9.3 BEFORE STARTING THE INTERCOM

Your SRC‑System™ headset has two buttons designated for quick con-
nection to two other headsets. These other headsets are referred to as
CHANNeL "A" and CHANNeL "B".
Channel "A" Button
Before you can begin using the intercom for Bike-to-Bike communi-
cation with one or two other headsets, all units must first be paired.
9.4 USING THE SRC-SYSTEM™ FOR INTERCOM WITH OTHER
SRC-SYSTEM™ HEADSETS
INteRCOm PAIRING / CONNeCtION
CHANNeL BUttON
CHANNEL "A" CHANNEL "A" BUTTON
CHANNEL "B" CHANNEL "B" BUTTON
9.4a. tWO‑WAy INteRCOm PAIRING OPtIONS BetWeeN tWO
PARtICIPANtS
Using two SRC‑System™ headsets
1.while both headsets are turned OFF, turn them ON by pressing and
holding the Mobile Buttons until the Blue Lights flash three times.
2. Make sure that both headsets are now flashing slowly in Blue.
3. Choose an available CHANNEL you wish to use to pair the headset
(CHANNEL "A" or CHANNEL "B").
QG SRC 207 - MAN00015 indd 33
Channel "B" Button
PAIRING mODe LeD
INDICAtORS
Rapid RED flashing
Rapid BLUE flashing
NOTe: Selecting a CHANNeL that is already in use will override the paired
headset on that CHANNeL with the newly paired headset.
4. On the SRC‑System™ headset, press and hold the assigned
CHANNEL BUTTON ("A" or "B") for at least six seconds until the
headset's BLUE or RED Light begins flashing rapidly, indicating it is
in Intercom Pairing mode. (See Intercom Channel Table for Pairing
LED indication for each CHANNEL).
5. Repeat Step 3-4 for the second SRC‑System™.
6. within a few seconds, both headsets will show a solid light for two
seconds, indicating that the two headsets are now paired, con-
nected and ready for use.
NOTe: If the Pairing process is not completed within two minutes the
headset will return to Standby mode.
Initiate Intercom calls
There are two ways to start an Intercom call with your paired headset
while the headset is in Standby mode:
VOICe CONNeCt:
Start talking loudly
Once you start talking loudly, an Intercom call will
be established with the other paired headset.
The Intercom call will stay on until all participants
remain silent for 30 seconds.
9.4b. tHRee‑WAy INteRCOm
The SRC‑System™ offers three-way intercom conference connectiv-
ity as follows:
CHANNeL BUttON
CONNeCt:
tap the chosen
CHANNeL Button once
to add or remove the
other headset from an
Intercom call.
33
