regency Horizon
www.regency-fire.com
WarninG
fire or explosion HaZard
failure to follow safety warnings exactly could result in serious
injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
- WHat to do if You sMell Gas
•
Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach you gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Tested by:
919-372
fpi fireplace products international ltd. 6988 Venture st., delta, Bc canada, V4G 1H4
Gas fireplace
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
HZ54e
™
Owners &
Installation Manual
MODELS: HZ54E-NG10 Natural Gas
HZ54E-LP10 Propane
Horizon HZ54E Product Video
09.10.14
Advertisement
Table of Contents
Related Manuals for Regency HZ54E-NG10
Summary of Contents for Regency HZ54E-NG10
- Page 1 Owners & regency Horizon HZ54e ™ Installation Manual Gas fireplace MODELS: HZ54E-NG10 Natural Gas HZ54E-LP10 Propane www.regency-fire.com Horizon HZ54E Product Video WarninG fire or explosion HaZard failure to follow safety warnings exactly could result in serious injury, death, or property damage.
- Page 2 To the New Owner: Congratulations! You are the owner of a state-of-the-art Gas Fireplace by ReGenCY . The HZ54e has been ® designed to provide you with all the warmth and charm of a wood fireplace at the flick of a switch.
-
Page 3: Manufactured Mobile Home Requirements
Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280, in the Untied States, or the Standard for Installation in Mobile Homes, CAN/CSA Z240 MH, in Canada. Regency Horizon Horizon HZ54 Product Video Gas Inserts Benefits Video Regency Horizon HZ54E-10 Gas Fireplace... -
Page 4: Table Of Contents
The Warranty: Limited Lifetime ........59 Venting Arrangements ..........27 Allowable Vertical Terminations for HZ54e-lp ..27 Unit Installation with Horizontal Termination ....28 Unit Installation with Vertical Termination ....29 Unit Installation Horizontal Termination .......30 with Flex Vent System .........30 Regency Horizon HZ54E-10 Gas Fireplace... -
Page 5: Copy Of Safety Decal
This is a copy of the label that accompanies each HZ54E-NG10/HZ54E-LP10 Direct Vent Gas Fireplace. We have printed a copy of the contents here for your review. note: Regency units are constantly being ® improved. Check the label on the unit and if there is a difference, the label on the unit is the correct one. -
Page 6: Ma Code - Co Detector
(e) A copy of all installation instructions for all Product Approved side wall horizontally vented gas fueled equipm ent, all venting instructions, all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or equipment at the completion of the installation. Regency Horizon HZ54E-10 Gas Fireplace... -
Page 7: Unit Dimensions
& door fraMe oVerlaY diMensions The Verona Glass Surround (Not Shown) Dimensions: 58-9/16" W x 27-1/8" H Regency Horizon HZ54E-10 Gas Fireplace... -
Page 8: Important Message
National Electrical Code, ANSI/NFPA 70 or CSA C22.1 Canadian electrical Code. 3) See general construction and assembly in- structions. The appliance and vent should be enclosed. Regency Horizon HZ54E-10 Gas Fireplace... -
Page 9: Installation Checklist
The Heat Release Kit expels warm air from the fireplace to the outside of the building, allowing the fireplace to be operated with less heat entering the room. The kit may be used on either the left or right side. Regency Horizon HZ54E-10 Gas Fireplace... -
Page 10: Clearances
1-1/2" firestop is used. Installed Close Installed Close to Ceiling to Floor non-coMBustiBle reQuireMents Metal Stud (header) 60-1/2" (1537mm) Wood Stud Wood Stud Non-combustible Material 52-7/8” Non-combustible Material 3-7/8" 5-1/2” ( 99mm) (140mm) 10 | Regency Horizon HZ54E-10 Gas Fireplace... -
Page 11: Non Combustible Facing Board
While every precaution is taken in providing the recommendations on preparation and finish, given the variations in paint quality, with temperature limits and workmanship in application, Regency is unable to guarantee the life of the joint compounds, paint or any other finish materials or workmanship applied to or used in any application surrounding the fireplace. -
Page 12: Mantel Clearances
Fireplace 28-1/8” Opening To Unit Base Legs Mantel leG clearances Combustible mantel leg clearances as per diagram: 4”(102mm) MANTEL LEG Non-Combustible 1.5" (38mm) 5-1/2” (140mm) Allowable mantel leg projection 8” (203mm) 11” (279mm) 12 | Regency Horizon HZ54E-10 Gas Fireplace... -
Page 13: Framing & Finishing
52-7/8 ” Unit shown without faceplate for Illustrative purposes only NOTE: The Verona Glass Surround (not shown) opening needs to be 60-1/16" W x 28 5/8" H Regency Horizon HZ54E-10 Gas Fireplace... -
Page 14: Unit Assembly Prior To Installation
Standoff Diagram 2 separate vent system. Common vent systems are prohibited. Remove screws to release standoffs 14 | Regency Horizon HZ54E-10 Gas Fireplace... - Page 15 The horizontal studs allow the non-combustible wall board to be attached and supported. (Located on the right side of the fireplace) Regency Horizon HZ54E-10 Gas Fireplace...
-
Page 16: Optional Framing Kit
4. Attach both vertical studs and secure using 6 screws (2 at bottom, 2 at top and 2 on the sides) as shown note: Ensure the flat side of the steel stud is facing the wood framing. 16 | Regency Horizon HZ54E-10 Gas Fireplace... -
Page 17: Wall Mount On / Off Switch Installation
11. Using the two (2) screws provided secure the cover plate to the Receiver. Low Voltage Junction Box Profl ame Receiver J-Box Receiver Slider Switch Wall Plate 10 ft. wire harness with 12 pin connector Diagram 1 Regency Horizon HZ54E-10 Gas Fireplace... -
Page 18: Vent Restrictor Position
THIS HOLE SETS THE VENTR ESTRICTOR VENT RESTRICTOR AT 2-1/2” AT 1” Vent Restrictor Set 5 Vent Restrictor Set 3 2” SET 4 THIS HOLE SETS THE VENTR ESTRICTOR AT 2” Vent Restrictor Set 4 18 | Regency Horizon HZ54E-10 Gas Fireplace... -
Page 19: Exterior Vent Termination Requirements
* Clearance in accordance with local installation codes and the requirements of the gas supplier 3 feet (91cm) within a height of 15 feet (4.5m) above the meter / regulator assembly 3 feet (91cm) above - if within 10 feet (3m) horizontally Regency Horizon HZ54E-10 Gas Fireplace... -
Page 20: Venting Arrangements
2) Only Flex pipe purchased from FPI may be used for Flex installations. 3) Horizontal vent must be supported every 3 feet. 4) A wall thimble is mandatory for all horizontal terminations due to high temperatures. 20 | Regency Horizon HZ54E-10 Gas Fireplace... -
Page 21: Rigid Pipe Venting Systems
Direct Vent Pro, ICC Excel and Selkirk ® Direct-Temp. AstroCap XL is a proprietary trademark of FPI Fireplace Products International Ltd. Dura-Vent® and Direct Vent are registered and/or proprietary trademarks of Simpson Dura-Vent Co. Inc. Regency Horizon HZ54E-10 Gas Fireplace... -
Page 22: 5" X 8" Rigid Pipe Cross Reference Chart
Components from different Manufacturers may not be mixed. Not All Rigid Pipe components are available directly from FPI. 5” X 8” RIGID PIPE CROSS REFERENCE CHART Components from different Manufacturers may not be mixed. Not all rigid pipe components are available directly from Regency. Description... - Page 23 • A Vent Guard is required when the AstroCap is installed above grade at 7 feet or lower. • The Simpson Dura-Vent and Selkirk Direct Temp horizontal termination caps cannot be used in any applications. • Only the AstroCap XL and Snorkels are certifi ed for horizontal terminations. Regency Horizon HZ54E-10 Gas Fireplace...
-
Page 24: Venting Arrangements
• A wall thimble is mandatory for all horizontal terminations due to • A wall thimble is mandatory for all horizontal terminations due high temperatures. to high temperatures. 24 | Regency Horizon HZ54E-10 Gas Fireplace... - Page 25 Please note min. 1 foot 5' Min. 4' Max. 10' Min. 7' Max. between 90 elbows is 6' Min. 6' Max. 11' Min. 9' Max. required. VENT RESTRICTOR SETTING: Vent restrictor factory set at Set 1, no adjustment required. Regency Horizon HZ54E-10 Gas Fireplace...
- Page 26 Please note min. 1 foot 5' Min. 6' Max. 8' Min. between 90 elbows is 6' Min. 8' Max. 9' Min. required. VENT RESTRICTOR SETTING: Vent restrictor factory set at Set 1, no adjustment required. 26 | Regency Horizon HZ54E-10 Gas Fireplace...
-
Page 27: Venting Arrangements
Set 1 to Set 2 or Set 4 if required. Note: Must use optional flue adaptor when using Rigid Pipe (Part # 770-994). Max. 10’ (3m)(centerline to centerline) Minimum length of pipe between elbows 12” (305mm) Regency Horizon HZ54E-10 Gas Fireplace... -
Page 28: Allowable Vertical Terminations For Hz54E-Lp
Set 1 to Set 4 or Set 5 if required. Note: Must use optional flue adaptor when using Rigid Pipe (Part # 770-994). Max. 10’ (3m)(centerline to centerline) Minimum length of pipe between elbows 12” (305mm) 28 | Regency Horizon HZ54E-10 Gas Fireplace... -
Page 29: Unit Installation With Horizontal Termination
The location of the horizontal vent termination on an exterior wall must meet all local and national building codes, and must not be blocked or obstructed. See "Exterior Vent Termination Locations" Diagram 7 section for more details. Regency Horizon HZ54E-10 Gas Fireplace... -
Page 30: Unit Installation With Vertical Termination
Diagram 5 or local codes. Note that for steep roof pitches, the vertical height must be increased. Diagram 3 30 | Regency Horizon HZ54E-10 Gas Fireplace... -
Page 31: With Flex Vent System
1-3/8"(35mm) and fasten with the 3 screws. NOTE: Horizontal sections must be supported at intervals not exceeding 3 feet (0.9 meter). (Flame picture and performance will be affected by sags in the liner). Regency Horizon HZ54E-10 Gas Fireplace... -
Page 32: High Elevation
Do not use open flame for leak testing. Note: To properly check gas pressure, both inlet and manifold pressures should be checked using the valve pressure ports on the valve. 32 | Regency Horizon HZ54E-10 Gas Fireplace... -
Page 33: Valve Cover Removal
2) The valve cover is located on the right side underneath the glass door - loosen 2 screws securing the valve cover (see Diagram 1 below). Diagram 3 Diagram 1 Valve cover 3) Slide the valve cover upward. Diagram 2 Regency Horizon HZ54E-10 Gas Fireplace... -
Page 34: Aeration Adjustment
For instructions to remove the burner for access to the aeration controls is NOT covered the ventury cap, see pages 46-47 in this manual. 1/2" under warranty. LP with Logs Full open LP with Stones Full open Venturi Cap 34 | Regency Horizon HZ54E-10 Gas Fireplace... -
Page 35: Wiring Diagram
Caution: Ensure that the wires do not touch any hot surfaces and are away from sharp edges. caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Regency Horizon HZ54E-10 Gas Fireplace... -
Page 36: Optional Reflective Panel Installation
Fit side panel tab into slot Right side back panel tab fi tted into slot Left side panel in position Bracket shown in place on right side of the fi rebox 36 | Regency Horizon HZ54E-10 Gas Fireplace 10/08/09 918-754a... -
Page 37: Glass Crystals Or Optional Stones
Beads Pebbles HZ54e 6 lbs 9lbs 2 packages (6 x bags pebbles) Natural River Pebbles shown surrounding the Horizon Burner Glass Crystals shown surrounding the Burner Optional Volcanic Stones + Glass Crystals shown on burner. Regency Horizon HZ54E-10 Gas Fireplace... -
Page 38: Optional Driftwood Log Set Installation
Ensure L and R sides are in the correct position. Secure template in place with magnets (supplied) on each side. HZ40E - log placement template - HZ54E - existing Pilot HZ54E - new Pilot shown in place. Hood Hood 38 | Regency Horizon HZ54E-10 Gas Fireplace 05/14/13 919-258a... - Page 39 13. Position Right Log (5) by lining pin on Logs 1 with pin landing on Log 3, match bottom of Log 5 and template profi le. 14. Carefully remove log placement template. Match pin and pin landing Logs 1 and 3. HZ40E shown - Completed Install Regency Horizon HZ54E-10 Gas Fireplace 919-258a 05/14/13...
-
Page 40: Faceplate & Door Frame Overlay Installation
There is a top and bottom, the top of the faceplate has a full 1" return whereas the bottom only has a 1/2" return as shown in the diagram below. 40 | Regency Horizon HZ54E-10 Gas Fireplace 06.03.14 919-387... - Page 41 Also if necessary, the faceplate may be adjusted up and down by loosening the top screw as shown in the diagram below and sliding the plate up or down as required. Faceplate Mounting Slots Completed Faceplate Installation Regency Horizon HZ54E-10 Gas Fireplace 919-387 06.03.14...
-
Page 42: Optional Fan Installation
Aerial View of the inside of the unit shown. 7) Remove bottom cover by undoing 3 screws securing it to the fi rebox base, lift up and out. Aerial View of the inside of the unit shown. 42 | Regency Horizon HZ54E-10 Gas Fireplace... -
Page 43: Fan Installation
fl oor of the fi rebox. Ground Lug 16) Slide the thermodisc into the bracket on the bottom side of the fan access panel - check fan access panel gasket - replace if necessary. Fan Access Panel Regency Horizon HZ54E-10 Gas Fireplace 918-903a 11/03/10... - Page 44 These fans collect a lot of dust from within your home. Ensure you maintain these fan motors on a regular basis by vacuuming the fan blades and housing using a soft brush nozzle. 44 | Regency Horizon HZ54E-10 Gas Fireplace...
-
Page 45: Wiring Diagram With Optional Fan
Caution: Ensure that the wires do not touch any hot surfaces and are away from sharp edges. caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Regency Horizon HZ54E-10 Gas Fireplace... -
Page 46: Operating Instructions
Use a non-abrasive cleaner and do not atteMpt to clean tHe Glass WHile it is Hot. 46 | Regency Horizon HZ54E-10 Gas Fireplace... -
Page 47: Lighting Procedure
1. Turn the wall mounted switch or remote to the "OFF" position. Button 2. Press "OFF" on the remote control. 3. Turn the gas control knob to the "OFF" position to turn off the pilot. Diagram 2 Remote shown in Manual Mode on Hi Regency Horizon HZ54E-10 Gas Fireplace... -
Page 48: Copy Of Lighting Plate Instructions
Utilisez l'interrupteur murale ON/OFF du Brûleur ou du contrôle à distance pour éteindre le brûleur. Appuyez sur OFF sur la télécommande. Mettre le bouton de commande de gaz en position OFF pour éteindre la veilleuse. DO NOT REMOVE THIS INSTRUCTION PLATE 919-401 48 | Regency Horizon HZ54E-10 Gas Fireplace... -
Page 49: Maintenance Instructions
7) In the event this appliance has been serviced should be done by a licensed or check that the vent-air system has been properly qualified service person. resealed & reinstalled in accordance with the manufacturer's instructions. 8) Verify operation after servicing. Regency Horizon HZ54E-10 Gas Fireplace... -
Page 50: Glass Door Removal
4) Remove the door frame overlay by swinging out 45 from the bottom and lift up and out. 6) Remove valve cover - (see valve cover removal section in this manual). 50 | Regency Horizon HZ54E-10 Gas Fireplace... - Page 51 6. Attach the completed assembly to the glass frame on the fireplace. 3. Pull the bottom of the inner door frame towards you, lift up and remove the frame Bend down the six tabs to secure the mesh to the outer door frame. Tabs Regency Horizon™ HZ54E-10 Gas Fireplace...
-
Page 52: Valve Tray Replacement
Prior to removing burner - remove the following (if installed): 4) Remove the door frame overlay by swinging out 45 from the bottom -crystals and lift up and out. -pebbles -spa stones -logs -inner panels 52 | Regency Horizon HZ54E-10 Gas Fireplace... -
Page 53: Hz54E-Ng Unit
8) Partially lift out valve tray. 9) Disconnect the inlet gas line. Green Wire Orange Wire 4) Disconnect the green ground wire from the valve bracket. 10) Replace valve and reverse steps. Green ground wire Regency Horizon HZ54E-10 Gas Fireplace... -
Page 54: Hz54E-Lp Unit
Location of screws securing burner 10) Partially lift out valve tray. 11) Disconnect the inlet gas line. Burner Bracket 6) With burner removed - lift out burner tray. Gas Inlet Line 12) Replace valve and reverse steps. 54 | Regency Horizon HZ54E-10 Gas Fireplace... -
Page 55: Main Assembly
Pilot Assembly 476-145 Pilot Shield 911-032 Wire harness 911-013 Valve wiring w/ IPI/CPI switch 910-576 Wall Switch/Receiver cover (white) 919-372 Manual 911-012 Ignition Board 946-721 AC Adaptor 910-592 GTMF Hand held transmitter 911-030 Fan Control Module Regency Horizon HZ54E-10 Gas Fireplace... - Page 56 56 | Regency Horizon HZ54E-10 Gas Fireplace...
-
Page 57: Accessories
Fan Kit 256-930/P Log Set 946-672 natural River Pebbles 946-674 Ceramic Spa Stones 946-710 Volcanic Stones Slate/Grey 946-711 Volcanic Stones Ivory/Tan 946-556 Heat Wave Duct Kit 946-570 Heat Release Kit 476-936 non-Combustible Board 4 Pieces Regency Horizon HZ54E-10 Gas Fireplace... - Page 58 58 | Regency Horizon HZ54E-10 Gas Fireplace...
- Page 59 Regency Horizon HZ54E-10 Gas Fireplace...
