- Page 1 Item no. 2201 Elite 400W DC to AC Pure Sine Inverter User’s Manual...
- Page 2 Elite 400W Pure Sine Inverter by Wagan Tech Introduction Thank you for purchasing this Wagan Tech 400 Watt Pure Sine Wave DC to AC Power Inverter. It delivers a true sine wave AC identical to that of commercial power. Use this inverter to power AC appliances in your vehicle. Pure Sine Wave AC means that your sensitive electronics such as audio/video systems, computers and communications equipment will operate properly.
-
Page 3: General Instructions
400 watts. WARNING INVERTER OUTPUT CAN BE LETHAL. IMPROPER USE OF THIS INVERTER MAY RESULT IN PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. ©2010 Wagan Corporation All Rights Reserved Wagan and wagan.com are trademarks used by Wagan Corporation... -
Page 4: Front Panel
Elite 400W Pure Sine Inverter by Wagan Tech Front Panel • ON/OFF Switch — This switch controls AC output of the inverter. • Operating LED (Green) — When this green LED is lit, the inverter is operating normally. • FAULT LED (Red) — This indicator turns RED as the inverter shuts down because of: Excessive Temperature, Overload, Under Voltage or Over voltage. -
Page 5: Rear Panel
Negative Stud Terminal — Negative (−) DC Input (Black) • Cooling Fan — High-speed and load controlled Cooling Fan Positive (+) Red Stud Terminal Negative (−) Black Stud Terminal ©2010 Wagan Corporation All Rights Reserved Wagan and wagan.com are trademarks used by Wagan Corporation... -
Page 6: Load Considerations
Elite 400W Pure Sine Inverter by Wagan Tech Load Considerations The startup load of an appliance is a major factor of whether this inverter can power it. Startup load is momentary. With many appliances, it is approximately twice the continuous load, but some appliance startup loads can be as high as eight times the continuous load. -
Page 7: Connecting The Inverter
5. While the Inverter is not in use, place the inverter’s ON/OFF Power Switch to the OFF position and, optionally, unplug the DC Adapter cable from the vehicle’s DC outlet. ©2010 Wagan Corporation All Rights Reserved Wagan and wagan.com are trademarks used by Wagan Corporation... - Page 8 Elite 400W Pure Sine Inverter by Wagan Tech Battery Clip Adapter Cord – Up to 400 Watts Output 1. Connect just the red spade terminal of the supplied DC Battery Clip Adapter Cord to the red stud terminal (+) on the rear of the inverter.
- Page 9 Isolate the television, its power cord and antenna cables from the 12 volt power source by running an extension cord from the inverter to the television set. ©2010 Wagan Corporation All Rights Reserved Wagan and wagan.com are trademarks used by Wagan Corporation...
-
Page 10: Troubleshooting
Elite 400W Pure Sine Inverter by Wagan Tech Troubleshooting PROBLEM: Low or No Output Voltage – Fault LED Lit Reason Solution Poor contact with battery, inverter Clean terminals thoroughly. Reinstall terminals or DC socket. and tighten. Clean DC socket with non- metallic abrasive emery stick. -
Page 11: Disposal/Recycling Of Inverter
Disposal/Recycling of Inverter Electronic products are known to contain materials that are toxic if improperly disposed. Contact local authorities for disposal and recycling information. ©2010 Wagan Corporation All Rights Reserved Wagan and wagan.com are trademarks used by Wagan Corporation... -
Page 12: Specifications
Elite 400W Pure Sine Inverter by Wagan Tech Specifications • Output Waveform: True Sine Waveform • Input: 10–15V DC • Output: 120V AC • Continuous Power: 400 watts • Peak Surge: 800 watts Efficiency: > 90% • • Frequency: 60Hz Total Harmonic Distortion (THD): <... - Page 15 In no event will WAGAN Corporation be responsible for any amount of damages beyond the amount paid for the product at retail. In the event of a defective item, please contact WAGAN Corporation at (800) 231-5806 to obtain a Returned Merchandise Authorization number (RMA#), and return instructions.
- Page 16 USA & CAN Toll Free: 1.800.231.5806 1.510.471.9221 31088 San Clemente Street Hayward, CA 94544 U.S.A. ©2010 Wagan Corporation All Rights Reserved Wagan and wagan.com are trademarks used by Wagan Corporation Mar 2010...
