EvenGlo GA 301 Installation, Operation & Maintenance Manual

Evenglo series ga301 radiant patio heater
Hide thumbs Also See for GA 301:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Manual
alfresco-heating.com
Performance that outshines
S
Manual for Installation, Operation & Maintenance
If you smell gas:
1. Shut off gas to appliance.
2. Extinguish any open flame.
3. If odour continues, immediately call your
gas supplier.
WARNING: Improper installation, adjustment, alteration,
service or maintenance can cause injury or property damage.
Read the installation, operating and maintenance instructions
thoroughly before installing or servicing this equipment.
Do not store or use gasoline or other flammable vapours and
liquids in the vicinity of this or any other appliance. An LP
cylinder not connected for use shall not be stored in the
vicinity of this or any other appliance.
*
FOR OUTDOOR USE ONLY
*
The Even-GLO heater has been approved for indoor use in non-residential
applications (See page 8 for details) for natural gas units ONLY
Please retain these instructions for future reference.
IMPORTANT: The installer or seller must leave these
instructions with the owner. Only those who are certified to do
so should perform service on these heaters.
23-428 Millen Road
Stoney Creek ON L8E 3N9 Canada
www.irenergy.ca
888-Warm-Glo
e
r
i
e
s
G
A
S
e
r
i
e
s
G
A
Radiant Patio Heater
DANGER
FOR YOUR SAFETY
3
0
1
3
0
1
