FIGURE 2: VLSCS INSTALLATION INSTRUCTIONS
Bend tabs down to
locate bridge in
ceiling tile
cutout.
Ther V-9914M-5 is recommended for use where extra speaker support is needed.
may be added for backbox protection. A V-9916M (bridge/backbox combination) is also available.
2
V-9915M-5 Backbox
V-9914M-5 Bridge
Attach backbox to
bridge with 4 screws
provided
Cut 8.5" round
hole in ceiling tile
8" Ceiling Grille
and Speaker
(4 white screws
provided)
A V-9915M-5
