English
NOTE: If the pilot lamp flickers in red, pull out the plug
from the receptacle and check if the battery is
properly mounted.
Before
charging
While
charging
Pilot lamp
Charging
(red)
complete
Overheat
standby
Regarding the temperature of the rechargeable
battery.
The temperatures for rechargeable batteries are
as shown in Table 3, and batteries that have
become hot should be cooled for a while before
being recharged.
4. Disconnect battery charger from the receptacle.
CAUTION:
Do not pull the plug out of the receptacle by pulling
on the cord.
Make sure to grasp the plug when removing from
receptacle to avoid damaging cord.
5. Remove the battery from the battery charger.
Supporting the battery charger with hand, pull out
the battery from the battery charger.
Regarding electric discharge in case of new
batteries, etc.
As the internal chemical substance of new batteries
and batteries that have not been used for an
extended period is not activated, the electric
discharge might be low when using them the first
and second time. This is a temporary
phenomenon, and normal time required for
recharging will be restored by recharging the
batteries 2 – 3 times.
14
Table 4
Indications of the pilot lamp
Blinks Lights for 0.5 seconds. Does not light
for 0.5 seconds. (off for 0.5 seconds)
Lights Lights continuously
Lights for 0.5 seconds. Does not light
Blinks
for 0.5 seconds. (off for 0.5 seconds)
Lights for 1 seconds. Does not light for
Blinks
0.5 seconds. (off for 0.5 seconds)
When the battery is fully charged, the pilot lamp
will blink in red slowly. (At 1-second intervals) (See
Table 4)
How to make the batteries perform longer.
Recharge the batteries before they become
completely exhausted.
When you feel that the power of the tool becomes
weaker, stop using the tool and recharge its
battery. If you continue to use the tool and exhaust
the electric current, the battery may be damaged
and its life will become shorter.
Avoid recharging at high temperatures.
A rechargeable battery will be hot immediately
after use. If such a battery is recharged immediately
after use, its internal chemical substance will
deteriorate, and the battery life will be shortened.
Leave the battery and recharge it after it has cooled
for a while.
CAUTION:
When the battery charger has been continuously
used, the battery charger will heated, thus
constituting the cause of the failures. Once the
charging has been completed, give 15 minutes rest
until the next charging.
If the battery is recharged when it is warm due to
battery use or exposure to sunlight, the pilot lamp
may light in green.
The battery will not be recharged. In such a case,
let the battery cool before charging. (UC18YRL,
UC18YFL)
When the pilot lamp flickers in red (at 0.2 second
intervals), check for and take out any foreign
objects in the charger's battery installation hole.
If there are no foreign objects, it is probable that
the battery or charger is malfunctioning. Take it
to your authorized Service Center. (UC18YRL,
UC18YFL)
Battery overheated.
Unable to charge.
(Charging will commence
when battery cools)
