- Page 1 OPERATOR Kent SelectScrub™ KA-27, KA-33, KA-39 Models 56636998, 56637002, 56637005 4/99 Form Number 56041444(083396)
-
Page 2: Table Of Contents
BATTERY SERVICE & GUARANTEE ................12 LINT SCREEN ....................... 13 MICROSTAT™ FILTER ....................13 REVERSING THE SQUEEGEE RUBBER ..............13 SQUEEGEE RUBBER REPLACEMENT ............... 13 TROUBLE SHOOTING GUIDE ..................14 1 - FORM NO. 56041444 / SELECTSCRUB KA-27, KA-33, KA-39... -
Page 3: Machine Specifications
All welded steel 7 Ga. and 11 Ga. with epoxy powder coating. epoxy powder coating. epoxy powder coating. Outer Shell: High-density molded polyethylene High-density molded polyethylene tanks High-density molded polyethylene tanks and covers. and covers. tanks and covers. FORM NO. 56041444 / SELECTSCRUB KA-27, KA-33, KA-39 - 2... -
Page 4: Accessories
Neoprene Rear Blade 039589 039568 039569 For a complete list of accessories and to order, contact your local Kent equipment dealer or the dealer from which the machine was purchased. 3 - FORM NO. 56041444 / SELECTSCRUB KA-27, KA-33, KA-39... -
Page 5: Introduction
When the machine is delivered, carefully inspect the shipping carton and the machine for damage. If damage is evident, save the shipping carton so that it can be inspected. Contact the Kent Customer Service Department immediately to file a freight damage claim. FORM NO. 56041444 / SELECTSCRUB KA-27, KA-33, KA-39 - 4... -
Page 6: Important Safety Instructions
Store your machine indoors in a cool, dry area. Do not expose the machine to temperatures in excess of 120°F or lower than 35°F for extended periods of time. Freezing solution can result in damage to the pump, solution plumbing, and tanks. Keep your work area well lighted. SAVE THESE INSTRUCTIONS 5 - FORM NO. 56041444 / SELECTSCRUB KA-27, KA-33, KA-39... -
Page 7: Set Up
Next, attach the squeegee to the squeegee bar using the two knobs supplied with the squeegee (Figure 2). The squeegee has been factory adjusted, so it does not need initial adjusting. The machine is now ready for the brushes to be installed and prepared for scrubbing. FIGURE 2 FORM NO. 56041444 / SELECTSCRUB KA-27, KA-33, KA-39 - 6... -
Page 8: Operation
The brush pressure on the floor can be adjusted by pressing the “+” or “-” side of switch. Monitor brush pressure by using the brush pressure indicator, readings will vary with different floor conditions. 7 - FORM NO. 56041444 / SELECTSCRUB KA-27, KA-33, KA-39... -
Page 9: Solution
This filter is located at the bottom of the tank through the opening in the front lid. This filter does not require regular cleaning; however, if something should fall into the tank, the filter should be inspected and possibly cleaned. FORM NO. 56041444 / SELECTSCRUB KA-27, KA-33, KA-39 - 8... - Page 10 Next, open the solution tank’s lid, then open the solution tank’s drain valve. Lower the squeegee to switch the vacuum motor on. This will rinse the recovery tank with the solution from the solution tank. Now, you are ready to drain the recovery tank using the procedures above in “EMPTYING AND RINSING THE RECOVERY TANK”. FIGURE 5 9 - FORM NO. 56041444 / SELECTSCRUB KA-27, KA-33, KA-39...
-
Page 11: Clean Up And Storage
Do not expose the machine to temperatures in excess of 120°F or lower than 35°F for extended periods of time either in storage or in transporting. Freezing solution can result in damage to the pump, solution plumbing, and tanks. FORM NO. 56041444 / SELECTSCRUB KA-27, KA-33, KA-39 - 10... -
Page 12: Maintenance
To raise the squeegee and reduce pressure on the squeegee blades, turn the knob counterclockwise to the desired height. Refer to Figure 8 for the correct height adjustment for the squeegee. FIGURE 8 11 - FORM NO. 56041444 / SELECTSCRUB KA-27, KA-33, KA-39... -
Page 13: Battery Charging
Service & Battery Guarantee. The Service & Battery Guarantee will not apply if battery has been opened or repaired or manufacturer’s identification markings has been obliterated before presentation for adjustment or if battery has broken case or cover or if battery is discharged. FORM NO. 56041444 / SELECTSCRUB KA-27, KA-33, KA-39 - 12... -
Page 14: Lint Screen
After these bolts are removed, the squeegee can be disassembled and reassembled with the new squeegee rubber. Once the squeegee is reassembled, replace the eight bolts and reattach it to the machine. For information on squeegee accessory part numbers and ordering, refer to “ACCESSORIES”. 13 - FORM NO. 56041444 / SELECTSCRUB KA-27, KA-33, KA-39... -
Page 15: Trouble Shooting Guide
Recharge batteries fully before beginning op- Corroded wires or connectors. eration. Clean thoroughly. Any electrical servicing must be performed by the dealer from which the machine was purchased or an authorized service station. FORM NO. 56041444 / SELECTSCRUB KA-27, KA-33, KA-39 - 14... - Page 16 Nilfisk-Advance, Inc. 14600 21st Avenue North Plymouth, MN, 55447-3408 www.nilfisk-advance.com Phone: 800-989-2235 Fax: 800-989-6566 ©1999 Nilfisk-Advance, Inc., Plymouth, MN 55447-3408 Printed in the U.S.A.
