Event Cylinder RF
User Instructions
5/12
Event Cylinder RF
Unpacking:
Thank you for purchasing the Event Cylinder RF by Ela-
tion Professionals
. Every Event Cylinder RF has been thoroughly
®
tested and has been shipped in perfect operating condition. Carefully
check the shipping carton for damage that may have occurred during
shipping. If the carton appears to be damaged, carefully inspect your
fixture for any damage and be sure all equipment necessary to oper-
ate the unit has arrived intact. In the event damage has been found
or parts are missing, please contact our toll free customer support
number for further instructions. Please do not return this unit to your
dealer without contacting customer support first.
Introduction:
The Event Cylinder RF is an battery powered RGB LED
cylinder. The fixture five operating modes; show mode, sound active
mode, fade mode, manual mode, & static color mode.
Customer Support:
Elation Professionals
tomer support line, to provide help and to answer any question should
you encounter problems during your set up or initial operation. You
may also visit us on the web at www.elationlighting.com for any com-
ments or suggestions. Service Hours are Monday through Friday 8:00
a.m. to 4:30 p.m. Pacific Standard Time.
Voice:
(323) 582-3322
Fax:
(323) 832-9142
E-mail:
support@elationlighting.com
To purchase parts online visit http://parts.elationlighting.com
Warning!
To prevent or reduce the risk of electrical shock or fire, do
not expose this unit to rain or moisture.
Warning!
This may cause severe eye damage. Avoid looking directly
into the light source at all times!
©Elation Pr
fessionals® - www.elationlighting.com - Instruction Manual Page 2
o
General Information
provides a toll free cus-
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Event Cylinder RF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Elation Event Cylinder RF

Summary of Contents for Elation Event Cylinder RF

  • Page 1 Event Cylinder RF General Information Unpacking: Thank you for purchasing the Event Cylinder RF by Ela- tion Professionals . Every Event Cylinder RF has been thoroughly ® tested and has been shipped in perfect operating condition. Carefully check the shipping carton for damage that may have occurred during shipping.

  • Page 2: General Instructions

    • Always be sure to mount this unit in an area that will allow proper ventilation. Allow about 6” (15cm) between this device and a wall. The Event Cylinder RF carries a 2 year (730 days) limited warranty. • Do not attempt to operate this unit, if it becomes damaged.
  • Page 3 Event Cylinder RF System Menu Event Cylinder RF System Menu ShoU - In this mode you can choose 1 of 10 shows to run. Shows can run with or without sound activity. 1. Press the MENU button until “ShoU” is displayed, press ENTER.
  • Page 4 Event Cylinder RF System Menu Event Cylinder RF System Menu 3. When you have found your desired color press ENTER, then 6. Once your desired color and settings are reached press and press and hold the MENU button for at least 3 seconds to acti- hold the MENU button for at least 3 seconds to confirm and vate.
  • Page 5 Event Cylinder RF System Menu Event Cylinder RF System Menu 2. The display will now show the battery status. Press MENU to 3. Press ENTER to confirm. To make the LED display reappear exit. after it has turned off, press any button.
  • Page 6 The RF Controller has many differnet functions and gives you The LED located on the front of the unit lets you know the current complete control of your Event Cylinder RF. To control the your de- status of the battery.

  • Page 7: Troubleshooting

    B. For warranty service, send the product only to the Elation® Professionals® factory. All shipping charges must be pre-paid. If the requested repairs or ser- 1. Use normal glass cleaner and a soft cloth to wipe down the out- vice (including parts replacement) are within the terms of this warranty, Ela- side casing.

  • Page 8: Specifications

    Event Cylinder RF Specifications Model: Event Cylinder RF Voltage: DC 12.6V 3A LEDs: 48 x TRI Color LEDs IP Rating: IP65 Power Consumption: Dimensions: 12”(L) x 12”(H) x 7.25”(D) 304mm x 304mm x 183mm Weight: 7.25 Lbs. / 3.2 kgs.
