HISTORY INFORMATION FOR THE FOLLOWING MANUAL:

SERVICE MANUAL

MODEL NAME
KDL-40XBR6
KDL-40XBR6
KDL-46XBR6
KDL-46XBR6
KDL-52XBR6
KDL-52XBR6
ORIGINAL MANUAL ISSUE DATE: 8/2008
REVISION DATE
8/2008
9-883-802-01
REMOTE COMMANDER
RM-YD024
RM-YD024
RM-YD024
RM-YD024
RM-YD024
RM-YD024
SUBJECT
No revisions or updates are applicable at this time.
DESTINATION
US/CND
MX/LATIN AMERICA
US/CND
MX/LATIN AMERICA
US/CND
MX/LATIN AMERICA
LCD DIGITAL COLOR TELEVISION
EX1
CHASSIS
