- Page 1 ELECTRIC HOB UNIT (For fitment to a Post 1974 4 Oven AGA or kitchen worktop) Installation Instructions LEAVE WITH CUSTOMER PLEASE READ THESE INSTRUCTIONS BEFORE INSTALLING THIS APPLIANCE For use in GB and IE 09/10 EINS 511674...
- Page 2 CONTENTS SECTION PAGE INTRODUCTION GENERAL REQUIREMENTS INSTALLATION INTO A WORKTOP INSTALLATION INTO AN EXISTING AGA...
-
Page 3: Rating Plate
The appliance is supplied: To fit directly into the worktop. As a retro-fit kit for a four oven AGA. (To be installed by an AGA Fitter). SUITABILITY For use as a domestic electric hob which may be fitted into a kitchen worktop or into an existing AGA. -
Page 4: General Requirements
The wires in the mains lead on this appliance are coloured in accordance with the following:- Green/Yellow - Earth Blue - Neutral Brown - Live COOKER CONTENTS CHECKLIST AGA PART No. DESCRIPTION QUANTITY Hob unit c/w knobs and 3m silicon cable AE4M240198... - Page 5 FITTING YOUR HOB INTO A WORKTOP Check contents against checklist. Follow instructions carefully. When using power tools always follow the manufacturers safety requirements. STEP 1 Cut hole into the worktop. DESN 511716 STEP 2 Position hob centrally into aperture ensuring seal is in position. View from underneath 10mm 10mm...
- Page 6 FITTING YOUR HOB INTO AN EXISTING AGA Check contents against checklist. Follow instructions carefully. When using power tools always follow the manufacturers safety requirements. STEP 1 Remove the hotcupboard top plate. STEP 2 Decide whether the mains is to enter from the back or side of the hotcupboard.
- Page 7 STEP 4 Electric AGA - Fit one-off insulation blanket JPAD210722 on top of oven roof. Supplied with hob). DESN 511734 STEP 5 Non-Electric AGA’s Only Place blanking plate AG2M210711 (supplied with hob) on top of the oven so that the return is to the left and facing upwards.
- Page 8 STEP 6 Non-Electric AGA’s only - Fit 2 layers of insulation blanket JPAD210722 (supplied with hob) on top of the oven roof. DESN 511733 STEP 7 Feed cable through the grommets. Continue to feed cable as the hob is placed in position.
- Page 12 For further advice or information please contact your local AGA Specialist With AGA’s policy continuous product improvement, the Company reserves the right to change specifications and make modifications to the appliance described at any time. Manufactured by Station Road Ketley Telford...
