Page 1: Quick Start Guide
P-2602HWUDL-D 802.11g Wireless ADSL VoIP IAD with Built-in DECT Base Station Quick Start Guide Version 3.40 8/2007 Edition 1 DEFAULT LOGIN IP Address http://192.168.1.1 Password 1234 Copyright © 2007. All rights reserved. - Page 2 2.0 ports for sharing files via USB compatible storage devices and one phone port for making calls over the Internet (Voice over IP or VoIP). The P-2602HWUDL-D can use regular phone services through regular (PSTN) phone lines and can also function as a print server.
-
Page 3: Hardware Connections
P-2602HWUDL-D Quick Start Guide To read the User’s Guide insert the CD that came in the box into your CD-ROM drive. A screen should pop up. Navigate to the User’s Guide from this screen. If a screen does not pop up, open Windows Explorer (click My Computer), click on the CD-ROM drive (usually drive D:) and navigate to it from there. - Page 4 Look at the LEDs (lights) on the top panel of the P-2602HWUDL-D. • The POWER light blinks during start-up and is green once the P-2602HWUDL-D is ready. • Each ETHERNET light turns on if the corresponding ETHERNET port is properly con- nected.
-
Page 5: Dect Phone Registration
1 Press down the DECT base station button ( ) on the left side (when facing the LEDs (lights)) of your P-2602HWUDL-D for 6 to 11 seconds. When the DECT light begins to blink, the P-2602HWUDL-D is in registration mode. The P-2602HWUDL-D in registration mode for 25 to 30 seconds. - Page 6 2 Put your DECT phone in registration mode. Refer to your DECT phone documentation. When the P-2602HWUDL-D is in registration mode, the DECT light blinks and the P- 2602HWUDL-D starts to scan its surrounding area for DECT phones in registration mode.
-
Page 7: Initial Configuration
P-2602HWUDL-D Quick Start Guide Once your DECT phones are registered with the P-2602HWUDL-D you can assign SIP accounts to make and receive VoIP calls. You can also use DECT phones to make internal calls, see your DECT phone documentation for more information. Internal calls are calls between DECT phones registered with the P-2602HWUDL-D. - Page 8 P-2602HWUDL-D and your wireless computer(s) must all use the same SSID (network name), channel and security settings. If you do not set wireless security, any one within range could use your P-2602HWUDL-D to access your network and the Internet. Make sure your wireless security settings are compatible with your existing wireless devices.
-
Page 9: Setting Up A Wireless Network
Alternatively, use OTIST, ZyXEL’s One-Touch Intelligent Security Technology (OTIST) feature. It allows you to automatically configure the SSID and WPA-PSK on all OTIST- equipped wireless clients within range of the P-2602HWUDL-D. See the wireless LAN chapter in the User’s Guide for more information on OTIST. -
Page 10: Make Phone Calls
5 Regular Phone Line Setup When one of your VoIP accounts is registered, the P-2602HWUDL-D normally uses the Internet (not the regular phone line) to make phone calls. Follow the directions in this section to make sure you can also use the regular phone line while one of your VoIP accounts is registered. -
Page 11: Voip Trunking Overview
VoIP links which PSTN (Public Switched Telephone Network) callers can use to: • Make phone calls via the Internet - Make a PSTN call to the P-2602HWUDL-D and it for- wards the call to any SIP based VoIP phone. In the example below, we call the P- 2602HWUDL-D (B) from a regular phone (A), the P-2602HWUDL-D then forwards the call to a VoIP phone (C). -
Page 12: Usb File Sharing
P-2602HWUDL-D Quick Start Guide example of a VoIP trunking call. A calls the P-2602HWUDL-D (B), B makes a VoIP connec- tion to another VoIP trunking device C and C forwards the call to a PSTN phone D. See the User’s Guide for information on how to configure VoIP trunking. - Page 13 4 Select Active in the User Configuration Setting section and fill in the User Name and Password fields. Retype your password and click Apply. The P-2602HWUDL-D automatically recognizes the USB device which is connected to the USB port and makes it available for sharing.
-
Page 14: Troubleshooting
2 Make sure your computer is on the same subnet as the P-2602HWUDL-D. The P- 2602HWUDL-D is set up by default to assign an IP address to your computer. If you have a static IP address on your computer change this setting to obtain an IP address automatically. - Page 15 P-2602HWUDL-D Quick Start Guide If you can access the Internet, but you cannot make calls through the Internet, follow these steps. 1 Check the PHONE lights. If neither of them is on, Make sure that your telephone is connected to the corresponding PHONE port.
