Specifications

UART:
OS Support:
Data Rates:
Buffering:
Drivers/Receivers:
Interface:
Signals:
Connector Configuration:
Bus Interface:
Dimensions:
Power Requirements:
Certification:
Operating Temperature
Range:
Humidity:

Features

New high performance 17D154 UART
Standard or the Fastcom: 232/4-LPCI-335
All baud rates up to and above 1 Mbps (See
64 byte FIFOs for improved throughput
Four independent channels
Software programmable baud rates
Switchless design for durability and reliability
Status LED's for system development / debugging
Durable cables with RFI shielding
Hardware documentation, software, and example programs provided on the Fastcom CD
Made in Wichita, Kansas USA
Exar 17D154
Windows XP, 2000 (Linux pending)
All baud rates up to and above 1 Mbit/s (See
section)
64 byte Tx FIFO each channel
64 byte Rx FIFO each channel
High Speed RS-232
RS-232F
TXD, RXD, DTR, DSR, DCD, RTS, CTS, RI
DIN1, DIN2, DOUT1, DOUT2
DB44 male to 4 DB25 male
32-bit PCI Version 2.3
Low Profile PCI - MD1
600mA @ +5V (typical)
FCC compliant, CE marked
0°C to 70°C
0 to 90% (non-condensing)
Maximum Data Rate
Maximum Data Rate
section)
3
