Fantech 2SHE0721 Series Operating Instructions & Parts Manual

Operating Instructions & Parts Manual
Please read and save these instructions
observing all safety information. Failure to comply with instructions could result in personal injury and/or property damage! Retain instructions for future reference.
Description
Designed to ventilate stores, offices, factories, shops, farm buildings, etc. Efficient, easy-to-
install exhaust fan with automatic shutters. 7" to 36" diameter deep pitched propeller. Steel
intake guard complies with United States OSHA Federal 1/2" max. opening requirement. Wire
guard has charcoal gray metallic polyester finish to resist corrosion. NOTE: These units are
designed for wall mounting only. Optional Accessories: Speed controllers, 3 amp model
5ACC03SC, 5 amp model 5ACC05SC, 6 amp model 5ACC06AC, and 10 amp model 5ACC10SC.
A Sq.
Figure 1 - Dimensions
Dimensions
Propeller
Model Dia.
2SHE0721* 07"
10
2SHE1021*
12
2SHE1221*
2SHE1661* 16
18
2SHE1871*
2SHE18B1 18
20
2SHE20B1W*
2SHE20B1X 20
20
2SHE20B1Y
2SHE20C1 20
24
2SHE24B1W*
24
2SHE24B1X
24
2SHE24C1G
‡ 24
2SHE24C1H
2SHE30C1 30
36
2SHE36D1
(*) Speed controllable. (‡) Two speed.
. Read carefully before attempting to assemble, install, operate or maintain the product described. Protect yourself and others by
B
3"
9
3 / "
16
1/4 x 1/2" Slots
Air Flow
A Sq.
1
11 / "
8
1
13 /
8
1
15 /
8
1
19 /
8
1
21 /
8
1
21 /
8
1
23 /
8
1
23 /
8
1
23 /
8
1
23 /
8
1
27 /
8
1
27 /
8
1
27 /
8
1
27 /
8
1
33 /
8
1
39 /
8
Shutter-Mounted
3
5 / "
4
C Sq.
B C Sq.
15
4 / " 08"
16
9
5 / 10
16
6 12
1
6 / 16
2
3
8 / 18
4
1
12 / 18
2
1
12 / 20
8
1
12 / 20
8
9
11 / 20
16
1
12 / 20
8
13
11 / 24
16
5
12 / 24
16
5
12 / 24
16
5
13 / 24
8
1
13 / 30
8
1
13 / 36
8
12118101
2SHE07 thru 2SHE36
Exhaust Fans
Fantech, Inc. and Systemair Mfg. certify
that the ventilators shown herein are
licensed to bear the AMCA Seal. The
ratings shown are based on tests and
procedures performed in accordance with
AMCA Publication 211 and AMCA
Publication 311 and comply with the
requirements of the AMCA Certified
Ratings Program.
Unpacking
1. When receiving the unit, inspect carefully
for any damage that may have occurred
during transit.
2. Before installing, rotate the propeller to
be sure there are no obstructions which
would interfere with proper operation.
Adjust as required.
General Safety Information
Do not depend on
any switch as sole means of
disconnecting power when installing or servicing the fan.
If the power disconnect is out-of-sight, lock it in the
open position and tag to prevent application of power.
Failure to do so may result in fatal electrical shock.
Lors de
l'installation ou d'une
réparation du ventilateur, ne pas compter sur un
sélecteur comme seul moyen de coupure de
l'alimentation électrique. Si l'interrupteur d'alimentation
est hors de vue, le verrouiller en position d'arrêt et
apposer une plaquette interdisant son utilisation. À
défaut, un choc électrique pourrait être fatal.
1. Follow all local electrical and safety codes in
the United States and Canada, as well as
the National Electrical Code (NEC) and the
Occupational Safety and Health Act (OSHA)
in the United States, and the Canadian
Electric Code (CEC) in Canada.
Do not touch motor.
May be hot enough to
cause injury.
2. Motor must be securely and adequately
grounded. This can be accomplished by
wiring with a grounded, metal-clad raceway
system, by using a separate
