Techno Line WS-9032 Instruction Manual

WEATHER STATION
Instruction Manual
INTRODUCTION:
Congratulations on purchasing this state-of-the-art weather station as an example of innovative
design and quality piece of engineering. Providing radio controlled time, date, calendar, Moon
phase, indoor and outdoor temperature, indoor and outdoor relative humidity, and air pressure
history information. This unit will never keep you guessing on current and future weather conditions.
Operation of this product is simple and straightforward. By reading this operating manual, the user
will receive a better understanding of the Weather Station together with the optimum benefit of all its
features.
FEATURES:
The Weather Station
LCD Display
Function keys
DCF Radio controlled time with manual setting option
Time reception ON/OFF (user selectable)
12/24 hour time display
Time zone option ±12 hours
Weekday and day calendar display (year and month only in setting mode)
Alarm setting with snooze function
Display 12 Moon phases throughout the year
Weather forecasting with weather tendency indicator
Indoor comfort indicator
Temperature display in ºC/ºF
Indoor and outdoor temperature display with MIN/MAX records and time of reception
Humidity data display as RH%
Indoor and outdoor humidity display with MIN/MAX records
Relative air pressure hPa/ inHg with adjustable reference value
Weather icon sensitivity setting
Relative air pressure history for the past
pressure trend)
LCD contrast selectable
Hanging hole
Battery
compartment
Stand
24 hours (electronic barometer with barometric
Can receive up to 3 outdoor transmitters
LED back light
Low battery indicator
Table standing or wall mounting
The Outdoor Thermo-Hygro Transmitter
TO INSTALL AND REPLACE BATTERIES IN THE WEATHER STATION
The Weather Station uses 3 x AA, IEC LR6, 1.5V batteries. To
install and replace the batteries, please follow the steps below:
1. Insert finger or other solid object in the space at the bottom
center of the battery compartment and lift up to remove the
cover.
2. Insert batteries observing the correct polarity (see
marking).
3. Replace compartment cover.
TO INSTALL AND REPLACE BATTERIES IN THE THERMO-HYGRO
TRANSMITTER
The Thermo-hygro transmitter uses 2 x AA, IEC LR6, 1.5V batteries. To install
and replace the batteries, please follow the steps below:
1. Remove the battery cover.
2. Insert the batteries, observing the correct polarity (see marking).
3. Replace the battery cover on the unit.
Note:
In the event of changing batteries in any of the units, all units need to be reset by following the
setting up procedures. This is because a random security code is assigned by the transmitter at
start-up and this code must be received and stored by the Weather station in the first 3 minutes of
power being supplied to it.
BATTERY CHANGE:
It is recommended to replace the batteries in all units on an annual basis to ensure optimum
accuracy of these units.
Please participate in the preservation of the environment. Return used batteries to
an authorized depot.
SETTING UP
1. First, insert the batteries into the Weather station (see "How to install and replace batteries
in the Weather station" above). Once the batteries are in place, all segments of the LCD will
light up briefly and a short signal tone will sound.
Remote transmission of outdoor temperature
and humidity to weather station by 433MHz
signals
Shower proof casing
Wall mounting case
Then the indoor temperature and humidity,
