Toshiba Tecra M3-S636 Specifications

Tecra M3 Detailed Product Specification
Model Name Description
M3-S636 Microsoft® Windows® XP Professional, Intel Pentium® M Processor 750, 512MB
DDR2, 60GB 5400rpm PATA, CD-RW/DVD-ROM, 14.1" XGA, NVIDIA GeForce™ Go
6200 TE with 64MB DDR, Intel PRO/Wireless 2200BG (802.11b/g), 3 year standard
limited warranty, 1 year standard limited warranty on AC adapter and battery.
2
Operating System
• Microsoft® Windows® XP Professional
3
Processor and Chipset
Intel® Centrino™ Mobile Technology featuring:
• Intel Pentium® M Processor 750
o 1.86GHz, 2MB L2, 533MHz FSB
• Chipset
o Mobile Intel 915GM Express Chipset
• Integrated Wi-Fi™ compliant wireless LAN
o Intel PRO/Wireless 2200BG (802.11b/g)
4
Memory
• Configured with 512MB PC4200 DDR2 533MHz SDRAM (using
one memory module, one memory expansion slot open)
• 512MB(min)/2048MB (max), 2 memory slots using 256MB, 512MB,
or 1024MB PC4200 DDR2 533MHz SDRAM, dual-channel
support requires two memory modules of same capacity and
clockspeed
5
Hard Disk Drive
• 60GB (5400 RPM) Enhanced IDE (ATA-6) hard disk drive; 9.5mm
height; user removable
Slim SelectBay Optical Disk Drive
• CD-RW/DVD-ROM drive maximum speed and compatibility:
o CD-ROM (24x:read), CD-R (24x:write), CD-RW
(10x:write), DVD-ROM (8x:read)
6
Display
• 14.1" diagonal TFT active-matrix LCD display at 1024x768 native
resolution (XGA)
7
Graphics
• NVIDIA GeForce™ Go 6200 TE with 64MB DDR discrete graphics
memory
Sound
• Analog Devices AD1981B 16-bit stereo software sound
o Supports Direct 3D Sound, DirectSound, Direct Music,
MIDI (playback)
• Built-in microphone
• Sound Volume Control Dial
• Built-in stereo speakers
• SRS Labs audio enhancements
o SRS TruSurround XT® virtual surround sound
o SRS WOW™ stereo enhancement
Input Devices
• Keyboard
o 85 key US keyboard
o Hot Key Functions (Fn)
o Windows Key Function
o Application Key Function
1
8
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Tecra M3-S636 BTS Rev. 1.02 2006-01-19 KK T20050810 CB1.50
Part Number
PTM30U-0J0017
• Toshiba Accupoint™ and TouchPad™ dual pointing device
• TouchPad™ Enable/Disable (FN+F9 or by help of software)
• Control Buttons:
o Toshiba Assist button to launch Toshiba Assist control
panel
o Presentation button to quickly connect to projectors
Communications
• Toshiba V.92 software modem
• 10/100/1000 Base-TX Ethernet
• Integrated Intel Pro/Wireless Network Connection 2200BG
10
(802.11b/g)
Expandability
• 2 main memory slots. Both slots may be occupied.
• 1 PC Card slot support 1 Type II, PCMCIA R2.01, PC Card16,
CardBus
• ExpressCard slot supporting ExpressCard/34 and ExpressCard/54
• Secure Digital slot (supports SDIO)
Ports
• RGB (monitor) port
• TV-out (S-Video)
• i.LINK(tm) IEEE-1394
• 2 Universal Serial Bus (USB) ports (v2.0)
• External Microphone jack
• Headphone jack
• RJ-45 LAN port
• RJ-11 modem port
• Parallel port
• Fast Infrared (4Mbps) port For FIR
• 240-pin docking connector
Physical Description for this Product Series
• Dimensions (WxDxH Front/H Rear): 12.7" (314.0mm) x 10.2"
(259.0mm) x 1.24" (31.5mm)[F]/1.37" (34.9mm)[R] without feet
• Weight: Starting at 4.98 lbs (2.26 kg) depending upon
11
configuration
• Indicators: DC-IN, Primary HDD/ODD Access,
Keyboard: Caps Lock, Arrow Mode, Numeric Mode
• Chassis Description
o Case material: PC+ABS Plastic
o LCD Cover Color: Premium Silver
• Physical Security
o Slot for cable lock;
o Items protected by a screw: Memory, Main HDD,
SelectBay Device
• Software Security
o Passwords: User power-on password, supervisor
password
o Hotkey locks: Screen Blank
Power Supply
• 75W (15V x 5A) Auto sensing external AC Adapter, 100-240V / 50-
60Hz frequency (Universal) input.
• Dimensions (WxDxH): 5.00" (127.0mm) x 1.20" (30.5mm) x 2.01"
(51.0mm)
• Weight: starting at 0.78 lbs (355 g)
UPC
032017348295
9
