packaged steam boiler with tankless heater
§§ Tankless heater rating based on intermittent draw.
† Ratings apply to the use of light oil of 11,000 W/L (140,000 Btu per gallon.)
** The Net ratings shown are based on a piping and pick-up allowance of 1.15 for
water and 1.333 for steam. For installations having unusual piping and pick-up
requirements, additional allowance should be made before selecting the boiler.

INSTALLATION REQUIREMENTS

BOILER LOCATION

Provide a level, solid foundation for the boiler. Location should be near
the chimney so that the Flue Pipe Connector or Breeching to the chim
ney is short and direct.
A. The foundation must be capable of supporting the weight of
the boiler when filled with water:
B. The TR Series Boiler has full wet base sections which surround
fire box for maximum heat absorption of burning fuel, and low floor
temperature.
C. If boiler is to be located over buried conduit containing electric wires
or telephone cables, consult local codes or the National Board of
Fire Underwriters for specific requirements.
Boiler
Approximate Total Weight of Boiler
Size
Assembly, filled with water
kg
TR- 20
200
TR-30
250
TR-40
300
TR-50
355
TR-60
405
TR-70
455
GROSS OUTPUT
Water Steam Water**
MBH kW MBH MBH kW
kW
132 39 132 117 30
34
149 – – 131
38
188 55 188 170 43
48
214 – – 190
55
246 72 246 223 56
63
272 – – 237
69
lbs
440
550
660
785
895
1000
NET OUTPUT CHIMNEY SIZE
Rectangular
Round I.D. ×
Steam** Steam
I.D. × Height Height
2 n × n × ft in × ft
MBH m Sq. Ft.
mm × mm × m
mm × m
101 39 421 6"×15'
8"×8"×15'
152×4.6m
– – – –
203×203
×4.6m
146 56 606
7"×15'
– – – –
178×4.6m
8"×12"×15'
191 74 796
203×305×
8"×15'
– – – – 4.6m
203×4.6m
P
Model
kg
TR 30 217
TR 40 257
TR 50 305
MINIMUM CLEARANCE
Provide accessibility clearance of 610 mm ( 24") from surfaces requiring
servicing (top and front) and 457 mm (18") on any side requiring pas
sage. The boiler shall be installed with the following MINIMUM clear
ances from combustible materials:
A. CHIMNEY CONNECTOR 457 mm (18")
B. BACK AND LEFT SIDE 152 mm (6") except as limited by 457 mm
(18") clearance for chimney connector
C. RIGHT SIDE 152 mm (6") except for allowing for Burner door fully
open which requires for:
Beckett Burner 191 mm (7
Riello E Series Burner 267 mm (10
D. FLOOR the boiler is approved for installation on a combustible
floor, but subject to any local code requirements. NOT to be
installed on or over carpet.
NOTE: As an alternate:
The burner door is removable so that the above service clearances are
not mandatory.
CAUTION: NEVER BURN GARBAGE OR
PAPER IN THE BOILER
AND NEVER LEAVE COMBUSTIBLE
MATERIAL ON OR AROUND IT.
WITH BECKETT BURNER
AFUE % FLUE SIZE
Water Steam mm In.
152 6
84.8 84.1
152 6
83.5 –
178 7
84.4 83.8
178 7
83.3 –
203 8
84.0 83.4
– –
203 8
PT PZ
lbs. kg lbs. kg
479 221 488 215
566 261 575 254
673 309 682 295
1 / ")
2
1 / ")
2
3
TANKLESS HEATER §§
Water Steam
mL/s USGPM mL/s USGPM
3.00
189
202 3.20
–
–
214 3.40
3.50
221
246 3.90
261 4.15 –
–
284 4.40 4.00
252
296 4.70
–
–
PZT
lbs. kg lbs.
473 224 483
559 263 579
671
651 304
