- Page 1 Manual de instalación y uso del aparato Manual de instalação e utilização do aparelho Installation manual and instructions for use Installations- und Bedienungsanleitung...
-
Page 3: Installation And Fitting
DISHWASHER INSTALLATION AND FITTING UNPACKAGING THE DISHWASHER UNPACKAGING Remove inner protection elements i.e. polystyrene wedges holding the baskets in place. I M P O R TA N T The specifications label is on the top edge of the interior of the door. This label must never be removed, since it provides information about the exact model of the dishwasher, required power supply, serial number and warranty. -
Page 4: Electrical Connection
The hose must run between the wall and the bottom space at the back of the dis- hwasher (b1) so that it is not squashed or overstretched. A fixed drain outlet at a If your dishwasher has a distance of 25 - 100 cm hot water inlet, connect from the floor is recom- the pipe to the hot water... - Page 5 English LEVELLING AND POSITIONING To install an integrated dishwasher: WORKTOP If the worktop is wooden, fit the plastic protection onto it to prevent the area from being damaged by steam. Fit the front brackets to the dishwasher so that it can be fixed to neighbouring units or the work surface (see point k, page 54).
- Page 6 DOOR An information template is provided with the assembly instructions. An information template is provided with the assembly instructions. Position the template, fix it in place and mark the position of the holes. Drill the holes with a Ø 2.5 mm bit and screw the supports to the panel with the curved part facing downwards.
- Page 7 English For integrated stainless steel models, the following installation instructions should be taken into account: Column-integrated Integrated beneath a worktop 50 114 mm...
- Page 8 PRE-WASH Once the dishwasher has been installed correctly, it should be first used on prewash programme: Open the dishwasher door. Press the dishwasher ON button. Select programme 1 PROG (prewash), with no dishes or detergent. Close the door. The dishwasher will start up automatically.
-
Page 9: Using The Appliance - A Few Practical Tips
DISHWASHER USING THE APPLIANCE - A FEW PRACTICAL TIPS WATER HARDNESS, SALT, RINSE-AID AND DETERGENT Adjusting water hardness. Before switching the dishwasher on, check the hardness of the water in your area. This information is available from your local water board, the town hall, the technical assistance service or you can use the Aquadur strip supplied in the bag of accessories. - Page 10 1. Press the Time Delay ELECTRONIC REGULATION button and hold it down for three seconds. The On some models, the salt letter “L” followed by a regulator is electric (has number will appear on the no numbers: (see Mod. C display (L1).
- Page 11 English When do I need to add salt? Depending on the model, a window on the lid of the salt container or a light indicator on the front of the appliance show when salt is required. It is recommended that WINDOW PILOT LIGHT you replace the used salt...
- Page 12 When do I need to add rinse-aid? The dishwasher itself will inform you of when the rinse aid needs refilling. A pilot light on the design panel will come on when a refill is necessary. PILOT LIGHT The deter gent is poured into a container on the inside of the door, next to the rinse-aid...
- Page 13 English TABLEWARE AND UTENSILS. TYPES AND POSITIONING Not all utensils can be silver cutlery does not not good. Check with the washed in a dishwasher. come into contact as they manufacturer of China. Do not attempt to wash may stain. Only wash glasses that items made of wood or Items made of alumi-...
- Page 14 L e s c o u v e r t s , Except for knives, cutlery should be placed in the cutlery rack, with the handles at the bottom. P l a c e t h e m o r e delicate items, such as cups, glasses, FOR 13 PLACE SETTINGS...
- Page 15 English Adjusting the racks The racks can be adjus- ted in accord with the load. The top rack can be pla- ced at two different heights for washing different-sized plates. In the upper position, the top rack holds standard- size plates of up to 19 cm and the bottom rack holds plates of up to 31 cm.
- Page 16 SELECTING THE WASH PROGRAMME PROG TOP or BOTTOM LOAD selector SALT TIME DELAY PROGRAMME PROGRAMME ON/OFF pilot light RINSE AID selector Visor selector button pilot light (VISOR) TOP or BOTTOM LOAD pilot lights PROG STOP 70º 65º 50º 55º 50º PROGRAMME TIME DELAY pilot llight...
- Page 17 English There are various programme types depending on the dishwasher model: It is very important to choose the wash programme in accordance with the type and amount of utensils and level of soiling. TOTAL APPROX. AMOUNT OF TEMPERATURE DURATION CONSUMPTION PROGRAMME SYMBOL TYPE OF UTENSILS...
-
Page 18: Selecting Additional Functions
SELECTING ADDITIONAL FUNCTIONS Wash functions must always be selected after the wash programme has been selected. If the programme is changed during the selection, the previously selected functions are cancelled. These functions make it possible to adjust the wash load, times and consumption to a maximum. The additional functions available depend on the model: Button: Time delay Button: Top/bottom... -
Page 19: End Of Programme
English END OF PROGRAMME When the dishwasher programme ends, a continuous beep will sound for 3 seconds. When you open the dishwasher door you will be able to see that washing has finished as MODELS a pilot light will have lit up DISPLAY on the design panel. -
Page 20: Appliance Maintenance And Cleaning
DISHWASHER APPLIANCE MAINTENANCE AND CLEANING You should perform the • Clean the filter. I M P O R TA N T cleaning operations • Cleaning the spray arms. If you are planning regularly so that your • Clean the inside. to be away for a long dishwasher will last •... -
Page 21: Cleaning The Inside Of The Appliance
English CLEANING THE SPRINKLERS The third spray arms (some models only), the upper spray arm and the lower spray arm are to be cleaned every three months. Removing the spray arms: The third spray arm is removed by pressing u p w a r d s a n d unscrewing it. -
Page 22: Troubleshooting
DISHWASHER TROUBLESHOOTING If you find a problem If this is not so, please when using your dishwas- contact the TECHNI- her, you will probably be CAL ASSISTANCE able to solve it by consul- SERVICE and be ready ting the following section. to provide as much infor- mation as possible. - Page 23 English • Why won’t the dishwasher start? This may be because: – There is no power. – It isn’t plugged in correctly. – The power fuses have blown. – The dishwasher is not connected to the mains. – You haven’t pressed the On/Off button (the pilot light for this button must be on continuously). –...
- Page 24 PROBLEMS WITH THE QUALITY OF THE WASH • Remains of dirt or food on the utensils This may be because: – The wash filter is dirty, blocked or not correctly in place. – The sprinkler holes are dirty, or the sprinklers are being blocked by the dishes. –...
-
Page 25: Further Information
DISHWASHER FURTHER INFORMATION INFORMATION FOR THE CORRECT DISPOSAL OF ELECTRICAL AND ELECTRONIC APPLIANCES When the appliance reaches the end of its service life, you should not dispose of it with the general domestic waste. It can be taken free of charge to the local administrations’ specific selective collection centres, or to distributors who provide this service.
