- Page 1 GT Platinum Part #40417 Not legal for sale or use in California on pollution-controlled vehicles. Doc. 40417-99 v1.0...
-
Page 2: Table Of Contents
CONTENTS Updating the GT ..........23- 30 Overview ................23-24 FAQs about Updating ..................23 Basic Steps to Update (Short Version) ............24 What You Need to Update the GT ...............24 Updating your GT (Detailed Steps for Windows) ....25-28 Troubleshooting Updating Problems ........29 Updating Your GT (Detailed Steps for Apple/Mac) ....30 Physical Installation ..........31-34 Brief Preview ................31 Detailed Instructions ............32-33... -
Page 3: About The Gt
2. Physically install the GT Platinum. 3. Install the tune to your vehicle. IMPORTANT NOTE: You MUST uninstall your Bully Dog engine tune before taking your vehicle in for ANY type of service. Check the GT Platinum product page at www.bullydog.com to check for new applications. -
Page 4: Vehicle Applications
MANUAL OVERVIEW This product is a combination of previous gas tuners sold by Bully Dog. To make a more expedient product for our dealers and a more efficient product for end users, we have combined all previous gas tuners into one amazing unit. Since particular tuners support a wider feature set but are for the most part the same in operation, make sure that as you go through this instruction manual, you READ CAREFULLY the sections that are intended for you when directed to do so. -
Page 5: Parts List
PARTS LIST Your GT Platinum package should include the following items: 1. The GT Platinum Head Unit 5. Fuse Tap Part Number: 40415-1 6. Fuse Spade 2. OBDII Adapter Plug Part Number: 40400-105 7. Micro SD Card Part Number: 40410-10 8. -
Page 6: Parts Description
PARTS DESCRIPTION GT Platinum Head Unit The main component of the Gauge Tuner is the head unit. It has the screen and the buttons that allow you to access all of the functions and features of the tuner. GT Platinum Front Side: The GT Platinum has seven capacitive touch buttons. -
Page 7: Parts Description
5. HDMI Port: Connects the OBDII adapter plug to the GT Platinum Head Unit. 6. Pyrometer/Sensor Docking Station Port: Connects the GT Platinum to optional sensors including pyrometers or the Bully Dog Sensor Docking Station. -
Page 8: Button Navigation
BUTTON NAVIGATION 1: Press the top left button to enter the Main Menu, also use this button to exit menus. FUNCTION Wasted Energy Menu Dec. Acc. Coolant Average M PG Gallons Grade 17 11.8 Intake Economy 0. 0 ® Press any of the four buttons on the FUNCTION 2: Use these buttons to scroll up and FUNCTION 5:... -
Page 9: The Main Screen
THE MAIN SCREEN This picture of the GT Platinum main screen has the Driving Coach selected for the Large Gauge option. You can change which gauge is featured in the upper right corner of the main screen by holding down one of the buttons on the left side of the GT Platinum until the gauge type that you want is shown. -
Page 10: Available Options - All Models
4. When you are done, use the top left button to go back to the Main Menu and General Display. NOTE: All of the gauge types may not be available through your vehicle’s diagnostic port (OBDII port). This fact is out of the control of Bully Dog; however, Bully... -
Page 11: Gauge Setup
This option shows a real-time reading of the timing position as com. Bully Dog and factory OEM sensors are the only pyrometers the truck is running. which will work with the GT Platinum. If pyro 1 & 2 are unavailable through the OEM, go through the Sensor Docking This option displays information from the Mass Airflow Sensor. - Page 12 0-5kHz 5V pulse range. The port on the Bully AUX 1, 2 & 3 Dog Sensor Docking Station for this gauge option is marked as FN. This gauge option shows the information from sensors connected to the 0-5V auxiliary inputs on the Bully Dog Sensor Docking Station.
-
Page 13: User Options
This feature offers drag racers the ability to complete the 1/4 Mile and 0-100 KPH performance tests. You can also download saved tests from your GT Platinum to your computer and analyze it using the Bully Dog Performance Testing Software. The software is available by free download from www.bullydog.com. -
Page 14: Driving Coach Setup
Driving Coach Setup The Driving Coach is a special feature designed to be your fuel economy dashboard and information center. It provides real-time visual and audio feedback about driving efficiency and where energy is being lost. The driving coach will help you understand the optimal conditions for your particular vehicle through real-time observation, giving you the power to maximize your vehicle’... - Page 15 Next: Go to a safe place with little to no traffic where you can perform a speed test. Make sure the speed limit is at least 60 mph. Here are two different ways to find out your vehicle’s actual speed: Method 1: GPS 1. Use a GPS device to compare your actual speed and the speed displayed on the Bully Dog. 2. Calculate the Percent Difference by using this formula:...
-
Page 16: Driving Coach Setup
Driving Coach Setup (continued) Checking Average Fuel Economy It is important to check the accuracy of the average economy readout on the GT Platinum at least once every changing season. There are many reasons to check and adjust the average fuel economy, here is one example: The fuel delivered to gas stations during the winter contains an average of 1.3% less energy than the fuel delivered in warmer seasons. -
Page 17: Vehicle Settings
Engine Coolant Temp Level Transmission Temperature Turn this setting off or add a Bully Dog boost sensor if your vehicle does not have a factory transmission temperature sensor. Adjust Economy Display Change the miles per gallon shown by the GT Platinum. - Page 18 Special Functions (available for some Toyota® vehicles only) Display and Lighting vehicle grade) and sunroof close if the driver window control is held closed. If the driver door window control is held open, the driver's Display Ex Off door window (and all the windows, depending on vehicle grade) This changes the brightness when canceling the lights for the and the sunroof will open.
- Page 19 Special Functions (available for some Toyota® vehicles only) Power Back Door Wireless PBD Operation This function changes the operation of the PBD by transmitter. PBD Buzzer This function will adjust the volume of the buzzer while the PBD operates. Security Entry Delay This will change the Entry Delay Time, or the period before starting the warning, by the Passive Mode.
- Page 20 Special Functions (for some Jeep®, Dodge® and Chrysler® vehicles only) Engine Fan Turn the engine fan off for water crossings or run it in high speed mode at any temp. NOTE: The coolant temperature light will not indicate if the vehicle begins to overheat when the fan is disabled. Idle Adjust Set the engine speed (in RPMs) to increase the voltage and provide additional power to the winch.
- Page 21 Special Functions (for some Jeep®, Dodge® and Chrysler® vehicles only) Traction Control Completely disable the vehicle’s Traction Control by choosing Disable. • After re-enabling traction control (reverting back to stock settings) the dash light may stay lit until the key is cycled. Tire Size Correct the speedometer (and fuel efficiency calculations) if you have changed your tire size from stock.
- Page 22 Special Functions (for Hemi engines only) The same special functions are not available for all vehicles. You can check out which features are available for your model by visiting the Bully Dog website. Tire Pressure Limit Headlights W/Wipers Change or disable the Tire Pressure Monitoring System (TPMS).
-
Page 23: Diagnostics
A new GT Platinum is covered for one year after the date of purchase. This warranty covers repairs for factory defects; it does not cover accidental damage or reset services. For pricing information and assistance in having a damaged GT Platinum unit repaired, contact technical support. You can find more specific warranty information at the following page on the Bully Dog website: http://www.bullydog.com/warranty.php... -
Page 24: Updating The Gt
This often immediately fixes the problem! 3. Bully Dog engineers are constantly working to expand the features and vehicles that the GT Platinum is able to support. Once a new vehicle or option is unlocked, they make sure it is available to everyone by including it in the updated software version. -
Page 25: Basic Steps To Update (Short Version)
UPDATING THE GT PLATINUM Basic Steps to Update (Short Version) 1. Run the Update Agent. 2. Connect the Micro SD card to your computer. 3. Choose the vehicle application and let the Agent search. 4. Click the Update button. 5. When the Update is finished, put the Micro SD card in the GT Platinum. 6. -
Page 26: Updating Your Gt (Detailed Steps For Windows)
• If it is already installed, skip to step 5. You can see if it is already installed by checking your Start Menu under All Programs. The Update Agent will be listed under the Bully Dog Technologies folder: Windows XP... - Page 27 UPDATING THE GT PLATINUM (DETAILED STEPS FOR WINDOWS) The following instructions are intended for Microsoft Windows computers. 4. You can download the installation file at http://www.bullydog.com/update_agent.php • Save the file first, then run it. (If you try to run the file without saving, your computer will generate an error message). •...
- Page 28 - Or you can stop the previous instance of the Update Agent and open a new one – either option is a winner. • If you have already installed the application in the past, it should be listed under Bully Dog Technologies in your computer’s list of All Programs. Just double-click the Update Agent icon in that folder to let it start.
- Page 29 UPDATING THE GT PLATINUM (DETAILED STEPS FOR WINDOWS) 8. NOTE: This step varies depending on how you have connected the Bully Dog to your computer. • If you have the Micro SD card connected to the computer: - Disconnect it from the computer and put it in the GT Platinum.
-
Page 30: Troubleshooting Updating Problems
TROUBLESHOOTING UPDATING PROBLEMS The Update Agent Won’t Install Why does my computer open a window full of weird symbols when I try to install the Update Agent? Your computer is not up to date and you need to run Windows Update first. -
Page 31: Updating Your Gt (Detailed Steps For Apple/Mac)
• Connect the GT Platinumwith the Micro SD card installed by using a USB cable. Do not use the HDMI cable to update the GT Platinum. 4. Go to the Bully Dog website and click on the link for Update Agent. -
Page 32: Physical Installation
PHYSICAL INSTALLATION Be sure to check the list and description of included parts in the "Parts List" section of this manual. Brief Preview This is a quick list of the basic installation steps. You can find more specific information about each step in the next section. 1. -
Page 33: Detailed Instructions
PHYSICAL INSTALLATION Detailed Instructions 1. Connect The OBDII Adapter Plug to the OBDII Port. • Find the OBDII port in your vehicle. As shown in the illustration, the specific location of the port can vary between different vehicles, but it is always somewhere under the driver’s side dash. -
Page 34: Using The Universal Windshield Mount
PHYSICAL INSTALLATION Detailed Instructions (Continued) 3. Run the HDMI cable under the dash. This step helps you install the HDMI cable in a way that is discreet, stylish, and that helps to protect the GT Platinum 1. Plug one end of the HDMI cable into the port on the OBDII adapter plug. 2. -
Page 35: Additional Gt Mounting Options
ADDITIONAL MOUNTING OPTIONS Bully Dog has created alternative mounting solutions which will allow you to mount your GT Platinum in even more convenient locations. RAM Mirror-Mate Part Numbers: 31600 and 33600 The RAM Mirror-Mate mounting kit will allow you to mount your GT Platinum directly beneath your rearview mirror. -
Page 36: Installing The Tune
You might need to connect to a computer to get special files from technical support if you encounter problems during the install. Do NOT install if you do not have a way to contact technical support. DO make sure that you can contact Bully Dog technical support. Technical support is open Monday-Friday, 8 a.m. – 5 p.m., Mountain Standard Time. -
Page 37: Important Preparation Steps
Make SURE the Tuner is Ready DO complete an online update with the Bully Dog Update Agent. This is a free application available on the Bully Dog website. - Page 38 DO make sure that you can contact Bully Dog technical support. Technical support is open Monday-Friday, 8 a.m. – 5 p.m., Moun- It is a good idea to have a battery charger ready to connect to your tain Standard Time.
- Page 39 Removing Fuses (GMC/Chevrolet® vehicles only) This step is vital for successful installation on some vehicles, but not required on others. The following pages include information about which fuses need to be pulled to allow the GT Platinum to install the tune to the engine computer on specific vehicles. If the fuses are not pulled, the tune will most likely freeze during the install process.
-
Page 40: How To Install The Tune
INSTALLING THE TUNE (GENERAL INSTRUCTIONS) Toyota®, Jeep® and Hemi engine vehicles requires slightly different Preparation Steps, continue to the appropriate section to find these preparation steps. 1. Complete the Pre-install steps • Update GT Platinum using Update Agent. • Physical Installation -pages. •... -
Page 41: Troubleshooting Installation Problems
Troubleshooting Installation Problems Error During Installation 1. Make note of the code number and all information displayed on the screen. 2. Disconnect and update your GT Platinum. 3. Make sure that you have disconnected all aftermarket electronics and completed all of the important preparation steps. 4. - Page 42 INSTALLING THE TUNE (TOYOTA VEHICLES) IMPORTANT NOTE: Steps 1-9 must be completed with/inside the vehicle. 1. Turn the key to the “on” (or “run”) position. 5. Read the disclaimer and press AGREE. a. Do NOT start the engine. DISCLAIMER Are you the owner of this vehicle? Have you read the disclaimer, and do you agree to all of its terms and conditions?
- Page 43 INSTALL THE TUNE (TOYOTA VEHICLES) 8. Read the battery charger screen, press MORE and press CON- 11. If the tuning screen below appears, skip to 22. Otherwise NECTED when the charger is connected. continue to 12. TUNING BATTERY CHARGER Please make sure you connect Tune X has been Set.
- Page 44 Unplug your GT Platinum. Steps 16-18 must be completed outside the will ask you to Con rm the tuning options selected. vehicle on a computer with Internet access. press MORE 16. Open the Bully Dog Update Agent on your PC. (see step C-1).
- Page 45 INSTALL THE TUNE 23. Select the tune you would like to install and press ENTER. 25. Check battery and connect charger if needed. If output is ≤12V, install will not continue until at least 12.1V is available. press TUNE ENTER BATTERY LEVEL Select Power Level Battery Level must be above...
- Page 46 Troubleshooting Installation Problems (Toyota® vehicles) Error During Installation 1. DO NOT TOUCH THE KEY UNLESS DISPLAY SCREEN SAYS TO. 2. Make note of the code number and all information displayed on the screen. 3. Disconnect and update your GT Platinum. 4.
- Page 47 INSTALL THE TUNE (HEMI ENGINE VEHICLES) Overview 1. Physically install the GT Platinum. 2. Prepare to install the tune. 3. Slide the adapter plug switch to BATT. 4. Turn the key to the “run” (or “on”) position. 5. Choose Install Download from the Main Menu. 6.
- Page 48 INSTALL THE TUNE (HEMI ENGINE VEHICLES) 6. Verify that the correct vehicle type is selected and then press YES. CAUTION Go Back to Main Menu Please verify vehicle type. Installing on a XXXX-XXXX Chrysler/Dodge/Jeep If this is correct press Y to continue. If not, restart and select the correct vehicle.
- Page 49 Steps 13-15 must be completed outside the vehicle on a computer with Internet access. 13. Open the Bully Dog Update Agent. 14. Connect the microSD memory card to the computer. a. Use the included card reader and a USB port on the computer.
- Page 50 INSTALL THE TUNE (HEMI ENGINE VEHICLES) A. Power Level ◦ Choose the option that matches the type of fuel in the gas tank. ◦ Premium: 91+ octane; up to 35 lbs. additional peak POWER LEVEL ENTER horsepower and up to 40 additional peak torque Select Power Level ◦...
- Page 51 INSTALL THE TUNE (HEMI ENGINE VEHICLES) F. Tire Size ◦ Set the tire size; correct the vehicle speedometer if you have changed your tire size from stock. TIRE SIZE TIRE SIZE ENTER Do you want to adjust tire size? Set Tire Size By using the Press YES to select your own Up and down Arrows...
- Page 52 INSTALL THE TUNE (HEMI ENGINE VEHICLES) ‣ Turn the key to “off” and press Continue.The GT Platinum will display countdown timers. Follow instructions on the screen. PLEASE WAIT Please Wait..Seconds 20. The GT Platinum will complete the download. ‣ Press Continue and wait for the GT Platinum to reboot. The installation is complete! DOWNLOAD FINISHED Continue...
- Page 53 INSTALLING THE TUNE (JEEP® VEHICLES) 1. Turn the key to the “on” (or “run”) position. ‣ Do NOT start the engine. 2. Choose Change Vehicle from the Main Menu. MAIN MENU Go Back to General Disp Change Vehicle Install Download Gauge Setup Set User Options 3.
- Page 54 INSTALL THE TUNE (JEEP VEHICLES) 5. Verify the vehicle type. ‣ Press YES to continue. CAUTION Go Back to Main Menu Please verify vehicle type. Installing on a XXXXXXXXXXXXXXXXXX If this is correct, press Y to continue. If not, restart and select the correct vehicle.
- Page 55 10. Remove the microSD memory card from the GT Platinum. Steps 11-13 must be completed outside the vehicle on a computer with Internet access. 11. Open the Bully Dog Update Agent app. ‣ www.BullyDog.com/updateagent.php 12. Connect the microSD memory card to the computer.
- Page 56 INSTALL THE TUNE (JEEP VEHICLES) 15. Choose Install Download from the Main Menu. 16. Read the disclaimer and press AGREE. 17. Read the battery disclaimer and press CONTINUE. 18. The GT Platinum will begin the initial download. ‣ This will take several minutes. ‣...
- Page 57 INSTALL THE TUNE (JEEP VEHICLES) 21. The GT Platinum will prompt you to specify the following tuning features: ‣ Power Level ‣ Adjust WOT Shift Points (if available, automatic ‣ Drive Rev. Limiter transmissions only) ‣ Neutral Rev. Limiter ‣ Tire Size ‣...
- Page 58 INSTALL THE TUNE (JEEP VEHICLES) Troubleshooting Installation Problems Error During Installation 1. Make note of the code number and all information displayed on the screen. 2. Disconnect and update your GT Platinum. 3. Make sure that you have disconnected all aftermarket electronics and completed all of the important preparation steps. 4.
-
Page 59: Uninstalling - Returning To Stock
UNINSTALLING - RETURNING TO STOCK What does this mean? “Uninstalling the Tune” and “Returning to Stock” are different ways to describe the same thing: writing the original (stock) information to the engine computer so it uses the settings that it used before you installed your GT Platinum. Doing this also sends a signal to the GT Platinum to let it know that it is no longer installed on a vehicle, which will allow you to install the tune at a later time. -
Page 60: How To Return To Stock
How to Return to Stock There are two ways to return your vehicle to stock. IMPORTANT NOTE: Both methods are very similar to installing the tune to your vehicle, so you should make the same preparations and take the same precautions. This means choosing a good time and place, making sure the battery is charged, pulling fuses (if necessary), disconnecting aftermarket electronics, etc. -
Page 61: What If I Don't Return To Stock
UNINSTALLING - RETURNING TO STOCK What if I Don’t Return to Stock? Here are some common examples: • If you take your vehicle in for service, they will “flash” the engine computer. Even if you ask them not to, any dealer or shop will do this automatically –... - Page 62 DATA LOGGING FEATURE (TOYOTA® VEHICLES) -Log parameters for 180 second period -Results are saved on SD Card -Data Logging Software can be downloaded from bullydog.com -Data can be played back for the period recorded...
-
Page 63: More Information
MORE INFORMATION Changing the Power Level The power level tunes on the GT gas are based on the octane of the fuel being run in the vehicle. Unlike the GT diesel, this option cannot be changed On The Fly (OTF), because it is impossible to change the type of fuel being used while you are driving. There are some times when this setting does need to be changed, like when filling the tank with a different octane than previously used before. -
Page 64: Pyrometer Calibration
MORE INFORMATION Pyrometer Calibration What is Pyrometer Calibration? Pyro calibration is a way to find the best temperature to use for the GT Platinum temperature warning setting for your vehicle. This will help you prevent heat damage to your engine. How to Calibrate Your Pyrometer 1. -
Page 65: Faqs/Troubleshooting
FAQS/TROUBLESHOOTING My GT Platinum Won’t Turn Off I have turned my vehicle off and removed the key – everything else has turned off. Why won’t my GT Platinum turn off? The power switch on the OBDII adapter plug is in the “wrong” position. If you want the GT Platinum to turn on and off along with the rest of your vehicle, you will need to make sure that the power switch is in the “correct”... - Page 66 My Vehicle isn’t Listed under Change Vehicle Why isn’t my vehicle included in the list under the Change Vehicle option? Chevrolet owners should choose the GMC option that matches the year of their vehicle. If your vehicle is very new or very old, you may need to update (see page 23) or your vehicle may not be supported yet.
-
Page 67: Contacting Technical Support
CONTACTING TECHNICAL SUPPORT Technical Support is open Monday-Friday, 8 a.m. – 5 p.m., Mountain Standard Time. The phone number to contact technical support is (940)783-9915. You should have all of the following items available when contacting technical support: • Your GT Platinum tuner •...
