Summary of Contents for Zeagle Octo-Z
- Page 2 This owner’s manual uses signal words recommended by the American National Standards Institute (see ANSI Z535.4) to des- ignate levels of hazard seriousness. These signal words and their designations are as follows: DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. This signal word is to be limited to the most extreme situ- ations.
-
Page 3: Table Of Contents
Introduction – Safety Information Warranty Information Disclaimer and Limitation of Remedy Nitrox Use Using the Octo-Z Breathing on the Octo-Z Inflating the BC with Tank Air Inflating the BC Orally Deflating the BC with the Octo-Z Post-Dive Care Maintenance Specifications Service Record Notes... -
Page 4: Introduction - Safety Information
Congratulations on your Zeagle Regulator Purchase! Your Zeagle Octo-Z is a combination Regulator and BC Inflator. It has been designed and manufactured to the highest possible standards of performance and reliability. With the reasonable care outlined in this manual it will provide you with many years of diving enjoyment. -
Page 5: Warranty Information
It is your record of when and where the regulator was purchased. If you bring your Octo-Z to a different Zeagle Dealer, they will ask to see your receipt to begin warranty service. The receipt also lets... -
Page 6: Disclaimer And Limitation Of Remedy
9. Warranty coverage in countries other than the US varies. Outside the US your dealer will be able to get further Warranty information from their Authorized Zeagle Regional Distributor. Disclaimer And Limitation On Remedy... - Page 7 This owner’s manual is in no way meant to be a substitute for the instruction received from a certified scuba training agency. 2. Zeagle regulators must be serviced only by dealers or technicians trained and authorized to service Zeagle Scuba equipment. At no...
- Page 8 1. Like all connections on your Scuba set-up, the connection between the corrugated hose and the Octo-Z should be checked for tightness before each dive. The Collar should be tightened using the fingers, with enough force so that it will not become accidentaly loosened during the dive.
-
Page 9: Nitrox Use
NITROX USE Zeagle regulators are manufactured using materials suitable for use with oxygen enriched gases (i.e., Nitrox, etc.) providing the oxygen content does not exceed 40%. The regulator must be kept “Oxygen Clean”... -
Page 10: Using The Octo-Z
Your Octo-Z has a large Threaded Coupling that attaches the large Corrugated Hose to the Octo-Z Body. Prior to setting up your gear for a dive, your Octo-Z will be in your regulator bag with your primary regulator, not drag- ging in the dirt at the end of your Corrugated BC hose like other Reg/Inflator Combination units. - Page 11 Z can be attached to the corrugated hose. Make this connection by bringing the coupling on the corrugated hose to the male thread on the Octo-Z and screwing the two together by hand. Tighten the collar (clockwise) snuggly with your fingers, not a wrench.
-
Page 12: Breathing On The Octo-Z
Octo-Z, push the Purge Cover gently inwards to allow compressed air to blow the water out of the Octo-Z for you. Once the housing is clear of water, you can begin breathing normally. -
Page 13: Inflating The Bc With Tank Air
QD fitting means that unlike most Reg/Inflator combinations of this style, you can easily rotate the mouthpiece outwards to make the Octo-Z more accessible to another diver if you prefer to hand off your Octopus (Safe-second) regulator instead of your primary regulator. -
Page 14: Inflating The Bc Orally
Octo-Z. When you have finished exhaling, release the oval Inflate Button. Repeat as necessary. To deflate your BC, you can pull the Octo-Z out away from you BC to apply tension to the cable release on your BC’s shoulder mounted Dump Valve (if equipped). -
Page 15: Maintenance
A LITTLE LEAKAGE IS OK. MAINTENANCE It is essential that your Octo-Z is checked at least annually by an authorized Zeagle regulator technician. Unusually heavy use, or use in dirty or contaminated water may result in the need for more frequent service. -
Page 16: Specifications
320-7200Y (Yellow), or 320-7200K (Black) FEATURES: - High-Flow QD Connection for Supply Air. - Corrugated Hose Disconnect (so Octo-Z can easily be stored with regulator) - Corrugated Hose Rinse Connection (Garden Hose can be connected to BC for easy effective rinsing. -
Page 17: Service Record
Service Record Work Done by: Date: Service: Year 1, Simple Inspection: Year 2, Complete Overhaul: Year 3, Simple Inspection: Year 4, Complete Overhaul: Year 5, Simple Inspection: Year 6, Complete Overhaul: Year 7, Simple Inspection: Year 8, Complete Overhaul: Year 9, Simple Inspection: Year 10, Complete Overhaul: Year 11, Simple Inspection: Year 12, Complete Overhaul:... -
Page 18: Notes
Notes: The date of purchase, dive store, and contact informa- tion at the store should be written on this page. A copy of the receipt could also be stapled to this page for future records. - Page 19 Zeagle Systems Inc. 37150 Chancey Road, Zephyrhills, FL, 33541 Phone: (813) 782-5568 Fax: (813) 782-5569 www.zeagle.com p/n 175-1650 © 2007 Zeagle Systems, Inc. 03/07...
