Summary of Contents for McLean T43
- Page 1 INSTRUCTION MANUAL ™ T-Series Air Conditioner T43 Model Protecting Electronics. Exceeding Expectations. ™ McLean Cooling Technology 11611 Business Park Blvd N Champlin, MN 55316 USA Tel 763-323-8200 Fax 763-576-3200 www.McLeanCoolingTech.com 10-1008-14 145- 5-Re Rev.
-
Page 3: Table Of Contents
Damage should be brought to the attention of the delivering carrier -- NOT to McLean Cooling Technology -- within 15 days of delivery. Save the carton and packing material and request an inspection. Then file a claim with the delivering carrier. -
Page 4: Installation
TEST FOR FUNCTIONALITY BEFORE MOUNTING THE AIR CONDITIONER TO THE ENCLOSURE. Refer to nameplate for proper electrical current requirements, then connect power cord to a properly grounded power supply. Minimum circuit ampacity should be at least 125% of the amperage shown in the design data section for the appropriate model. No other equipment should be connected to this circuit to prevent overloading. -
Page 5: Design Data, Model Drawing
16/20 9670/10290 131/55 125/57 T43-1026-G15X 50/60 10040/10670 131/55 125/57 -X will be replaced with a three-digit number designating all desired options. Consult the factory for specific model numbers. T43 Model Drawings 6K BTU 8-10K BTU 10-1008-145 Rev. 10 Page 3... -
Page 6: Mounting Instructions
T43 Mounting Cutout Dimensions External Cutout Internal Cutout 10-1008-145 Rev. 10 Page 4... - Page 7 T43 Mounting Gasket Kit 10-1008-145 Rev. 10 Page 5...
-
Page 8: Components List
T43 Series Components List Part Number (115 Volt) Part Description 6000 BTU 8000 BTU 10000 BTU Capacitor, Compressor, Start 10-1032-05 10-1032-08 10-1032-32 Capacitor, Compressor, Run S-6173 52-6032-01 52-6032-06 Capacitor, Impeller, Condenser 52-6084-01 52-6084-01 52-6031-03 Capacitor, Impeller, Evaporator 52-6084-01 52-6084-01 52-6084-01... -
Page 9: Wire Diagrams
T43 Generic Schematic (actual unit options may vary) T43 Generic Wire Diagram (actual unit options may vary) 10-1008-145 Rev. 10 Page 7... -
Page 10: Temperature Control
TEMPERATURE CONTROL The electromechanical thermostat is factory preset to 75 F/24 C. To change the temperature setting, remove the nylon plug (if applicable) from the back face of the unit. Use a standard screwdriver to adjust thermostat. For cooler temperatures turn clockwise, for warmer temperatures turn counterclockwise. - Page 11 Inlet Air Filter Proper maintenance of the inlet air filter, located behind the front cover, will assure normal operation of the air conditioner. If filter maintenance is delayed or ignored, the maximum ambient temperatures under which the unit is designed to operate will be decreased. If the compressor’s operating temperature increases above designed conditions due to a dirty or clogged filter (or plugged condenser coil), the air conditioner’s compressor will stop operating due to actuation of the thermal overload cut-out switch located on the compressor housing.
- Page 12 Caution: Operation of the air conditioner in areas containing airborne caustics or chemicals can rapidly deteriorate filters, condenser coils, blowers and motors, etc. Contact McLean Cooling Technology for special recommendations.
-
Page 13: Trouble Shooting
TROUBLE SHOOTING Basic Air Conditioning Trouble Shooting Check List Check manufacturer’s nameplate located on the unit for correct power supply. Turn the power to the unit on. The evaporator (Enclosure or “COLD” air) impeller should come on. Is there airflow? YES, proceed to step # 3. - Page 14 Getting water in enclosure * Drain plugged * Drain tube kinked * Enclosure not sealed (allowing humidity in) * Mounting gasket damaged For additional technical information (i.e., amp draw, pressures, temperatures) contact McLean Cooling Technology at 763-323-8200. 10-1008-145 Rev. 10 Page 12...
-
Page 15: Mclean Cooling Technology Warranty
McLEAN WARRANTY MCLEAN warrants that the Goods manufactured by MCLEAN will be free from defects in material and workmanship for a period of one (1) year from the date of shipment by MCLEAN, subject to the following conditions and exclusions: A. - Page 16 RETURN & REPAIR POLICY McLean products that: (i) are made to order, (ii)have been modified by Buyer , (ii) have special finishes, or (iv) are determined by McLean to constitute “custom” products that cannot be returned to stock or resold to other Buyers, will not be accepted for return by McLean.
- Page 17 3. Within 121-180 days of invoice date - 40% of applicable selling price. 4. Beyond 180 days - subject to individual review by McLean. If product being returned for credit requires repair or modification, the cost of any labor or material necessary to bring product into saleable condition will be deducted from credit.
- Page 20 Protecting Electronics. Exceeding Expectations. ™ McLean Cooling Technology 11611 Business Park Blvd N Champlin, MN 55316 USA Tel 763-323-8200 Fax 763-576-3200 www.McLeanCoolingTech.com...
