Icom IC-PCR1500 Service Manual page 24

5-3 MAIN-B UNIT ADJUSTMENT (PCR2500 only; continued)
ADJUSTMENT
S-METER
[NS0]–[WS6]
–
S-METER FLATNESS
[L5L]–[L8H]
–
CENTER METER
[CML] (LOW)
[CMH] (HIGH)
SQUELCH
[SQL]
RSSI
[RS0]–[RS6]
–
RSSI FLATNESS
[R5L]–[R8H]
–
†
Refer to the "ADJUSTMENT ITEM LIST" on page 5-7.
‡
The output level of the standard signal generator (SSG) is indicated as the SSG's open circuit.
*Displayed on the controller's display.
1 • Set the SSG as;
Frequency : Specifi ed frequency*
Modulation : None
Level : Specifi ed level
2 • Push [SET•SKIP] to store the adjustment value.
3 • Repeat 1–2 for each specifi ed frequency and value for [NS0] to [WS6].
1 • Set the SSG as;
Frequency : Specifi ed frequency*
Modulation : None
Level : Specifi ed level
2 • Push [SET•SKIP] to store the adjustment value.
3 • Repeat 1-2 for each specifi ed frequency and value for [L5L] to [L8H].
1 Set the SSG as;
Frequency : 3 kHz lower than specifi ed frequency*
Modulation : None
Level : +34 dBµ (–73 dBm)
2 • Push [SET•SKIP] to store the adjustment value.
1 • Set the SSG as;
Frequency : 3 kHz higher than specifi ed frequency*
Modulation : None
Level : +34 dBµ (–73 dBm)
2 • Push [SET•SKIP] to store the adjustment value.
1 • Set the SSG as;
Frequency : Specifi ed frequency*
Mode : FM
Modulation : 1 kHz
Deviation : 3.5 kHz
Level : –13 dBµ (–120 dBm)
2 • Set the [SQL] value to close the squelch with [DIAL]. Then set the
[SQL] value at the point where the audio signals just appear.
3 • Turn the SSG output OFF, and verify that the squelch is closed.
4 • Push [SET•SKIP] to store the adjustment value.
1 • Set the SSG as;
Frequency : Specifi ed frequency*
Modulation : None
Level : Specifi ed level
2 • Push [SET•SKIP] to store the adjustment value.
3 • Repeat 1–2 for each specifi ed frequency and value for [RS0] to [RS6].
1 • Set the SSG as;
Frequency : Specifi ed frequency*
Modulation : None
Level : Specifi ed level
2 • Push [SET•SKIP] to store the adjustment value.
3 • Repeat 1–2 for each specifi ed frequency and value for [R5L] to [R8H].
OPERATION
†
†
‡
‡
‡
†
†
5 - 6
VALUE
Automatic adjustment
Automatic adjustment
Automatic adjustment
Automatic adjustment
Automatic adjustment
Automatic adjustment
