CHARACTERISTICS
Ref.
Q.ty Product Components
1
1
Hood Canopy complete with: Controls, Light, Fan unit,
Filters
2.1
1
Upper chimney
2.2
1
Lower chimney
5
1
Lighting unit
8
1
Directional air outlet grille
9
1
Reduction flange 150-120
16
1
Filter cover
Ref.
Q.ty Installation Components
7.2.1
2
Upper chimney fixing brackets
11
6
Plugs
11a
2
SB 12/10 Wall Plugs
12a
6
Screws 4.2 x 44.4
12c
10
Screws 2.9 x 6.5
12r
2
Screws 2.9 x 6.5
12d
2
Screws 2.9 x 9.5
Q.ty Documentation
1
Instruction Manual
EN
Components
12a
7.2.1
2.1
12c
2.2
9
12d
8
12c
16
11a
1
11
12a
11
12r
9
5 5
