Bully Dog Technologies, LLC is a team built on integrity that is dedicated to leading the vehicle performance
industry with an uncompromising code of ethics demonstrated in the soundness of its employees, excellent
customer service and superior products.
UNLEASH THE POWER
WITH BULLY DOG PERFORMANCE PRODUCTS
OutLook Monitor
Intake Systems
Custom OutLook Pod
Exhaust Systems
See More at: bullydog.com
Doc.# BD40502 v1.0.1
For a full listing of Diagnostic Trouble Codes go to: www.bullydog.com/DTC.php
®
For Free Technical Support
Call: 866-bullydog (866-285-5936)

Advertisement

Table of Contents
loading

Related Manuals for Bully Dog Triple Dog Downloader

Summary of Contents for Bully Dog Triple Dog Downloader

  • Page 1 Bully Dog Technologies, LLC is a team built on integrity that is dedicated to leading the vehicle performance industry with an uncompromising code of ethics demonstrated in the soundness of its employees, excellent customer service and superior products. UNLEASH THE POWER...
  • Page 2 INSTALLATION MANuAL TRIPLE DOG DOWNLOADER Vehicle Application Triple Dog Part # ‘03-’05 Dodge 5.9L Cummins 40502 ‘06-’07 Dodge 5.9L Cummins 40502 ‘99-’02 Ford 7.3 L Power Stroke 40502 ‘03-’07 Ford 6.0 L Power Stroke 40502 ‘01-’05 GM 6.6L Duramax 40502 ‘06-’07 GM 6.6L Duramax (not including LMM)

  • Page 3: Table Of Contents

    TABLE OF CONTENTS TROUBLESHOOTING: If you have questions during the installation of this product, please visit www.bullydog.com/Product_Updates.php. The latest version of these instructions can be found at the same location. Please review the Troubleshooting section before calling technical support to cover the most common issues.

  • Page 4: Introduction

    The Triple Dog Downloader, manufactured exclusively by Bully Dog Technologies, is the only downloader on the market that offers on-the-fly tuning. The Triple Dog Downloader will fit the Ford ‘03-’07 6.0L Power Stroke, Ford ‘99-’02 7.3L Power Stroke , ‘01-07 GM 6.6L Duramax (lB7,LLY, LBZ) or ‘03-’07 Dodge 5.9L Cummins diesel pickups all with one single part number.

  • Page 5: Gm Fuses

    GM FuSE LOCATION reMovIng Fuses For ’01-’02 gM durAMAx veHIcLes IMPORTANT: Skip the steps on this page if your vehicle is not an ’01-’02 GM 6.6L Duramax . WARNING: Failure to remove the fuses while downloading the programs into the computer may result in computer hardware failure.

  • Page 6: 05 Gm Duramax Fuse Removal

    GM FuSE LOCATION reMovIng Fuses For ’03-’05 gM durAMAx veHIcLes IMPORTANT: Skip the steps on this page if your vehicle is not an ’03-’05 GM 6.6L Duramax . WARNING: Failure to remove the fuses while downloading the programs into the computer may result in computer hardware failure.After download is complete replace all fuese.

  • Page 7: Triple Dog Installation

    TRIPLE DOG INSTALLATION InstALLAtIon IntroductIon/oBdII port This is a very simple product to operate; all operations take place inside the cab of the vehicle with the down- loader hooked up to the OBDII port. Operating the Triple Dog does not require any mechanical background. Refer to this instruction booklet for general guide- lines through the download process and determining the different features available for your vehicle.

  • Page 8: Navigation/Starting The Downloader

    TRIPLE DOG INSTALLATION nAvIgAtIon/stArtIng tHe doWnLoAder IMPORTANT: The steps on this page are performed on all vehicles. Scroll Right Scroll Left Scroll Up Yes/Enter Scroll Down No/Exit If your vehicle is an ‘01-’05 GM Duramax 6.6L always pull the fuses indicated in the GM fuse IMPORTANT: section of this instruction manual.

  • Page 9: Main Menu Options

    TRIPLE DOG INSTALLATION MAIn Menu optIons IMPORTANT: The information on this page is applicable to all vehicles. NOTE: The Dodge ‘03-’07 5.9L Cummins will have a main menu item that reads “Other Functions,” rather than “Read DTCs.” To read and erase DTCs on the Dodge Cummins enter the Other Functions menu and select Read DTCs. INSTALL DOWNLOAD Select this option to download the on-the-fly programming.

  • Page 10: Install Download, Selecting The Correct Vehicle

    TRIPLE DOG INSTALLATION InstALL doWnLoAd IMPORTANT: The information on this page is applicable to all vehicles. In these steps you will begin the downloading process.Select the “Install Download” option from the main menu and follow the screen prompts. SELECT VEHICLE To select the correct vehicle the correct files must first be loaded to the downloader, so it may ap- pear as though vehicles have to be selected twice.

  • Page 11: L Ford Power Stroke Features

    Adding a different sized tire than the stock OEM tire size will cause the speedometer to read incorrect speeds. The Triple Dog Downloader can calibrate the OEM speedometer to read correctly for any tire size from stock up to 37” in...
  • Page 12 TRIPLE DOG INSTALLATION TRANSMISSION TUNING This feature is controllable only within the on-the-fly menu, after the on-the-fly programming has been down- loaded. The downloader offers 3 different transmission tuning options to facilitate added horsepower and to make the driving experience more enjoyable. The descriptions below offer our recommendations of use with each of the three different options.

  • Page 13: L Gm Duramax Features

    TRIPLE DOG INSTALLATION gM 6.6L durAMAx veHIcLe specIFIc FeAtures IMPORTANT: The information on this page is only applicable to GM 6.6L Duramax vehicles. Skip this page if your vehicle is not a ’02-’07 6.6L Duramax LB7, LLY, and LBZ. (Not available for ‘01 Duramax Model) SPEED LIMITER The Triple Dog gives racing enthusiasts the option to remove the OEM speed limiter.

  • Page 14: L Dodge Cummins Features

    This feature is another adopted for racing enthusiasts. This will enable the vehicle to reach crankshaft revolutions up to 4100 per minute. This feature is only available if Crazy Larry has been downloaded from the Bully Dog Website, because this feature is a racing only application.
  • Page 15 IMPORTANT: The information on this page is only applicable to Dodge 5.9L Cummins vehicles. LOW END POWER: (AUTOMATIC TRANSMISSION ONLY) This feature will improve low-end throttle response over Standard Bully Dog Tuning. dodge 5.9L cuMMIns otHer FunctIons Menu IMPORTANT: The information on this page is only applicable to Dodge 5.9L Cummins vehicles.
  • Page 16 Adding a different sized tire than the stock OEM tire size will cause the speedometer to read incorrect speeds. The Triple Dog Downloader can calibrate the OEM speedometer to read correctly for any tire size from stock up to 37” in increments of .25”.
  • Page 17 TRIPLE DOG INSTALLATION dodge 5.9L cuMMIns veHIcLe optIons IMPORTANT: The information on this page is only applicable to Dodge 5.9L Cummins vehicles. IDLE UP This feature is only available for vehicles with an automatic transmission. When enabled this feature will increase the vehicle idle RPM using the cruise control button system to facilitate vehicle warm-up under cold weather conditions.
  • Page 18 TRIPLE DOG INSTALLATION FOG LAMP Enabling this feature will allow the fog lights and high beams to operate at the same time. This feature is for Off-road use only. HORN CHIRP ON LOCk Enabling this feature will sound a horn chirp each time the doors are locked when using a remote door lock system.

  • Page 19: Operating Functions

    OPERATING FuNCTIONS AdJustIng poWer on tHe FLY IMPORTANT: The information on this page is applicable to all vehicles. Note: selecting the stock power level in the on the fly screen does not return the vehicle to factory stock; this will only instruct the vehicle to operate at a stock power level. To return to stock the program must be removed from the vehicle through the download process.

  • Page 20: Other Functions

    OPERATING FuNCTIONS otHer FunctIons IMPORTANT: The information on this page is applicable to all vehicles. USING THE OUTLOOk MONITOR: (USING THE OUTLOOk MONITOR IN COMBINATION) 1. If you already have an Outlook Monitor installed on your pickup, you will need to remove the plug from the OBDII port to download a power program.

  • Page 21: Internet Updates

    Triple Dog. On many vehicle models there is an option to replace the Extreme setting on the Triple Dog with a Crazy Larry setting. Bully Dog offers the Crazy Larry setting upgrade as well as the new vehicle additions for free. Simply visit Bully Dog’s web site www.bullydog.com/download_center.

  • Page 22: Transmission Relearns

    4. At full throttle get up into 5th gear. Once you are in 5th gear, apply light pressure to the brake pedal until the truck is stopped. 5. Go through the same process with the Tow Haul button on and enjoy your Triple Dog downloader. Ford 6.0L poWerstroke AutoMAtIc torque sHIFt trAnsMIssIon 1.

  • Page 23: Troubleshooting

    Try unplugging the downloader and try again. If problem Checksum error during initial Installation continues, go to Bully Dog website and get latest upgrades install and try again. No, only the 6 position chip works on the earlier model of...

  • Page 24: Warranty & Disclaimer

    Never exceed recommended vehicle or tire top speed ratings. DISCLAIMER OF LIABILITY Bully Dog Technologies, LLC. Its distributors, jobbers, and dealers (hereafter Seller) shall be in no way responsible for the product’s proper use and service. THE BUYER HERBY WAIVES ALL LIABILITY CLAIMS.
