Optional Devices

Battery charger

The battery charger provides a convenient way to charge battery packs
without requiring the use of your computer. The battery charger holds up to
two battery packs (lithium ion).

Hard disk drive pack

An extra HDD expands the flexibility of your system and lets you carry your
data without carrying the computer.
Use a point size 0 Phillips screwdriver.

Removing the HDD pack

To remove the HDD pack, follow the steps below.
1. Set the computer to boot mode and turn off the power.
2. Disconnect the AC adaptor and all external cables connected to the
computer.
3. Remove the main battery and optional secondary battery when it is
used.
4. Turn the computer upside down and remove one screw securing the
HDD cover.
5. A small row of ridges mark latches securing the cover. Press on these
ridges until you hear a click.
6. Press on the arrows and lift the cover up and out to remove it.
7. Raise the HDD's plastic tab, pinch it and slide the HDD pack to
disconnect from the connector.
Be sure to slide the HDD pack first and confirm that the HDD pack has
disconnected.
8-14
Screw
Figure 8-15 Removing the HDD pack cover
