- Page 1 S E A T I N G U N I T FOUR WHEEL BASE It can It can be fixed be fixed on 3 on 3 BASES BASES THREE JOGGER FEEDING BASE WHEEL BASE USE AND MAINTENANCE HANDBOOK USE AND MAINTENANCE HANDBOOK...
- Page 3 If, after reading it, you still have questions, contact your retailer, who will be happy to help you, or call ORMESA directly at +39 0742 22927, send a fax to +39 0742 22637 or send an e-mail to: info@ormesa.com...
-
Page 4: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS ........................2 WARNINGS............................4 SOME EXAMPLES OF WHAT NOT TO DO WITH ................5 THE PRODUCT..........................5 HOW TO TILT THE STROLLER AND CLIMB UP CURBS............5 LABELS AND PLATES ........................6 WHAT IS New BUG ...........................6 TECHNICAL FEATURES ........................6 BASE 869 BRAKING ........................7 BASE 901 BRAKING ........................7 BASE 856 BRAKING ........................8... - Page 5 ADJUSTING THE PADDED SIDE SUPPORTS ................39 ADJUSTING THE DEPTH OF THE SEAT..................40 FRONT WHEEL DIRECTION LOCKS................... 40 TECHNICAL SPECIFICATIONS of New BUG with BASE ..........42 INITIAL PREPARATION........................44 PACKAGING INFORMATION ....................... 44 HOW and WHERE TO GRIP the COMPONENTS of NEW BUG with 856 BASE ......44 HOW TO USE New BUG WITH BASE .................
-
Page 6: Warnings
- The manual reflects the technical state of the product at the time it was sold. ORMESA s.r.l. Reserves the right to make any changes to the product or manual suggested by experience, technical considerations or regulatory developments without any obligation to update its previous production and relevant manual. -
Page 7: Some Examples Of What Not To Do With
SOME EXAMPLES OF WHAT NOT TO DO WITH THE PRODUCT - DO NOT CARRY THE CHILD OVER ROUGH OR STEEP SURFACES OR STAIRS - DO ALLOW CHILDREN TO USE THE PRODUCT, EVEN FOR PLAYING - DO NOT REST EXCESSIVELY HOT CONTAINERS OR OBJECTS ON THE TRAY SURFACE BECAUSE THEY COULD TIP OVER AND BECAUSE THE WOOD OR COVERING COULD BE SEVERELY DAMAGED - NEVER LEAVE THE CHILD ALONE IN THE DEVICE... -
Page 8: Labels And Plates
LABELS AND PLATES Name of the model Series number Article number ® s.r.l. Via A. Da Sangallo, 1 06034 Foligno (PG) ITALY Tel. +39 074222927 Fax +39 074222637 M O D E L . P A R T N ° Max load MAX. -
Page 9: Base 869 Braking
BASE 869 BRAKING LOCKS UNLOCKS BASE 901 BRAKING LOCKS MANUAL BRAKE LEVER UNLOCKS 7/73... -
Page 10: Base 856 Braking
BASE 856 BRAKING LOCKS UNLOCKS 8/73... - Page 11 SEAT New BUG with 4-Wheel base 9/73...
-
Page 12: Technical Specifications Of New Bug With Base
TECHNICAL SPECIFICATIONS of New BUG with BASE HANDLE ADJUSTABLE 180° Stroller closed with seat removed Stroller closed with seat attached - WHEELS pneumatic: front, with direction locks, 17 cm; rear, with shock absorbers, 25 cm BRAKES independent parking brakes 10/73... - Page 13 Measures in inches and weights in pounds The numbers divided by the dash, specify a minimum and a maximum adjustment 11/73...
-
Page 14: Initial Preparation
INITIAL PREPARATION PACKAGING INFORMATION HOW TO REMOVE New BUG FROM THE BOX REMOVE THE SEAT FROM THE BOX AND THEN THE FRAME ATTENTION! CUT WITHOUT PRESSING TOO HARD WITH THE BLADE SO AS NOT TO DAMAGE THE CONTENTS OF THE HOW and WHERE TO GRIP the COMPONENTS of NEW BUG with 869 BASE 12/73... -
Page 15: Opening The Stroller
HOW TO USE New BUG WITH BASE OPENING the STROLLER a) WITHOUT THE SEAT A CLICK MEANS THAT THE FRAME IS OPEN PULL THE HANDLE CLOSING UPWARDS LOCK ATTENTION! ATTENTION! DO NOT PUT YOUR FINGER IN THE MAKE SURE THE CLOSING LOCK TO AVOID IT BEING FRAME IS LOCKED ACCIDENTALLY CRUSHED... -
Page 16: How To Hook The Seat To The Frame
HOW TO HOOK THE SEAT TO THE FRAME AFTER ENGAGING THE BRAKES, REST THE SEAT (THE POINT) ON THE TRAPEZOIDAL NOTCH (Fig. A) FIG. A VIEW FROM ABOVE THE FRAME TRAPEZOIDAL NOTCH GUIDE PUSH THE SEAT BACKWARDS SLIDING IT ON TO THE TRAPEZOIDAL NOTCH ENGAGE THE LOCKING LEVER. - Page 17 ATTENTION! DO NOT STICK YOUR FINGER BETWEEN THE LOCKING LEVER AND THE FRAME TO AVOID IT BEING ACCIDENTALLY CRUSHED ATTENTION! MAKE SURE THE SEAT IS IN THE TRAPEZOIDAL NOTCH BEFORE LOCKING IT WITH THE LEVER LOCKING LEVER SAFETY DEVICE SAFETY DEVICE LOCKING LEVER LOCKS UNLOCKS...
-
Page 18: How To Detach The Seat From The Frame
HOW TO DETACH THE SEAT FROM THE FRAME ATTENTION! FIRST ENGAGE THE BRAKES 1. LIFT THE SAFETY DEVICE 2. TURN THE LOCKING LEVER FROM LEFT TO RIGHT 3. SLIDE THE SEAT FORWARD ATTENTION! DO NOT STICK YOUR FINGER BETWEEN THE LOCKING LEVER AND THE FRAME TO AVOID IT VIEW FROM BEHIND BEING ACCIDENTALLY CRUSHED... -
Page 19: Closing The Base
CLOSING THE BASE ATTENTION! WE SUGGEST THAT YOU CLOSE THE BASE WITHOUT THE SEAT 1. PULL THE BLACK LOCKS WITH BOTH HANDS 2. SLOWLY ACCOMPANY THE HANDLE DOWNWARD 3. FRAME CLOSED 17/73... -
Page 20: Adjusting The Inclination Of The Seat (Tilting)
ADJUSTING THE INCLINATION OF THE SEAT (TILTING) 1 PULL THE TILTING KNOB 2 TILT THE SEAT KEEPING THE KNOB PULLED AND RELEASE IT WHEN TILTED TO THE DESIRED POSITION KNOB FOR ADJUSTING THE TILT VIEW FROM BEHIND 18/73... -
Page 21: Reclining The Backrest
RECLINING THE BACKREST PULL THE KNOB TO RECLINE THE BACKREST RECLINE THE BACKREST, KEEPING THE KNOB PULLED AND LET IT GO WHEN THE BACKREST HAS REACHED THE DESIRED POSITION KNOB FOR ADJUSTING THE BACKREST VIEW FROM BEHIND 19/73... -
Page 22: Adjusting The Height Of The Backrest
ADJUSTING THE HEIGHT OF THE BACKREST - LOOSEN THE TWO SCREWS LOCATED ON THE REAR OF THE BACKREST WITH THE WRENCH PROVIDED - SLIDE THE BACKREST TO THE DESIRED POSITION VIEW FROM BEHIND TIGHTEN THE SCREWS ADJUSTMENT SCREWS FOR NEW BUG SIZES 1, 2 AND 3 ADJUSTMENT SCREWS FOR NEW...
