- Page 1 Instruction Manual Ver 1.0...
- Page 2 Fly high with Hitec This instruction manual is the integrated manual for all three types of the Sky Scout 2Go (R2GO, H2GO, P2GO). It is easy-to-read with...
- Page 3 Fly high with Hitec C2812-1100 Brushless Outrunner Motor (installed) CG-115 DC Balancing Charger (included) C2812-1100 Brushless Outrunner Motor (installed) CG-115 DC Balancing Charger (included) C2812-1100 Brushless Outrunner Motor (installed) safety instructions for its use.
- Page 4 Fly high with Hitec The product contains small and sharp components. with the right polarity. them away from children at is damaged or produces all times. Be careful when using tools produce heat during the winds or storms. The Sky Scout may not perform as desired.
- Page 5 Fly high with Hitec charger.
- Page 6 Fly high with Hitec...
- Page 7 Fly high with Hitec release tailplane clip Carefully slide the Tailplane into the fuselage slot while at the same time Tailplane slot in the rear of the fuselage as shown. Insert the Wing Joiner into one of the wing panels and insert them into the the clip latches into place and that the Tailplane is securely set in place.
- Page 8 Fly high with Hitec follow the instructions in the Hitec 2Go section. their neutral positions. 4. Proceed to using the HPP-22 interface. On the transmitter or module press and hold the link ELEVON Link CH1C H2 CH3C H4 V-TAIL 2.4GHz 4 Channel Aircraft Radio installed in the plane.
- Page 9 Fly high with Hitec to their neutral positions.
- Page 10 Fly high with Hitec guide appears at the end of this manual in from the you. the fuselage to ensure that it is always positioned correctly.
- Page 11 Fly high with Hitec a) Check to make sure the model is in safe operating condition and that there is no damage to the wings or the tail. Check to make sure the model responds correctly to the transmitter inputs.
- Page 12 Fly high with Hitec their neutral position. gliding process. least chance of damage.
- Page 13 Fly high with Hitec do parts 3 and 4. . Allow underside. fuselage shells. Fit the pre-formed aileron pushrods through the second hole from the ailerons (wing panels earlier. cesses and channels, and thread the plain end of the pre-formed aileron pushrods working loose.
- Page 14 Fly high with Hitec following information.
- Page 15 Fly high with Hitec Decal Sheet Wing Joiner TailPlane Clip Set...
- Page 16 Fly high with Hitec Control Horn Set Canopy Latch Set Motor Mount Set Replacement Props Motor Battery Charger...
- Page 17 Fly high with Hitec Allow the glue to set hard, then insert the tailplane slider to ensure that Glue the the parts are accurately aligned. CA glue. Glue the tailplane clip and the tailplane frame in the right-hand fuselage shell...
- Page 18 Fly high with Hitec , and glue them in the upper part of the two fuselage shells and glue it in the underside of the right-hand fuselage shell . Glue the latch catches underside. . Allow in the appropriate openings using CA Glue.
- Page 19 Fly high with Hitec that the transmitter trims are also at the neutral position. Slip the pre-formed steel pushrods which are long. Connect the pre-formed end of the pushrod to the second hole from the channels, running CA glue right along the channel.
- Page 20 Fly high with Hitec into the openings in Fit the three screws to secure the motor cowl Glue the latch tongues in the recesses in the canopy . Glue the cowl screw support at the front end of the motor pod.
- Page 21 Fly high with Hitec We recommend that you apply a drop of medium-strength thread-lock seconds, and then press the horns into its recess. To guarantee a secure seating, the tailplane frame trol surfaces, cutting along the moulded-in end channels only. Repeatedly the recess of the tailplane .
- Page 22 Fly high with Hitec into one of the wing panels as shown in the lead already installed in the fuselage. will now form itself into a loop in the space designed for it. 57010. using the two dowel pins Fit the O-ring through the spinner cone .
- Page 23 Fly high with Hitec...
- Page 24 Fly high with Hitec Operating the speed controller, which follows your control commands from the transmitter. . The aero- wing, and the lift collapses. many a critical situation. upward force (lift) which keeps the aircraft in the air.
- Page 25 Fly high with Hitec settings initially. The rudder (left / right) The throttle (motor off / on) The ailerons (left / right) How this setting works you can read up in the operating instructions supplied with your radio control system.
- Page 26 Fly high with Hitec ELEVON CH1C H2 CH3C H4 Link V-TAIL 2.4GHz 4 Channel Aircraft Radi o ELEVON CH1C H2 CH3C H4 Link V-TAIL 2.4GHz 4 Channel Aircraft Radi o ELEVON CH1C H2 CH3C H4 Link V-TAIL 2.4GHz 4 Channel Aircraft Radi o...
- Page 27 Fly high with Hitec ELEVON CH1C H2 CH3C H4 Link V-TAIL 2.4GHz 4 Channel Aircraft Radi o ELEVON CH1C H2 CH3C H4 Link V-TAIL 2.4GHz 4 Channel Aircraft Radi o ELEVON CH1C H2 CH3C H4 Link V-TAIL 2.4GHz 4 Channel Aircraft Radi o...
- Page 28 Fly high with Hitec ELEVON CH1C H2 CH3C H4 Link V-TAIL 2.4GHz 4 Channel Aircraft Radi o ELEVON CH1C H2 CH3C H4 Link V-TAIL 2.4GHz 4 Channel Aircraft Radi o...
- Page 29 Fly high with Hitec ELEVON CH1C H2 CH3C H4 Link V-TAIL 2.4GHz 4 Channel Aircraft Radi o ELEVON CH1C H2 CH3C H4 Link V-TAIL 2.4GHz 4 Channel Aircraft Radi o ELEVON CH1C H2 CH3C H4 Link V-TAIL 2.4GHz 4 Channel Aircraft Radi o...
- Page 30 Fly high with Hitec ELEVON CH1C H2 CH3C H4 Link V-TAIL 2.4GHz 4 Channel Aircraft Radi o ELEVON CH1C H2 CH3C H4 Link V-TAIL 2.4GHz 4 Channel Aircraft Radi o ELEVON CH1C H2 CH3C H4 Link V-TAIL 2.4GHz 4 Channel Aircraft Radi o...
- Page 31 Fly high with Hitec...
