HISTORY INFORMATION FOR THE FOLLOWING MANUAL:

SERVICE MANUAL

MODEL NAME
KDL-40XBR9
KDL-40XBR9
KDL-46XBR9
KDL-46XBR9
KDL-52XBR9
KDL-52XBR9
ORIGINAL MANUAL ISSUE DATE: 4/2009
: UPDATED ITEM
REVISION DATE
4/2009
5/2009
9/2009
9-883-821-03
REMOTE COMMANDER
RM-YD029
RM-YD029
RM-YD029
RM-YD029
RM-YD029
RM-YD029
SUBJECT
No revisions or updates are applicable at this time.
Added section 2-4. Setting the Destination After Replacing the BU Board. Replaced page 43.
Corrected BU Board Part Numbers for Mexico and Latin America models. Replaced page 82 & 87.
Updated Exploded View Section to remove LCD Panel specifi c information. Replaced page 85.
EX2M
DESTINATION
US/CND
MX/LATIN AMERICA
US/CND
MX/LATIN AMERICA
US/CND
MX/LATIN AMERICA
LCD DIGITAL COLOR TELEVISION
CHASSIS

Advertisement

Table of Contents
loading

Related Manuals for Sony KDL-40XBR9

Summary of Contents for Sony KDL-40XBR9

  • Page 1: Service Manual

    HISTORY INFORMATION FOR THE FOLLOWING MANUAL: EX2M SERVICE MANUAL CHASSIS MODEL NAME REMOTE COMMANDER DESTINATION KDL-40XBR9 RM-YD029 US/CND KDL-40XBR9 RM-YD029 MX/LATIN AMERICA KDL-46XBR9 RM-YD029 US/CND KDL-46XBR9 RM-YD029 MX/LATIN AMERICA KDL-52XBR9 RM-YD029 US/CND KDL-52XBR9 RM-YD029 MX/LATIN AMERICA ORIGINAL MANUAL ISSUE DATE: 4/2009...
  • Page 2 Self Diagnosis Supported model EX2M SERVICE MANUAL CHASSIS MODEL NAME REMOTE COMMANDER DESTINATION KDL-40XBR9 RM-YD029 US/CND KDL-40XBR9 RM-YD029 MX/LATIN AMERICA KDL-46XBR9 RM-YD029 US/CND KDL-46XBR9 RM-YD029 MX/LATIN AMERICA KDL-52XBR9 RM-YD029 US/CND KDL-52XBR9 RM-YD029 MX/LATIN AMERICA DISPLAY LIGHT POWER TV POWER FUNCTION...

  • Page 3: Table Of Contents

    1-7-1. Cleaning the LCD Panel ..........21 D4N Board Schematic Diagram (KDL-52XBR9 Only) ..70 WIRE DRESSING ................ 22 G6N Board Schematic Diagram (1 of 2) (KDL-40XBR9 Only) ..........73 KDL-40XBR9 Only ............... 22 G6N Board Schematic Diagram (2 of 2) KDL-46XBR9 Only ............... 28 (KDL-40XBR9 Only) ..........

  • Page 4: Specifi Cations

    HDMI: Video: 480i, 480p, 720p, 1080i,1080p, 1080/24p Power Consumption (W) Audio: Two channel linear PCM 32, 44.1 and In Use (Max) 205W (KDL-40XBR9 Only) 48 kHz, 240W (KDL-46XBR9 Only) 16, 20 and 24 bits, Dolby Digital 300W (KDL-52XBR9 Only) AUDIO (for HDMI IN 1 Only): In Standby Less than 0.1W with 120 V AC...
  • Page 5 Terrestrial Quick Setup Guide 1-135 Cable Warranty Card Digital Safety and Regulatory Booklet 2-69 Terrestrial Attaching the Table-Top Stand (KDL-40XBR9/46XBR9 Only) 1-135 Cable Screws (4) (KDL-40XBR9/46XBR9 Only) Antenna Optional Accessories 75-ohm external terminal for RF inputs Connecting Cables Panel System...

  • Page 6: Warnings And Cautions - English

    Components identifi ed by shading and ! mark on the schematic diagrams, exploded views, and in the parts list are critical for safe operation. Replace these components with Sony parts whose part numbers appear as shown in this manual or in supplements published by Sony. Circuit adjustments that are critical for safe operation are identifi...

  • Page 7: Warnings And Cautions - French

    Les composants identifi es par une trame et par une marque ! sur les schemas de principe, les vues explosees et les listes de pieces sont d’une importance critique pour la securite du fonctionnement. Ne les remplacer que par des composants Sony dont le numero de piece est indique dans le present manuel ou dans des supplements publies par Sony.

  • Page 8: Safety-Related Component Warning

    KDL-40XBR9/46XBR9/52XBR9 SAFETY-RELATED COMPONENT WARNING There are critical components used in LCD color TVs that are important for safety. These components are identifi ed with shading and mark on the schematic diagrams and the electrical parts list. It is essential that these critical parts be replaced only with the part number specifi...
  • Page 9 Due to the higher melting point of Lead Free Solder the soldering iron tip temperature needs to be set to 370 degrees centigrade. This requires soldering equipment capable of accurate temperature control coupled with a good heat recovery characteristics. For more information on the use of Lead Free Solder, please refer to http://www.sony-training.com KDL-40XBR9/46XBR9/52XBR9...

  • Page 10: Safety Check-Out

    KDL-40XBR9/46XBR9/52XBR9 SAFETY CHECK-OUT The AC leakage from any exposed metal part to earth ground and After correcting the original service problem, perform the following from all exposed metal parts to any exposed metal part having a safety checks before releasing the set to the customer: return to chassis, must not exceed 0.5 mA (500 microamperes).

  • Page 11: Self-Diagnostic Function

    KDL-40XBR9/46XBR9/52XBR9 Self Diagnosis SELF-DIAGNOSTIC FUNCTION Supported model The units in this manual contain a self-diagnostic function. If an error occurs, the POWER/STANDBY LED indicator will automatically begin to fl ash. The number of times the LED fl ashes translates to a probable source of the problem. A defi nition of the POWER/STANDBY LED fl ash indicators is listed in the instruction manual for the user’s knowledge and reference.
  • Page 12 KDL-40XBR9/46XBR9/52XBR9 POWER/STANDBY LED Diagnostic Description Number of times Diagnostic Item POWER/STANDBY LED Possible Location Description lamp flashes Main Power 2 times G6N Board (40") G7N Board (46" & 52") Board BU Board DC Alert1 3 times G6N Board (40") G7N Board (46" & 52") Board...

  • Page 13: Section 1: Disassembly

    KDL-40XBR9/46XBR9/52XBR9 SECTION 1: DISASSEMBLY 1-1. REAR COVER REMOVAL 1-1-1. KDL-40/46XBR9 REAR COVER REMOVAL Remove 8 screws from Rear Cover Remove 1 screw from Side Jack position Remove 1 screw from Terminal position Remove 4 screws near the VESA positions Remove 3 screws from Bottom Frame positions...

  • Page 14: Kdl-52Xbr9 Rear Cover Removal

    KDL-40XBR9/46XBR9/52XBR9 1-1-2. KDL-52XBR9 REAR COVER REMOVAL Remove 14 screws from Rear Cover Remove 1 screw from Side Jack position Remove 1 screw from Terminal position Remove 4 screws near the VESA positions Remove 4 screws from Bottom Frame positions Carefully lift the Rear Cover bottom side up and rotate toward top side...

  • Page 15: Switch Unit Removal

    KDL-40XBR9/46XBR9/52XBR9 1-2. SWITCH UNIT REMOVAL Push Point A as shown and rotate Switch Unit clockwise to release the hook from Front Cabinet Assembly. Push Point B as shown and rotate Switch Unit counterclockwise to release the hook from Front Cabinet Assembly.

  • Page 16: Bu Board, Inverter Board (D1N Board, D2N Board, D3N Board, Or D4N Board), And Power Board (G6N Board Or G7N Board) Removal

    Disconnect 7 connectors from G7N Board (KDL-46/52XBR9 ONLY) Remove 2 screws from G7N Board (KDL-46/52XBR9 ONLY) Disconnect 7 connectors from G6N Board (KDL-40XBR9 ONLY) Remove 4 screws from G6N Board (KDL-40XBR9 ONLY) 10 Disconnect 4 connectors from D1N Board (KDL-40/46XBR9 ONLY)

  • Page 17: Table-Top Stand Assembly And Under Cover Removal

    KDL-40XBR9/46XBR9/52XBR9 1-4. TABLE-TOP STAND ASSEMBLY AND UNDER COVER REMOVAL Gently lay LCD panel on a soft cloth. Remove 4 screws from Table-Top Stand Assembly Remove 2 screws from Under Cover from Bottom Frame 2 Screw, +PSW M5X16 Table-Top Screw, Stand Assembly...

  • Page 18: Structural Parts And Ac Inlet Removal

    KDL-40XBR9/46XBR9/52XBR9 1-5. STRUCTURAL PARTS AND AC INLET REMOVAL Release embossed indentation from LCD Panel hole (KDL-40/46XBR9 ONLY) Push and slide Top Stay out from Front Cabinet Assembly (KDL-40/46XBR9 ONLY) Rotate VESA Brackets to counter clockwise and remove from Front Cabinet Assembly...

  • Page 19: Loudspeakers And Tweeters Removal

    KDL-40XBR9/46XBR9/52XBR9 1-6. LOUDSPEAKERS AND TWEETERS REMOVAL Remove 1 screw from Tweeter Slide out both Speaker Boxes from Front Cabinet Assembly Remove 1 screw from Tweeter Screw, +PSW M3X8 Soft Cloth 3 Screw, +PSW M3X8 KDL-40XBR9/46XBR9/52XBR9...

  • Page 20: Lcd Panel, Illumination Module, Hl5 Board, And Heat Sink Removal

    1-7. LCD PANEL, ILLUMINATION MODULE, HL5 BOARD, AND HEAT SINK REMOVAL Remove Flexible Flat (LVDS) cable and connector assemblies from the LCD panel Remove 3 screws and release LCD panel from Front Cabinet Assembly (KDL-40XBR9 ONLY) Remove 5 screws and release LCD panel from Front Cabinet Assembly (KDL-46XBR9 ONLY)

  • Page 21: Cleaning The Lcd Panel

    KDL-40XBR9/46XBR9/52XBR9 1-7-1. CLEANING THE LCD PANEL CAUTION: When cleaning the TV, be sure to unplug the power cord to avoid any chance of electric shock. Clean the cabinet of the TV with a dry soft cloth. Wipe the LCD screen gently with a soft cloth.

  • Page 22: Wire Dressing

    KDL-40XBR9/46XBR9/52XBR9 WIRE DRESSING KDL-40XBR9 ONLY OVERALL VIEW KDL-40XBR9/46XBR9/52XBR9...
  • Page 23 KDL-40XBR9/46XBR9/52XBR9 KDL-40XBR9 ONLY G6N BOARD TO D1N BOARD ) ” ) ” KDL-40XBR9/46XBR9/52XBR9...
  • Page 24 KDL-40XBR9/46XBR9/52XBR9 KDL-40XBR9 ONLY G6N BOARD TO D1N BOARD (CONTINUED) ) ” ) ” KDL-40XBR9/46XBR9/52XBR9...
  • Page 25 KDL-40XBR9/46XBR9/52XBR9 KDL-40XBR9 ONLY D2N BOARD CONNECTOR ) ” KDL-40XBR9/46XBR9/52XBR9...
  • Page 26 KDL-40XBR9/46XBR9/52XBR9 KDL-40XBR9 ONLY D1N BOARD TO D2N BOARD ” ) ” ” ) ” I I - KDL-40XBR9/46XBR9/52XBR9...
  • Page 27 KDL-40XBR9/46XBR9/52XBR9 KDL-40XBR9 ONLY D1N BOARD TO D2N BOARD (CONTINUED) ” ) ” ” ) ” I I - KDL-40XBR9/46XBR9/52XBR9...

  • Page 28: Kdl-46Xbr9 Only

    KDL-40XBR9/46XBR9/52XBR9 KDL-46XBR9 ONLY OVERALL VIEW KDL-40XBR9/46XBR9/52XBR9...
  • Page 29 KDL-40XBR9/46XBR9/52XBR9 KDL-46XBR9 ONLY G7N BOARD TO D1N BOARD ) ” ) ” KDL-40XBR9/46XBR9/52XBR9...
  • Page 30 KDL-40XBR9/46XBR9/52XBR9 KDL-46XBR9 ONLY G7N BOARD TO D1N BOARD (CONTINUED) ) ” ) ” KDL-40XBR9/46XBR9/52XBR9...
  • Page 31 KDL-40XBR9/46XBR9/52XBR9 KDL-46XBR9 ONLY D2N BOARD CONNECTOR ) ” KDL-40XBR9/46XBR9/52XBR9...
  • Page 32 KDL-40XBR9/46XBR9/52XBR9 KDL-46XBR9 ONLY D1N BOARD TO D2N BOARD ” 0 ) ” ” ) ” I I - KDL-40XBR9/46XBR9/52XBR9...
  • Page 33 KDL-40XBR9/46XBR9/52XBR9 KDL-46XBR9 ONLY D1N BOARD TO D2N BOARD (CONTINUED) ” ) ” ” ) ” I I - KDL-40XBR9/46XBR9/52XBR9...
  • Page 34 KDL-40XBR9/46XBR9/52XBR9 KDL-46XBR9 ONLY LVDS CONNECTOR INSTALLATION s ’ KDL-40XBR9/46XBR9/52XBR9...

  • Page 35: Kdl-52Xbr9 Only

    KDL-40XBR9/46XBR9/52XBR9 KDL-52XBR9 ONLY OVERALL VIEW KDL-40XBR9/46XBR9/52XBR9...
  • Page 36 KDL-40XBR9/46XBR9/52XBR9 KDL-52XBR9 ONLY G7N BOARD TO D3N BOARD ) ” ) ” KDL-40XBR9/46XBR9/52XBR9...
  • Page 37 KDL-40XBR9/46XBR9/52XBR9 KDL-52XBR9 ONLY G7N BOARD TO D3N BOARD (CONTINUED) ) ” ) ” KDL-40XBR9/46XBR9/52XBR9...
  • Page 38 KDL-40XBR9/46XBR9/52XBR9 KDL-52XBR9 ONLY D4N BOARD CONNECTOR ) ” KDL-40XBR9/46XBR9/52XBR9...
  • Page 39 KDL-40XBR9/46XBR9/52XBR9 KDL-52XBR9 ONLY D3N BOARD TO D4N BOARD ) ” ) ” I I - KDL-40XBR9/46XBR9/52XBR9...
  • Page 40 KDL-40XBR9/46XBR9/52XBR9 KDL-52XBR9 ONLY LVDS CONNECTOR INSTALLATION ) ” ) ” I I - KDL-40XBR9/46XBR9/52XBR9...
  • Page 41 KDL-40XBR9/46XBR9/52XBR9 KDL-52XBR9 ONLY s ’ KDL-40XBR9/46XBR9/52XBR9...

  • Page 42: Section 2: Service Adjustments

    KDL-40XBR9/46XBR9/52XBR9 SECTION 2: SERVICE ADJUSTMENTS 2-1. VIEWING SERVICE ADJUSTMENT DATA SERVICE There are no adjustments necessary for these models. All data has INFO been set for optimal viewing for our customers. The following sections SOFTWARE VERSION are for informational purposes only.

  • Page 43: Setting The Destination After Replacing The Bu Board

    KDL-40XBR9/46XBR9/52XBR9 4. To write the data press MUTE, and then press Channel 0 . 2-4. SETTING THE DESTINATION AFTER REPLACING THE BU BOARD WRITE MODEL By default, the data value set for the Destination information on the DESTINATION replacement BU Board is set to 3 for US and Canada models. To...

  • Page 44: Section 3: Diagrams

    KDL-40XBR9/46XBR9/52XBR9 SECTION 3: DIAGRAMS 3-1. CIRCUIT BOARDS LOCATION 3-2. PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS INFORMATION All capacitors are in μF unless otherwise noted. pF : μμF 50WV or All voltages are in V. less are not indicated except for electrolytics and tantalums.
  • Page 45 KDL-40XBR9/46XBR9/52XBR9 REFERENCE INFORMATION Terminal name of semiconductors in silk screen RESISTOR CAPACITOR : RN METAL FILM : TA TANTALUM printed circuit ( : RC SOLID : PS STYROL Circuit Device Printed symbol Terminal name : FPRD NONFLAMMABLE CARBON : PP...

  • Page 46: Block Diagram

    KDL-40XBR9/46XBR9/52XBR9 3-3. BLOCK DIAGRAM -USB11_EN -USB11_OVRCUR -X_SUSPEND x255 x255 USB1.1 FS "OCR" & "EN" USB2.0 HS2 USB HS GDDR2 GDDR2 -1000 -1000 ULPI CH .A 64MB 64MB USB2.0 HS1 GDDR2 GDDR2 -1000 -1000 RMII CH .B Ethenet PHY 64MB 64MB -FAN_DRV I2C.

  • Page 47: Video And Signal Flow Diagram

    KDL-40XBR9/46XBR9/52XBR9 3-4. VIDEO AND SIGNAL FLOW DIAGRAM USB2.0 Video2 Audio In.1 USB2.0 Speaker PWM. 3 x255 L/R Out ULPI PWM. 1 Seiji PWM x3 In.5 Ethernet RMII S.Woofer PWM. 2 Video1 Audio DSP In.3 In. IF0 D-IF Tuner Video3 In.4 Opt.

  • Page 48: Schematics And Supporting Information

    KDL-40XBR9/46XBR9/52XBR9 3-5. SCHEMATICS AND SUPPORTING INFORMATION BU BOARD SCHEMATIC DIAGRAM (1 OF 11) — A_V1_IN_Y R1016 D3.3V CN1000 1/10W VD1006 RN-CP A_LINEOUT 0.5% SPDIF_OUT A_V1_IN_C C1038 — R1038 0 . 1 D3.3V 1/10W RN-CP 1005 Opt Output VD1016 A_V1_IN_SSW RB1007...

  • Page 49: Bu Board Schematic Diagram (2 Of 11)

    KDL-40XBR9/46XBR9/52XBR9 BU BOARD SCHEMATIC DIAGRAM (2 OF 11) SDOUT1 TAS_AD33 — D3.3V F2001 1.6A FB2009 C2008 — CL2009 AUDIO_13V SPDIF_IN SPDIF_OUT PWM3_RI AU_13V FE_I2S CL2010 PWM3_RD RB2002 FE_I2S_DATA3 PWM3_LI FE_I2S_DATA2 — PWM3_LD FE_I2S_DATA1 C2023 F2201 C2021 0 . 1 0 . 1...

  • Page 50: Bu Board Schematic Diagram (3 Of 11)

    KDL-40XBR9/46XBR9/52XBR9 BU BOARD SCHEMATIC DIAGRAM (3 OF 11) r e s e r v e d R3029 r e s e r v e d — 1/16W CHIP r e s e r v e d RESET r e s e r v e d...

  • Page 51: Bu Board Schematic Diagram (4 Of 11)

    KDL-40XBR9/46XBR9/52XBR9 BU BOARD SCHEMATIC DIAGRAM (4 OF 11) CN5101 PC-R CL5107 PC_R 011:4D R5102 PC-G HDMI_2 CL5108 PC_G 011:4C PC-B R5103 — CL5109 PC_B 011:4E R5104 R5105 R5107 R5110 F5101 0.5A 1/10W 1/10W 1/10W RN-CP RN-CP RN-CP D1.8V CL5102 0.5% 0.5%...

  • Page 52: Bu Board Schematic Diagram (5 Of 11)

    KDL-40XBR9/46XBR9/52XBR9 BU BOARD SCHEMATIC DIAGRAM (5 OF 11) — R7049 4 . 7 k C7040 1/16W 100p RN-CP R7037 R7041 0.5% 1/16W 1/16W RN-CP RN-CP 0.5% 0.5% CL7000 — REG12V R7050 R7055 R7061 100k 1/16W 1/16W 1/16W CHIP RN-CP CHIP 0.5%...

  • Page 53: Bu Board Schematic Diagram (6 Of 11)

    KDL-40XBR9/46XBR9/52XBR9 BU BOARD SCHEMATIC DIAGRAM (6 OF 11) — D1.05V D3.3V_A1VDD D3.3V FL7204 AA10 AA12 AD12 VDDC VDDR3 C7200 C7211 C7222 C7231 C7210 C7255 C7256 C7257 C7241 C7254 AA11 AA22 AD14 VDDC VDDR3 6.3V 6.3V 6.3V 6.3V 6.3V C7216 6.3V 6.3V...

  • Page 54: Bu Board Schematic Diagram (7 Of 11)

    KDL-40XBR9/46XBR9/52XBR9 BU BOARD SCHEMATIC DIAGRAM (7 OF 11) — MEMA_A0 MEMA_DQ15 MEMA_A0 MEMA_DQ20 MEMA_A1 MEMA_DQ12 MEMA_A1 MEMA_DQ23 MEMA_A2 MEMA_DQ9 MEMA_A2 MEMA_DQ19 MEMA_A3 MEMA_DQ10 MEMA_A3 MEMA_DQ17 MEMA_A4 MEMA_DQ8 MEMA_A4 MEMA_DQ16 MEMA_A5 MEMA_DQ13 MEMA_A5 MEMA_DQ18 MEMA_A6 MEMA_DQ11 MEMA_A6 MEMA_DQ22 D1.8V DDR2_1.8V —...

  • Page 55: Bu Board Schematic Diagram (8 Of 11)

    KDL-40XBR9/46XBR9/52XBR9 BU BOARD SCHEMATIC DIAGRAM (8 OF 11) — CL7419 CL7420 D1.8V R7450 1/16W CHIP R7451 1/16W RB7402 CHIP FAD1 — FAD(0) FAD6 C7473 0 . 1 D3.3V FAD(1) FAD0 1005 JL7466 FAD(2) FAD7 FAD(3) FAD14 FAD9 ADQ9 R7452 FAD(4)

  • Page 56: Bu Board Schematic Diagram (9 Of 11)

    KDL-40XBR9/46XBR9/52XBR9 BU BOARD SCHEMATIC DIAGRAM (9 OF 11) R7582 USB1.1 PORTA 1/16W CHIP JL7525 AL12 USB1.1OCP C7577 USB11_VBUSA USB_OVRCURb 100p USB11_NA JL7526 — 1005 JL7523 AM12 USB1.1PA USN11_PA USBPA USB1.1NA USB11_GNDA JL7524 AN12 USBNA AM11 USB1.1PB USBPB AN11 USB1.1NB USBNB...

  • Page 57: Bu Board Schematic Diagram (10 Of 11)

    KDL-40XBR9/46XBR9/52XBR9 BU BOARD SCHEMATIC DIAGRAM (10 OF 11) — C7655 C7650 1005 L7601 C7637 0.27uH 0 . 1 1005 C7653 1005 CL7603 1005 R7613 AM27 VI_IFP0 1/16W — CHIP AN27 CL7604 VI_IFM0 C7654 C7638 0 . 1 L7602 0.27uH AN18...

  • Page 58: Bu Board Schematic Diagram (11 Of 11)

    KDL-40XBR9/46XBR9/52XBR9 BU BOARD SCHEMATIC DIAGRAM (11 OF 11) — RX_POWER5V HDMI0_5V — OUT_DDC_CLK DDC0_SCL OUT_DDC_DAT DDC0_SDA TMDS_RX0+ HDMI0_D0P TMDS_RX0- HDMI0_D0N DVOCLK0 TMDS_RX1+ HDMI0_D1P DVOCLK1 TMDS_RX1- HDMI0_D1N DVOLB(0) TMDS_RX2+ HDMI0_D2P DVOLB(1) — TMDS_RX2- HDMI0_D2N DVOLB(2) TMDS_CLK+ HDMI0_CLKP DVOLB(3) TMDS_CLK- HDMI0_CLKN DVOLB(4)
  • Page 59 KDL-40XBR9/46XBR9/52XBR9 [I/O, AUDIO, MIMAS, HDMI/PC, POWER SUPPLY, X255 POWER, GND, PWR DECOUPLING, XTAL, PLL, RESET, PERIPHERAL, X255 DDR2, X255 SERIAL FLASH, NVM, FLEXBUS, ONENAND, BOOT STRAPS, X255 DVI, ANALOG VIDEO, AUDIO I2S IF, USB1.1, USB 2.0, ETHERNET, X255 FRONTEND, GPIO, ADC, X255 LVDS, PANEL IF] COMPONENT SIDE —...
  • Page 60 KDL-40XBR9/46XBR9/52XBR9 [I/O, AUDIO, MIMAS, HDMI/PC, POWER SUPPLY, X255 POWER, GND, PWR DECOUPLING, XTAL, PLL, RESET, PERIPHERAL, X255 DDR2, X255 SERIAL FLASH, NVM, FLEXBUS, ONENAND, BOOT STRAPS, X255 DVI, ANALOG VIDEO, AUDIO I2S IF, USB1.1, USB 2.0, ETHERNET, X255 FRONTEND, GPIO, ADC, X255 LVDS, PANEL IF]...

  • Page 61: D1N Board Schematic Diagram (Kdl-40/46Xbr9 Only)

    KDL-40XBR9/46XBR9/52XBR9 D1N BOARD SCHEMATIC DIAGRAM (KDL-40/46XBR9 ONLY) 40" ONLY *JW6601 L6600 68uH JL6600 CN6600 EY6602 C6607 R6636 *R6603 0 . 4 7 — PFC_OUT(395V) 450V C6600 1/4W FPRD TO G-Board PRI_GND 450V JL6603 JL6611 JL6616 CN6501 46" ONLY EY6603 PRI_VCC(12V)
  • Page 62 KDL-40XBR9/46XBR9/52XBR9 [INVERTER] COMPONENT SIDE (KDL-40/46XBR9 ONLY) R V 6 7 5 1 1 - 8 7 8 - 6 2 0 - 1 2 F r e q F B 6 6 1 3 E Y 6 6 5 7 —...
  • Page 63 KDL-40XBR9/46XBR9/52XBR9 [INVERTER] CONDUCTOR SIDE (KDL-40/46XBR9 ONLY) 1 - 8 7 8 - 6 2 1 - 1 2 cam16 E P G W L P ( 1 7 3 0 4 5 5 1 2 ) E T 6 9 0 4...

  • Page 64: D2N Board Schematic Diagram (Kdl-40/46Xbr9 Only)

    KDL-40XBR9/46XBR9/52XBR9 D2N BOARD SCHEMATIC DIAGRAM (KDL-40/46XBR9 ONLY) 40" ONLY *JW6801 L6800 68uH JL6800 CN6800 C6807 *R6803 EY6802 0 . 4 7 R6836 — 450V PFC_OUT C6800 46" ONLY 1/4W FPRD TO G-Board 450V JL6803 JL6811 JL6816 PRI_GND CN6502 EY6803 PRI_VCC(12V)
  • Page 65 KDL-40XBR9/46XBR9/52XBR9 [INVERTER] COMPONENT SIDE (KDL-40/46XBR9 ONLY) 1 - 8 7 8 - 6 2 1 - 1 2 E Y 6 8 5 7 ( 1 7 3 0 4 5 5 1 2 ) — C N 6 9 0 1...
  • Page 66 KDL-40XBR9/46XBR9/52XBR9 [INVERTER] CONDUCTOR SIDE (KDL-40/46XBR9 ONLY) 1 - 8 7 8 - 6 2 1 - 1 2 G W L P ( 1 7 3 0 4 5 5 1 2 ) E T 6 9 0 4 —...

  • Page 67: D3N Board Schematic Diagram (Kdl-52Xbr9 Only)

    KDL-40XBR9/46XBR9/52XBR9 D3N BOARD SCHEMATIC DIAGRAM (KDL-52XBR9 ONLY) L6600 R6603 JL6600 0 . 4 7 68uH 1/2W CN6600 EY6602 R6636 PFC_OUT(395V) C6600 1/4W — FPRD TO G7 450V JL6603 JL6611 PRI_GND CN6502 EY6603 PRI_VCC(12V) D6613 C6615 UF4005PKG23 JL6601 D6612 JL6652 JL6650...
  • Page 68 KDL-40XBR9/46XBR9/52XBR9 [INVERTER] COMPONENT SIDE(KDL-52XBR9 ONLY) 1 - 8 7 8 - 9 9 7 - 1 1 — E Y 6 6 5 7 ( 1 7 3 0 6 0 0 1 1 ) J W 6 6 2 2...
  • Page 69 KDL-40XBR9/46XBR9/52XBR9 [INVERTER] CONDUCTOR SIDE(KDL-52XBR9 ONLY) 1 - 8 7 8 - 9 9 7 - 1 1 J R 6 7 0 8 R 6 7 3 7 ( 1 7 3 0 6 0 0 1 1 ) C 6 7 0 2...

  • Page 70: D4N Board Schematic Diagram (Kdl-52Xbr9 Only)

    KDL-40XBR9/46XBR9/52XBR9 D4N BOARD SCHEMATIC DIAGRAM (KDL-52XBR9 ONLY) R6803 L6800 JL6800 0 . 4 7 68uH 1/2W CN6800 EY6802 R6836 PFC_OUT C6800 1/4W TO G7 450V FPRD JL6803 JL6811 PRI_GND CN6502 EY6803 — PRI_VCC(12V) C6815 D6813 UF4005PKG23 JL6801 D6812 JL6850 JL6851...
  • Page 71 KDL-40XBR9/46XBR9/52XBR9 [INVERTER] COMPONENT SIDE (KDL-52XBR9 ONLY) — — J W 6 9 1 5 J W 6 9 2 5 F B 6 8 5 0 — E Y 6 8 1 1 E Y 6 8 5 4 E Y 6 8 5 5...
  • Page 72 KDL-40XBR9/46XBR9/52XBR9 [INVERTER] CONDUCTOR SIDE (KDL-52XBR9 ONLY) C 6 9 1 6 R 6 9 2 9 R 6 9 4 8 C 6 9 1 8 R 6 9 2 6 R 6 9 2 7 C 6 9 4 2...

  • Page 73: G6N Board Schematic Diagram (1 Of 2) (Kdl-40Xbr9 Only)

    KDL-40XBR9/46XBR9/52XBR9 G6N BOARD SCHEMATIC DIAGRAM (1 OF 2) (KDL-40XBR9 ONLY) R6501 1/10W RN-CP L6501 165uH — EY6511 R6557 EY6512 0 . 4 7 1/2W L6500 EY6513 EY6214 EY6508 260uH EY6509 D6510 PFC_OUT EY6532 SF5L60 R6559 Q6501 2SK3934(LBS1SONY.Q 1/4W FPRD R6524...

  • Page 74: G6N Board Schematic Diagram (2 Of 2) (Kdl-40Xbr9 Only)

    KDL-40XBR9/46XBR9/52XBR9 G6N BOARD SCHEMATIC DIAGRAM (2 OF 2) (KDL-40XBR9 ONLY) — — — REG12V REG12V REG12V REG12V TO TCON REG12V_GND REG12V_GND REG12V_GND — REG12V_GND CN6101 PFC_OUT 12V @7.6A L6151 R6129 4.7uH JL6150 JL6151 1/4W JL6156 RN-CP REG12V JL6159 — FB6100...
  • Page 75 KDL-40XBR9/46XBR9/52XBR9 [POWER] COMPONENT SIDE (KDL-40XBR9 ONLY) C N 6 1 0 3 F B 6 5 0 0 P R I _ V C C J W 6 5 0 0 P H 6 3 0 1 P F C _ G N D...
  • Page 76 KDL-40XBR9/46XBR9/52XBR9 [POWER] CONDUCTOR SIDE P R I _ V C C (KDL-40XBR9 ONLY) P F C _ G N D F B 6 5 0 0 C N 6 1 0 3 P H 6 3 0 1 P F C _ O U T...

  • Page 77: G7N Board Schematic Diagram (Kdl-46Xbr9/52Xbr9 Only)

    KDL-40XBR9/46XBR9/52XBR9 G7N BOARD SCHEMATIC DIAGRAM (KDL-46XBR9/52XBR9 ONLY) The schematics and PWB diagrams for this board are not available. KDL-40XBR9/46XBR9/52XBR9...

  • Page 78: Hl5 Board Schematic Diagram

    KDL-40XBR9/46XBR9/52XBR9 HL5 BOARD SCHEMATIC DIAGRAM — JL306 STBY3.3V STBY_LED HD_LED ON_TIMER PWR/RESERVE_LED — PICTURE_OFF JL307 BL_IN JL308 VD3.3V JL309 SIRCS CN301 — S i r c s IC301 RS-770N — JL301 JL304 JL305 JL302 JL303 — R307 PH301 BH1690FVC-TR Q305...
  • Page 79 KDL-40XBR9/46XBR9/52XBR9 [LED, IR, SENSOR] COMPONENT SIDE C N 3 0 1 C N 3 0 2 JL307 JL303 JL308 JL301 JL305 JL304 JL302 C306 JL309 1 - 8 7 8 - 9 3 8 - 1 1 JL306 1 2 3...

  • Page 80: Semiconductors

    KDL-40XBR9/46XBR9/52XBR9 3-6. SEMICONDUCTORS – KDL-40XBR9/46XBR9/52XBR9...

  • Page 81: Section 4: Exploded Views

    2-580-607-01 SCREW, +PSW M5X12 (SCREWS TO ATTACH TABLE-TOP STAND TO TV) For product protection and safety reasons, Sony strongly recommends that you use the screws provided with the TV. CAUTION: These screws cannot be used to secure the TV to Wall Mount Brackets.

  • Page 82: Chassis

    DESCRIPTION [ASSEMBLY INCLUDES] REF. NO. PART NO. DESCRIPTION [ASSEMBLY INCLUDES] (Check the Sony Electronics Service Information website for any additional service related issues for this model.) A-1663-188-B D2N-40 BOARD, COMPLETE 1-487-341-11 G7N BOARD, COMPLETE (POWER UNIT) 2-580-593-01 SCREW, +PSW M3X8...

  • Page 83: Connectors (Kdl-40/46Xbr9 Only)

    PART NO. DESCRIPTION [ASSEMBLY INCLUDES] REF. NO. PART NO. DESCRIPTION [ASSEMBLY INCLUDES] (Check the Sony Electronics Service Information website for any additional service related issues for this model.) 1-836-474-11 CONNECTOR ASSEMBLY 1-910-054-35 CONNECTOR ASSEMBLY, 9P (KDL-40XBR9 ONLY) (KDL-40XBR9/46XBR9 ONLY) 1-836-473-11...

  • Page 84: Connectors (Kdl-52Xbr9 Only)

    REF. NO. PART NO. DESCRIPTION [ASSEMBLY INCLUDES] REF. NO. PART NO. DESCRIPTION [ASSEMBLY INCLUDES] (Check the Sony Electronics Service Information website for any additional service related issues for this model.) 1-836-472-21 CONNECTOR ASSEMBLY 1-910-054-35 CONNECTOR ASSEMBLY, 9P 1-836-743-11 CONNECTOR ASSEMBLY 1-910-054-38...

  • Page 85: Bezel Assembly And Lcd Panel

    PART NO. DESCRIPTION [ASSEMBLY INCLUDES] REF. NO. PART NO. DESCRIPTION [ASSEMBLY INCLUDES] (Check the Sony Electronics Service Information website for any additional service related issues for this model.) X-2342-908-1 CABINET ASSEMBLY (40) 4-122-605-01 SHEET, RADIATION (TCON SLIM) 2-580-640-01 SCREW, +BVTP2 4X16...

  • Page 86: Screw Legend

    See Appendix A: Encryption Key Components in the back of this manual. 4-6. SCREW LEGEND (Check the Sony Electronics Service Information website for any additional service related issues for this model.) KDL-40XBR9 DESCRIPTION REMARKS...

  • Page 87: Section 5: Electrical Parts List

    1-114-354-11 CAP, CERAMIC 0.1MF X7R (1410) C2011 1-114-331-11 CERAMIC CHIP 4.7μF A-1728-743-A BU BOARD, COMPLETE C2012 1-100-916-11 CERAMIC CHIP 0.1μF (KDL-40XBR9 ONLY) A-1728-744-A BU BOARD, COMPLETE C2013 1-135-366-11 ELECT CHIP 100μF (KDL-46XBR9 ONLY) C2014 1-114-331-11 CERAMIC CHIP 4.7μF A-1728-745-A BU BOARD, COMPLETE...
  • Page 88 KDL-40XBR9/46XBR9/52XBR9 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES C2209 1-114-326-11 CERAMIC CHIP 0.22μF C3013 1-100-916-11 CERAMIC CHIP 0.1μF C2210 1-100-912-11 CERAMIC CHIP 1μF C3015 1-100-916-11 CERAMIC CHIP 0.1μF C2211 1-114-326-11 CERAMIC CHIP 0.22μF C3017 1-100-916-11 CERAMIC CHIP 0.1μF...
  • Page 89 KDL-40XBR9/46XBR9/52XBR9 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES C7053 1-112-781-11 CERAMIC CHIP 1μF C5103 1-100-916-11 CERAMIC CHIP 0.1μF C7054 1-100-916-11 CERAMIC CHIP 0.1μF C5104 1-164-874-11 CERAMIC CHIP 100pF C7055 1-100-916-11 CERAMIC CHIP 0.1μF C5105 1-164-874-11...
  • Page 90 KDL-40XBR9/46XBR9/52XBR9 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES C7215 1-114-130-11 CERAMIC CHIP 1μF 6.3V C7277 1-100-909-11 CERAMIC CHIP 10μF 6.3V C7216 1-114-532-21 ELECT CHIP 330μF C7278 1-100-909-11 CERAMIC CHIP 10μF 6.3V C7279 1-100-909-11 CERAMIC CHIP 10μF...
  • Page 91 KDL-40XBR9/46XBR9/52XBR9 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES C7524 1-100-905-11 CERAMIC CHIP 0.001μF 10% C7437 1-100-916-11 CERAMIC CHIP 0.1μF C7438 1-114-367-11 CERAMIC CHIP 0.1μF 6.3V C7527 1-100-916-11 CERAMIC CHIP 0.1μF C7439 1-114-130-11 CERAMIC CHIP 1μF 6.3V...
  • Page 92 KDL-40XBR9/46XBR9/52XBR9 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES C7612 1-100-916-11 CERAMIC CHIP 0.1μF C7663 1-112-777-11 CERAMIC CHIP 0.01μF C7613 1-100-916-11 CERAMIC CHIP 0.1μF C7665 1-114-800-11 CERAMIC CHIP 0.0015μF 10% C7666 1-112-001-81 CERAMIC CHIP 270pF C7614...
  • Page 93 KDL-40XBR9/46XBR9/52XBR9 NOTE: Les composants identifi es per un trame et une NOTE: The components identifi ed by shading marque sont critiques pour la securite. Ne les remplacer mark are critical for safety. Replace only que par une piece portant le numero specifi e.
  • Page 94 KDL-40XBR9/46XBR9/52XBR9 NOTE: Les composants identifi es per un trame et une NOTE: The components identifi ed by shading marque sont critiques pour la securite. Ne les remplacer mark are critical for safety. Replace only que par une piece portant le numero specifi e.
  • Page 95 KDL-40XBR9/46XBR9/52XBR9 NOTE: Les composants identifi es per un trame et une NOTE: The components identifi ed by shading marque sont critiques pour la securite. Ne les remplacer mark are critical for safety. Replace only que par une piece portant le numero specifi e.
  • Page 96 KDL-40XBR9/46XBR9/52XBR9 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R3023 1-218-937-11 METAL CHIP 1/16W R3097 1-218-990-81 SHORT CHIP R3024 1-218-937-11 METAL CHIP 1/16W R3098 1-218-945-11 METAL CHIP 1/16W R3102 1-218-941-81 METAL CHIP 1/16W R3025 1-218-977-11 METAL CHIP...
  • Page 97 0.50% 1/16W R7452 1-218-965-11 METAL CHIP 1/16W R7069 1-208-911-11 METAL CHIP 0.50% 1/16W R7453 1-208-923-11 METAL CHIP 0.50% 1/16W (KDL-40XBR9 ONLY) R7070 1-208-711-11 METAL CHIP 0.50% 1/16W R7071 1-220-802-11 METAL CHIP 1/16W R7453 1-208-923-11 METAL CHIP 0.50% 1/16W (KDL-46XBR9 ONLY)
  • Page 98 KDL-40XBR9/46XBR9/52XBR9 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R7456 1-218-990-81 SHORT CHIP R7565 1-208-908-11 METAL CHIP 7.5K 0.50% 1/16W R7459 1-218-955-11 METAL CHIP 1.5K 1/16W R7570 1-218-990-81 SHORT CHIP R7582 1-218-941-81 METAL CHIP 1/16W R7461...
  • Page 99 KDL-40XBR9/46XBR9/52XBR9 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R7642 1-208-939-11 METAL CHIP 150K 0.50% 1/16W RB2306 1-234-375-21 RES, NETWORK 1K (1005X4) R7643 1-218-953-11 METAL CHIP 1/16W RB3000 1-239-698-11 RESISTOR, NETWORK 10K R7649 1-218-978-11 METAL CHIP...
  • Page 100 1-802-078-11 VARISTOR (SMD) VD1006 1-802-078-11 VARISTOR (SMD) VD1007 1-802-078-11 VARISTOR (SMD) A-1663-184-B D1N-40 BOARD, COMPLETE VD1008 1-802-078-11 VARISTOR (SMD) (KDL-40XBR9 ONLY) VD1010 1-802-078-11 VARISTOR (SMD) A-1663-186-B D1N-46 BOARD, COMPLETE VD1011 1-802-078-11 VARISTOR (SMD) (KDL-46XBR9 ONLY) VD1012 1-802-078-11 VARISTOR (SMD) 2-580-592-01...
  • Page 101 PART NO. DESCRIPTION VALUES C6619 1-114-323-11 CERAMIC CHIP 0.01μF C6763 1-162-959-11 CERAMIC CHIP 330pF C6631 1-100-912-11 CERAMIC CHIP 1μF (KDL-40XBR9 ONLY) C6632 1-114-326-11 CERAMIC CHIP 0.22μF C6763 1-100-831-91 CERAMIC CHIP 0.001μF 2% (KDL-46XBR9 ONLY) C6633 1-114-326-11 CERAMIC CHIP 0.22μF C6764...
  • Page 102 JR6652 1-216-296-11 SHORT CHIP (KDL-46XBR9 ONLY) JR6653 1-216-296-11 SHORT CHIP ! Q6604 6-552-207-01 TRANSISTOR TK6A60D JR6654 1-216-296-11 SHORT CHIP (KDL-40XBR9 ONLY) JR6655 1-216-296-11 SHORT CHIP ! Q6605 6-552-207-01 TRANSISTOR TK6A60D (KDL-40XBR9 ONLY) JR6656 1-216-295-91 SHORT CHIP ! Q6606 6-551-713-01 TRANSISTOR 2SK3569(LBS1SONY.Q...
  • Page 103 DESCRIPTION VALUES R6727 1-216-833-11 METAL CHIP 1/10W ! R6612 1-216-021-00 METAL CHIP 1/10W R6728 1-218-871-11 METAL CHIP 0.50% 1/10W (KDL-40XBR9 ONLY) R6732 1-216-839-11 METAL CHIP 1/10W ! R6612 1-216-308-00 METAL CHIP 1/10W R6733 1-216-864-11 SHORT CHIP (KDL-46XBR9 ONLY) R6737 1-218-863-11 METAL CHIP 4.7K...
  • Page 104 PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R6779 1-218-871-11 METAL CHIP 0.50% 1/10W C6815 1-107-888-11 ELECT 47μF (KDL-40XBR9 ONLY) C6816 1-112-744-61 MYLAR 1μF 450V R6779 1-218-863-11 METAL CHIP 4.7K 0.50% 1/10W C6819 1-114-323-11 CERAMIC CHIP 0.01μF (KDL-46XBR9 ONLY)
  • Page 105 REF. NO. PART NO. DESCRIPTION VALUES ! D6807 8-719-027-76 DIODE 1SS357-TPH3 ! Q6804 6-552-207-01 TRANSISTOR TK6A60D D6808 6-501-818-01 DIODE MA2J1130GLS0 (KDL-40XBR9 ONLY) D6809 6-501-818-01 DIODE MA2J1130GLS0 ! Q6805 6-552-207-01 TRANSISTOR TK6A60D ! D6812 8-719-081-67 DIODE M1FM3 (KDL-40XBR9 ONLY) D6813 8-719-979-64 DIODE μF4005/23...
  • Page 106 VALUES R6819 1-216-825-11 METAL CHIP 2.2K 1/10W R6981 1-218-879-11 METAL CHIP 0.50% 1/10W ! R6836 1-249-393-11 CARBON 1/4W (KDL-40XBR9 ONLY) R6839 1-218-885-11 METAL CHIP 0.50% 1/10W R6981 1-218-883-11 METAL CHIP 0.50% 1/10W (KDL-40XBR9 ONLY) (KDL-46XBR9 ONLY) R6839 1-218-883-11 METAL CHIP 0.50% 1/10W...
  • Page 107 KDL-40XBR9/46XBR9/52XBR9 NOTE: Les composants identifi es per un trame et une NOTE: The components identifi ed by shading marque sont critiques pour la securite. Ne les remplacer mark are critical for safety. Replace only que par une piece portant le numero specifi e.
  • Page 108 KDL-40XBR9/46XBR9/52XBR9 NOTE: Les composants identifi es per un trame et une NOTE: The components identifi ed by shading marque sont critiques pour la securite. Ne les remplacer mark are critical for safety. Replace only que par une piece portant le numero specifi e.
  • Page 109 KDL-40XBR9/46XBR9/52XBR9 NOTE: Les composants identifi es per un trame et une NOTE: The components identifi ed by shading marque sont critiques pour la securite. Ne les remplacer mark are critical for safety. Replace only que par une piece portant le numero specifi e.
  • Page 110 KDL-40XBR9/46XBR9/52XBR9 NOTE: Les composants identifi es per un trame et une NOTE: The components identifi ed by shading marque sont critiques pour la securite. Ne les remplacer mark are critical for safety. Replace only que par une piece portant le numero specifi e.
  • Page 111 METAL CHIP 100K 0.50% 1/10W R6918 1-218-891-11 METAL CHIP 0.50% 1/10W A-1663-218-A G6N BOARD, COMPLETE R6919 1-218-881-11 METAL CHIP 0.50% 1/10W (KDL-40XBR9 ONLY) 2-580-592-01 SCREW, +PSW M3X8 R6920 1-218-881-11 METAL CHIP 0.50% 1/10W R6921 1-218-865-11 METAL CHIP 5.6K 0.50% 1/10W CAPACITOR...
  • Page 112 KDL-40XBR9/46XBR9/52XBR9 NOTE: Les composants identifi es per un trame et une NOTE: The components identifi ed by shading marque sont critiques pour la securite. Ne les remplacer mark are critical for safety. Replace only que par une piece portant le numero specifi e.
  • Page 113 KDL-40XBR9/46XBR9/52XBR9 NOTE: Les composants identifi es per un trame et une NOTE: The components identifi ed by shading marque sont critiques pour la securite. Ne les remplacer mark are critical for safety. Replace only que par une piece portant le numero specifi e.
  • Page 114 KDL-40XBR9/46XBR9/52XBR9 NOTE: Les composants identifi es per un trame et une NOTE: The components identifi ed by shading marque sont critiques pour la securite. Ne les remplacer mark are critical for safety. Replace only que par une piece portant le numero specifi e.
  • Page 115 1-100-916-11 CERAMIC CHIP 0.1μF (KDL-46XBR9 ONLY) 3-268-497-01 BAG, PROTECTION CONNECTOR (KDL-52XBR9 ONLY) 3-290-788-11 BAG, PROTECTION (40) CN301 1-821-137-11 HEADER ASSEMBLY FOR PWB (KDL-40XBR9 ONLY) DIODE 3-287-548-11 BAG, PROTECTION (STAND) D301 6-502-615-01 DIODE SML-Z14MTT86A (KDL-40XBR9 ONLY) D302 6-502-755-01 DIODE SML-Z14YTT86A 4-117-034-01...
  • Page 116 2-580-607-01 SCREW, +PSW M5X12 (SCREWS TO ATTACH TABLE-TOP STAND TO TV) For product protection and safety reasons, Sony strongly recommends that you use the screws provided with the TV. CAUTION: These screws cannot be used to secure the TV to Wall Mount Brackets.

  • Page 117: Appendix A: Encryption Key Components

    MUST BE RETURNED to Sony. b) and if the core charge is NOT covered under the product warranty, the defective un-repaired or modifi...
  • Page 118 In an effort to reduce the size of this pdf fi le the tiled schematics are not attached to this Service Manual. To receive a complete set of the tiled schematics for this manual please submit a request to the Service Promotion Department at Service_Promotion@am.sony.com.

This manual is also suitable for:

Kdl-52xbr9Kdl-46xbr9

Table of Contents
