Unitech MS912 Quick Reference Manual

Wireless scanner
Hide thumbs Also See for MS912:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual, Quick Manual

Package Contents

Please make sure the following contents are in the MS912 carton. If
something is missing or damaged, please contact your Unitech
representative.
MS912 scanner
Resource CD
USB Charging Cable
Hand Strap
Note:
1.
The scanner's default power off (idle mode) time is 3 minutes.
2.
Please charge scanner for at least 2 hours prior to initial use.
Unitech electronics co., ltd.
5F., No.135, Ln. 235, Baoqiao Rd., Xindian Dist., New Taipei City 231, Taiwan (R.O.C.)
Tel: + 886 2 89121122
Fax: +886 2 89121810
Quick Guide
Quick Connection Card
website: www.ute.com

Scanner Detail

Specifications

Light source
625nm visible red LED
Scan rate
240 scans/sec
Sensor
Linear CMOS sensor
Resolution
5mil/ 0.127mm
PCS
30%
Housing
Plastic (ABS)
Profile
SPP, HID
Working Hours
8 hours (1 scan/ 5 sec)
Charge Time
2 hours (fully charged)
Coverage
10M/33ft. (line of sight)
Operating Temp
0 to 50° C (32° F to 122° F)
Symbologies
All major 1D barcodes incl. GS1 Databar
MS912 Wireless Scanner
Quick Reference Guide
Version 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS912 and is the answer not in the manual?

Questions and answers

Related Manuals for Unitech MS912

Summary of Contents for Unitech MS912

  • Page 1: Package Contents

    MS912 Wireless Scanner Quick Reference Guide Package Contents Scanner Detail Please make sure the following contents are in the MS912 carton. If something is missing or damaged, please contact your Unitech representative. MS912 scanner Resource CD Quick Guide Specifications Light source...

  • Page 2: Getting Started

    MS912 Wireless Scanner Quick Reference Guide GETTING STARTED BEEPER INDICATION Single long beep Power up Single beep Good read The scanner reads a Code39 of ASCII in Single short beep configuration procedure. Two beeps Wireless connection The scanner successfully reads a Two short beeps configuration barcode.

  • Page 3: Pincode Setup

    MS912 Wireless Scanner Quick Reference Guide GETTING CONNECTED PINCODE SETUP There are two modes of wireless communication: Step 1 .E032$ .E042$ BT Mode – SPP Pincode Start 1. Press the trigger for 1 second to activate the scanner. Step 2 2.

  • Page 4: Numeric Bar Codes

    MS912 Wireless Scanner Quick Reference Guide NUMERIC BARCODES Version 1.0 Unitech electronics co., ltd. 5F., No.135, Ln. 235, Baoqiao Rd., Xindian Dist., New Taipei City 231, Taiwan (R.O.C.) Tel: + 886 2 89121122 Fax: +886 2 89121810 website: www.ute.com...

  • Page 5: Smartphone Connection - Android

    MS912 Wireless Scanner Quick Reference Guide SMARTPHONE CONNECTION - iOS (Apple) SMARTPHONE CONNECTION - Android Getting Connected Getting Connected To get connected to Android, please follow the instructionin [BT Please pair with the scanner via [BT mode - HID]. mode - SPP].

  • Page 6: Power Off Timeout

    MS912 Wireless Scanner Quick Reference Guide POWER OFF TIMEOUT LINK QUALITY The timeout is before automatic power-off to save power. .B017$ .E035$ 1 MIN ENABLE .B018$ .E036$ 3 MIN DISABLE .B019$ Link Quality (enabled by default) ensures a more secure data transmission from the scanner to the cradle/host.

  • Page 7: General Settings

    MS912 Wireless Scanner Quick Reference Guide GENERAL SETTINGS READING MODE .A001$ .F002$ TRIGGER DEFAULT .F003$ .P023$ TOGGLE RESET .F001$ .A007$ FLASH CHECK VERSION .F005$ CONTINUOUS BEEPER .F012$ .F006$ CONTINUOUS AUTO BEEP OFF .F018$ BEEP ON Version 1.0 Unitech electronics co., ltd.

  • Page 8: Keyboard Layout

    MS912 Wireless Scanner Quick Reference Guide KEYBOARD LAYOUT . C009$ .C010$ ENGLISH JAPAN (106 key) (USA) . C018$ . C025$ ENGLISH CANADIAN (UK) (FRENCH) . C012$ . C034$ CANADIAN FRENCH (TRADITIONAL) . C029$ . C011$ GERMAN NORWEGIAN . C014$ . C026$...
  • Page 9 MS912 Wireless Scanner Quick Reference Guide KEYBOARD LAYOUT . C030$ . C017$ BELGIAN CZECH (AZERTY) (QWERTY) . C028$ . C022$ CZECH DUTCH (QWERTZ) . C027$ . C021$ HUNGARIAN DANISH (QWERTZ) . C032$ . C024$ HUNGARIAN SLOVAK (101 KEY) . C016$ .
  • Page 10 MS912 Wireless Scanner Quick Reference Guide ENABLE SYMBOLOGIES . A002$ . G010$ ENABLE CODE 93 ALL CODE . K010$ . N017$ IATA CODE 32 . L014$ . L010$ TELEPEN UK PLESSEY . N032$ . L001$ GS1 DATABAR . N010$ . N001$...
  • Page 11 MS912 Wireless Scanner Quick Reference Guide TERMINATOR . D012$ The following pages only apply to the memory version mini wireless scanner. The firmware version with suffix “MEM” supports memory function. e.g. SM3-c-X.XX.BTA.MEM . D011$ The firmware version can be found either on the scanner box or by scanning below barcode.

  • Page 12: Memory Mode

    MS912 Wireless Scanner Quick Reference Guide MEMORY MODE OUTPUT DATA For memory version only For memory version only . R001$ . R003$ OUTPUT DATA ENABLE MEMORY . R002$ Data Output Method . R014$ DISABLE MEMORY WIRELESS Once enabled, the scanner will stop sending data via Bluetooth .

  • Page 13: Data Format

    MS912 Wireless Scanner Quick Reference Guide DATA FORMAT DATE & TIME SETUP . R011$ . R006$ SET DATE DATA FORMAT Example: To set Date to 2012-08-01 (Year-Month-Day): The default Data Format is <Item No.>, <Date>, <Time>, <Barcode 1. Scan [Set Date] Data>...

  • Page 14: Date Format

    MS912 Wireless Scanner Quick Reference Guide DATE FORMAT TIME FORMAT . R008$ . R009$ TIME FORMAT DATE FORMAT The default Date Format is DD/MM/YYYY (Code = 09), below is full The default Time Format is HH:MM:SS (Code = 01), below are...
