4.3 INCH WIDE COLOR DIGITAL SCREEN TFT
MOTORIZED SLIDE DOWN AND DETACHABLE PANEL
CAR DVD/VCD/CD/MP3/MPEG4/USB PLAYER
AM/FM DIGITAL RADIO AND TV TUNER
REL
BND
PAIR
DEAR CUSTOMER
Congratulations for your purchase!
Please read this manual carefully,and deep it for future reference.
If you need extra support,please write to
INSTRUCTIONAL MANUAL
SCR-2070TFT
RESET
VOL
COMPACT
DIGITAL AUDIO
AUX/MP3-IN
CAR DVD/VCD/CD/MP3/MPEG4/TV PLAYER
SCR-2070TFT
DVD/RECEIVER CONTROL
DVD/RECEIVER CONTROL
MODE
MUTE
PLAY/PAUSE
STOP
REDIAL
ANGLE
MO/ST
PAIR
LOUD
MENU
EQ
CLK
LO/DX
OSD
BAND
ENTER
TITLE/PBC
A/PS
VOL
TOP
RPT
INT
1
3
2
VOL
RDM
4
5
6
7
8
9
SEL
+10
0
SETUP
GOTO
info@premiermundo.com
MU
IR
COMPACT
DIGITAL VIDEO
EQ
SEL
MIC
CH 1-6
MOD
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Premier SCR-2070TFT
Summary of Contents for Premier SCR-2070TFT
- Page 1 INSTRUCTIONAL MANUAL 4.3 INCH WIDE COLOR DIGITAL SCREEN TFT MOTORIZED SLIDE DOWN AND DETACHABLE PANEL CAR DVD/VCD/CD/MP3/MPEG4/USB PLAYER AM/FM DIGITAL RADIO AND TV TUNER SCR-2070TFT RESET COMPACT DIGITAL VIDEO COMPACT DIGITAL AUDIO PAIR CH 1-6 AUX/MP3-IN CAR DVD/VCD/CD/MP3/MPEG4/TV PLAYER SCR-2070TFT...
-
Page 2: Table Of Contents
WWW.PREMIERMUNDO.COM WWW.PREMIERMUNDO.COM CONTENTS Safety Information..................Disc Notes ....................Installation ....................Panel Angle Adjustment ................Electric Connection ..................Remote Control ..................Basic Operation ..................MP3/WMA/JPEG Disc Play ..............MPEG4 Player ..................AUX Operation ..................Scroll Caption Adjustment ................. Blue-tooth Operation ................Video Quality Adjustment ............... -
Page 3: Safety Information
WWW.PREMIERMUNDO.COM WWW.PREMIERMUNDO.COM SAFETY INFORMATION CAUTION: THIS DVD PLAYER IS A CLASS I LASER PRODUCT. HOWEVER THIS DVD PLAYER USES A VISIBLE/INVISIBLE LASER BEAM WHICH COULD CAUSE . HAZARDOUS RADIATION EXPOSURE IF DIRECTED. BE SURE TO OPERATE THE DVD PLAYER CORRECTLY AS INSTRUCTED. USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.DO NOT OPEN COVERS AND DO NOT... -
Page 4: Disc Notes
WWW.PREMIERMUNDO.COM WWW.PREMIERMUNDO.COM DISC NOTES Disc formats supported by this unusable) depending on your handle it player and conditions in the usage environment. Note these scratches are not an Audio and Video indication of any problem with the player. Disc size 12 cm Label side Audio and Video Disc size 12 cm... -
Page 5: Installation
WWW.PREMIERMUNDO.COM WWW.PREMIERMUNDO.COM INSTALLATION NOTES: Choose the mounting location where the unit will not interfere with the normal driving function of the driver. Before finally installing the unit, connect the wiring temporarily and make sure it is all connected up properly and the unit and the system work properly. Use only the parts included with the unit to ensure proper installation. - Page 6 WWW.PREMIERMUNDO.COM WWW.PREMIERMUNDO.COM INSTALLATION DASH BOARD HEX NUT METAL MOUNTING STRAP SPRING WASHER CONSOLE PLAIN WASHER SLIDE BRACKET TAPPING SCREW HOUSING HEX BOLT KEY PLATE PLASTIC COVER KEY PLATE If you want to take CHASSIS out of the SLIDE BRACKET HOUSING, first remove the PLASTIC COVER of the both sides away, then insert the two KEY PLATE into left and right side of chassis as above illustration.
- Page 7 WWW.PREMIERMUNDO.COM WWW.PREMIERMUNDO.COM INSTALLATION How To Remove And Install The Front Panel When detaching or attaching the control panel, be careful not to damage the connectors on the back of the control panel and on the panel holder. Detaching The Front Panel Before detaching the control panel, be sure to turn off the power.
-
Page 8: Panel Angle Adjustment
WWW.PREMIERMUNDO.COM WWW.PREMIERMUNDO.COM PANEL ANGLE ADJUSTMENT CHANGING THE CONTROL PANEL ANGLE When you want to change the viewing angle of the operating unit to play, you can press the (angle)button repeatedly to select the desired angle as follows: Angle 1 Angle 2 Angle 4 Angle 3 Caution:... -
Page 9: Electric Connection
WWW.PREMIERMUNDO.COM WWW.PREMIERMUNDO.COM ELECTRIC CONNECTION WIRING CONNECTION MAIN UNIT (B+)12V WHITE REAR CAMERA SWITCH GREEN (B-)PARKING BRAKE TV ANT IN YELLOW REAR CAMERA INPUT AUX(optional) VIDEO IN YELLOW RCH IN RED ANTENNA CONNECTOR LCH IN WHITE RCA CABLE GREY SUBWOOFER VIDEO OUT 2 YELLOW IGNITION COAXIAL OUT BROWN SWITCH(B+) -
Page 10: Remote Control
WWW.PREMIERMUNDO.COM WWW.PREMIERMUNDO.COM REMOTE CONTROL DVD/RECEIVER CONTROL DVD/RECEIVER CONTROL MODE MUTE PLAY/PAUSE STOP MO/ST REDIAL ANGLE PAIR LOUD MENU LO/DX BAND ENTER TITLE/PBC A/PS GOTO SETUP Press it briefly to show / hide the clock, press longer to set the time. 1.CLK Press it to use the Bluetooth function , refer to the page 16 . -
Page 11: Preparing The Remote Control
WWW.PREMIERMUNDO.COM WWW.PREMIERMUNDO.COM REMOTE CONTROL In TV mode, press it to ADD and DELETE channel . 24.SKIP In DISC mode, press it to reverse rapidly Numeric buttons. 25. 0 - 9 26.+10/ Tens digit select button, cooperatively used with numeric buttons. In Bluetooth menu, it serves as the button on your mobile handset. -
Page 12: Basic Operation
PAIR CH 1-6 AUX/MP3-IN CAR DVD/VCD/CD/MP3/MPEG4/TV PLAYER SCR-2070TFT 1.REL BUTTON Press the REL button to release the removable front panel. Refer to see page 6 (POWER On/Off)/MOD BUTTON Press it to switch the device ON, press and hold (approximately 2 seconds) to switch the device OFF . - Page 13 WWW.PREMIERMUNDO.COM WWW.PREMIERMUNDO.COM BASIC OPERATION . BAND BUTTON In RADIO mode, press the BAND button on the front panel or on the remote controller to select your desired radio band and word which band is selected will be displayed in the TFT . Press it to change the bands as below : For 3 Bands (Europe) For 2 Bands (Europe) For 2 Bands (USA)
- Page 14 WWW.PREMIERMUNDO.COM WWW.PREMIERMUNDO.COM BASIC OPERATION /CH 1-6 BUTTON (RADIO PRESET) a). In Disc Playback Mode Press this button to pause playback, press it again to resume playback. b). In Radio Mode Press this button repeatedly to preset station. With this system a total of 30 stations can be stored in the memory .
- Page 15 WWW.PREMIERMUNDO.COM WWW.PREMIERMUNDO.COM BASIC OPERATION TOP/RPT/INT/RDM FUNCTION (Only for the RC.) A. To memorize the current frequency, press any one of the six preset buttons[1-6] on the remote controller hold for more than 2 seconds. B. To recall the preset memory, press one of the preset buttons [1-6]. C.
-
Page 16: Mp3/Wma/Jpeg Disc Play
WWW.PREMIERMUNDO.COM WWW.PREMIERMUNDO.COM BASIC OPERATION MP3/WMA/JPEG/MPEG4 DISC PLAY 1.When inserting an MP3/WMA/JPEG disc. Ex: When MP3 file is detected. .Current track(file)(highlighted bar) .Current track (file) number/total 00:56 04:07 number of tracks(files) in the current Repeat one 003/112 folder. .Elapsed playing time of the current track( not available for JPEG disc) .total playing time. -
Page 17: Blue-Tooth Operation
WWW.PREMIERMUNDO.COM WWW.PREMIERMUNDO.COM BASIC OPERATION BLUETOOTH CAR KIT USER MANUAL 1. “Pair” To Your Bluetooth Phone Prior to using the Car Kit for the fist time, you must pair it with a Bluetooth-enabled mobile handset. The following steps describes pairing the instruction for a typical Bluetooth- enabled mobile handset. -
Page 18: Video Quality Adjustment
WWW.PREMIERMUNDO.COM WWW.PREMIERMUNDO.COM BASIC OPERATION Adjust the Volume During conversation in progress, tune the Volume switch until you reach the desired volume level. Play MP3 music In Bluetooth menu, press MOD to select the “BT MUSIC”, you can play the MP3 from your mobile handset. -
Page 19: Usb Operation
WWW.PREMIERMUNDO.COM WWW.PREMIERMUNDO.COM BASIC OPERATION USB Operation On-Screen Display Function Following the diagram below, connect Press the OSD button during playback your USB device to the front panel to display the contents of the current USB port . If it is properly connected, disc on the screen. -
Page 20: Multi-Audio Language Function
WWW.PREMIERMUNDO.COM WWW.PREMIERMUNDO.COM BASIC OPERATION Notes: e.Press for the fifth time: - The language number is different The message on the screen will be according to the disc. cleared for SVCD and VCD. - Some discs only contain one subtitle C.Example for MP3: language. -
Page 21: Setup
WWW.PREMIERMUNDO.COM WWW.PREMIERMUNDO.COM SETUP GENERAL SETUP --- GENERAL PAGE --- DOLBY DOLBY -----General setup page---- -----General setup page---- TV Display TV Display Normal/PS Normal/LB Angle Mark Angle Mark Wide OSD Lang OSD Lang SPDIF/RAW Spdif Output Spdif Output Captions Captions Screen Saver Screen Saver Last Memory Last Memory... - Page 22 WWW.PREMIERMUNDO.COM WWW.PREMIERMUNDO.COM SETUP DOLBY DOLBY -----General setup page---- -----General setup page---- TV Display TV Display Angle Mark Angle Mark OSD Lang Osd Lang SPDIF OFF Spdif Output Spdif Output SPDIF/RAW Captions Captions SPDIF/PCM Screen Saver Screen Saver Last Memory Last Memory Set Angle Mark Setup SPDIF ANGLE MARK DISPLAY SETUP...
-
Page 23: Speaker Setup
WWW.PREMIERMUNDO.COM WWW.PREMIERMUNDO.COM SETUP SPEAKER SETUP DOLBY --- SPEAKER SETUP PAGE --- DOLBY -----General setup page---- TV Display -----Speaker Setup Page---- Angle Mark OSDLang DOWNMIX LT/RT Spdif Output STEREO Captions Screen Saver Set Downmix Mode Last Memory Screen Saver This is to activate the audio output from DOLBY AC3 5.1 DOWNMIX to 2 channel mode. -
Page 24: Preferences Setup
WWW.PREMIERMUNDO.COM WWW.PREMIERMUNDO.COM SETUP PREFERENCES SETUP --- PREFERENCES PAGE --- DOLBY DOLBY -----Preference Page---- -----Preference Page---- TV Type TV Type English AUTO Audio Audio French NTSC Subtitle Subtitle Spanish Disc Menu Disc Menu German Parental Parental Italian Password Password Portuguese Default Default Set TV standard Preferred Subtitle Language... -
Page 25: Defaults Table
WWW.PREMIERMUNDO.COM WWW.PREMIERMUNDO.COM SETUP DOLBY DOLBY -----Preference Page---- -----Preference Page---- 1KID SAF TV Type TV Type Audio Audio Subtitle Subtitle 4PG13 Disc Menu Disc Menu 5PGR Parental Parental Password Password 7NC 17 Default Default RESET 8 ADULT Load Fcatory Setting Set Parental Control 7.DEFAULTS 5.PARENTAL Select reset to become factory initial... -
Page 26: Specifications
WWW.PREMIERMUNDO.COM WWW.PREMIERMUNDO.COM SPECIFICATION Supply Voltage: 12V DC (11V-15V) Current Consumption: Less than10 A Signal System: Compositive video 1.0Vp-p 75 Discs Played: (1)DVD-VIDEO Disc 5"(12 cm) single-sided, single-layer 5"(12 cm) single-sided, double-layer (2)Compact Disc (CD-DA, VIDEO CD) 5"(12cm) disc TV System: NTSC/PAL-M/N TV Sensitivity: Audio Signal Output:... -
Page 27: Trouble Shooting
WWW.PREMIERMUNDO.COM WWW.PREMIERMUNDO.COM TROUBLE SHOOTING Before going through the check list, check wiring connection. If any of the problems persist after check list has been made, consult your nearest service dealer. SYMPTOM CAUSE SOLUTION If the power supply is properly connected to the car accessory The car ignition switch is terminal,switch the ignition key not on...
