Page 1: Air Conditioner
INSTRUCTION MANUAL Air Conditioner HB16 Series Protecting Electronics. Exceeding Expectations.™ Pentair Equipment Protection 2100 Ho man Way Minneapolis, MN 55303 USA +1.763.422.2211 +1.763.576.3200 PentairEquipmentProtection.com Rev. I © 2013 Pentair Technical Products P/N 10-1008-06 87976428... -
Page 2: Table Of Contents
TABLE OF CONTENTS UNPACKING AND INSPECTING..................................2 HANDLING ........................................... 3 HOW TO IDENTIFY YOUR HIBOY® AIR CONDITIONER ..........................3 TECHNICAL INFORMATION .................................... 4 Design Data ......................................... 4 Bench Testing ......................................5 INSTALLATION INSTRUCTIONS................................6 Mounting Inside of the Enclosure ............................... 6 Mounting on Top of the Enclosure .............................. -
Page 3: Handling
HANDLING To avoid possible shipping damage and facilitate transportation and storage, the HIBOY® air conditioner was shipped in a freight carrier tested corrugated container in its normal mounting position. After uncartoning, be certain that the air conditioner is placed in its normal upright mounting position for a minimum of five (5) minutes before operating, in order to allow the compressor oil to drain to the compressor sump area. -
Page 4: Technical Information
TECHNICAL INFORMATION Design Data BTU/Hr. @ Maximum Full Load Shipping Weight Model Voltage Hertz Phase Maximum Ambient °F Ambient Amps (lb. / kg) Temperature Temperature HB160816GXXX 50/60 18.8/20.4 7075/8133 145/66 HB160826GXXX 50/60 9.4/10.2 7075/8133 145/66 HB160846GXXX 50/60 5.2/5.6 7075/8133 160/73 - 4 - ©... -
Page 5: Bench Testing
Bench Testing CAUTION To avoid possible damage to the air conditioner, it must be in an upright operating position for a minimum of five (5) minutes before functional testing is started. When “bench testing the HIBOY® air conditioner before mounting to the electronic enclosure, follow the procedures outlined in the following paragraphs: Make sure that the HIBOY®... -
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS Mounting Inside of the Enclosure 1. Slide rails must be provided for supporting the rear portion of the air conditioner. Do not depend on the units mounting flange to support the entire weight. For mounting opening cutout dimensions, see Figure 2. -
Page 7: Mounting On Top Of The Enclosure
Mounting on Top of the Enclosure 1. Make sure the enclosure design is capable of supporting the air conditioners weight. For interfacing air “IN” and “OUT” openings, refer to Figure 4. Also refer to Dimensional Drawings on page 11. 2. To protect the integrity of the closed-loop design (see PRINCIPLES OF OPERATION), adhesive backed gasket tape is provided (shipped loose) for sealing around the enclosures cutout openings. -
Page 8: Principles Of Operation
PRINCIPLES OF OPERATION HIBOY® air conditioners are designed specifically to cool and dehumidify the internal environments of cabinets and enclosure which are used to package electronic components, thus assuring a cool, clean atmosphere for reasons of optimum performance and longevity. Hot air inside the electronic enclosure or rack is removed and cooled by means of refrigeration. -
Page 9: Maintenance
MAINTENANCE Compressor The compressor requires no maintenance. It is hermetically sealed, properly lubricated at the factory and should provide years of satisfactory operating service. Should the freon charge be lost, recharging ports (access fittings) on the suction and discharge sides of the compressor are provided for recharging and/or checking suction and discharge pressures. -
Page 10: How To Remove, Clean Or Install A New Filter
How to Remove, Clean or Install a New Filter 1. Lift the filter up so the bottm clears the lower filter retainer. 2. Pull the bottom of the filter out while pushing down until the top of the filter clears the upper retainer. If the unit is operating, carefully remove it assuring no dirt from the filter enter the air intake opening. -
Page 11: Dimensional Drawings
Dimensional Drawings HB16 Models 8000 BTUs/Hr. (2051 Watts) 87976428 © 2013 Pentair Technical Products - 11 -... -
Page 12: Parts List
Parts List (Specify model and serial numbers when ordering parts) Item Number Part Number Quantity Description 10-1000-08 Inlet Filter, Reusable Aluminum 16-7001-00 Coil, Condenser 52-6034-10M Blower, Condenser (115 V) 52-6025-10M Blower, Condenser (230 V) 52-6075-00 Blower, Evaporator (115 V) 52-6076-00 Blower, Evaporator (230 V) 52-6121-01 Coil, Evaporator (8000-9000 BTU/Hr.) -
Page 13: Parts Exploded View
Parts Exploded View 87976428 © 2013 Pentair Technical Products - 13 -... -
Page 14: Wiring Schematic
Wiring Schematic - 14 - © 2013 Pentair Technical Products 87976428... -
Page 15: Electrical Schematic
Electrical Schematic 87976428 © 2013 Pentair Technical Products - 15 -... - Page 16 Notes - 16 - © 2013 Pentair Technical Products 87976428...
- Page 17 Notes 87976428 © 2013 Pentair Technical Products - 17 -...
-
Page 18: Warranty
WARRANTY Please note: Warranty effective at time of shipment. Pentair Technical Products warrants that all material and workmanship are free of defects in quality which impair the usefulness of the thermoelectric cooler or heat exchanger for a period of five (5) years for nonoperating parts, except for the filter; and for one (1) year for everything else when installed and operated under the following conditions: A. -
Page 19: Hold Harmless
HOLD HARMLESS In consideration of purchase of equipment from Pentair Technical Products by a customer, Pentair Technical Products agrees to indemnify and hold harmless such customer and users with a defense, as to any claim, demand, statutory court cost, fees for attorney’s services provided for below, and/or judgment, for actual of alleged patent infringement in any country, arising out of the use, sale or advertisement of any equipment manufactured or sold by Pentair Technical Products to Pentair Technical Products’s own specifications, provided that the customer or user shall promptly notify Pentair Technical Products in writing of any... - Page 20 Protecting Electronics. Exceeding Expectations.™ Pentair Equipment Protection 2100 Ho man Way Minneapolis, MN 55303 USA +1.763.422.2211 +1.763.576.3200 PentairEquipmentProtection.com Rev. I © 2013 Pentair Technical Products P/N 10-1008-06 87976428...
