P-2612HNU(L)-FxF
802.11n ADSL2+ VoIP IAD
Firmware V3.10
Edition 1, 9/2010
DEFAULT LOGIN DETAILS
IP Address:
User Login:
Administrator
Login:
www.zyxel.com
http://192.168.1.1
User Name: user
Password: 1234
User Name: admin
Password: 1234
Copyright 2010
ZyXEL Communications Corporation

Advertisement

Table of Contents
loading

Related Manuals for ZyXEL Communications P-2612HNU(L)-FxF

Summary of Contents for ZyXEL Communications P-2612HNU(L)-FxF

  • Page 1 P-2612HNU(L)-FxF 802.11n ADSL2+ VoIP IAD Firmware V3.10 Edition 1, 9/2010 DEFAULT LOGIN DETAILS IP Address: http://192.168.1.1 User Login: User Name: user Password: 1234 Administrator User Name: admin Login: Password: 1234 Copyright 2010 ZyXEL Communications Corporation www.zyxel.com...
  • Page 2 Device Panels INTERNET POWER WLAN WLAN PHONE 1, 2 ETHERNET BUTTON LEDS LINE POWER PORT PORT RESET ON/OFF ETHERNET PHONE PORT PORTS PORT PORTS PORT...
  • Page 3 USB 2.0 ports: they can be used for sharing files via a USB compatible storage device and 3G connection by inserting a 3G wireless adapter. There are also two phone ports for making calls over the Internet (Voice over IP or VoIP). The P-2612HNU(L)-FxF can also function as a print server. Requirements Make sure you have the following things before you start.

  • Page 4: Hardware Connections

    • 3G account - if you want to access the Internet through a 3G network. The P-2612HNU(L)-FxF uses this 3G connection as your WAN or a backup when the DSL/Ethernet WAN connection fails. • Internet Explorer 6.0 and later versions, with JavaScript enabled, or Mozilla Firefox 3 and later versions or Safari 2.0 and later versions.
  • Page 5 3. USB 2.0: There are two USB ports on your P-2612HNU(L)-FxF, one is at the back panel and one is one the side panel. You can do the following: a.
  • Page 6 7. Push the power button to the on position. Look at the LEDs (lights) on the top panel of the P-2612HNU(L)-FxF. • The POWER light blinks during start-up and is green once the P- 2612HNU(L)-FxF is ready.

  • Page 7: Set Up A Wireless Network

    Network Setting > Broadband screen to set up the WAN connection.  If you want to have the P-2612HNU(L)-FxF use 3G as your WAN or as a backup when the Ethernet WAN connection fails, see your User’s Guide for how to use the Network Setting >...
  • Page 8 PIN (Personal Identification Number) into the configuration screen of the P-2612HNU(L)-FxF. See Configuration on page 9. You must use the same method on the P-2612HNU(L)-FxF and the wireless client. Push Button Configuration 1. Place a WPS-enabled device that is installed in your system and supports the WPS Push Button method within range of the P- 2612HNU(L)-FxF.
  • Page 9 2. Press the WLAN button on the P-2612HNU(L)-FxF’s top panel for five seconds. 3. Use the WPS-enabled device’s WPS button. It can be either a button in the utility or a physical button. See the device’s documentation if you cannot locate the WPS button. It doesn’t matter which button is pressed first.
  • Page 10 Register in the P-2612HNU(L)-FxF web configurator screen. 7. The P-2612HNU(L)-FxF and the other WPS-enabled device establish a secure connection. This can take up to two minutes. 8. Congratulations! Your computer is now ready to connect to the...
  • Page 11 1. Right-click the wireless adapter icon which appears in the bottom right of your computer monitor. Click View Available Wireless Networks. 2. Select the P-2612HNU(L)-FxF’s SSID name and click Connect (A). The SSID “SecureWirelessNetwork” is given here as an example.
  • Page 12 Congratulations! Your computer is now ready to connect to the Internet wirelessly through your P-2612HNU(L)-FxF.  If you cannot connect wirelessly to the P-2612HNU(L)-FxF, check you have selected the correct SSID and entered the correct security key. If that does not work, ensure your wireless network adapter is enabled by clicking on the wireless adapter icon and clicking Enable.

  • Page 13: Make Phone Calls

    • For call forward service, contact your service provider to know if they support this feature. • To receive a call through the P-2612HNU(L)-FxF, the other party must have your SIP number and a SIP account of their own. The Web Configurator 1.

  • Page 14: Usb File Sharing

    • Connect your USB 2.0 file sharing device to an USB port of the P- 2612HNU(L)-FxF (See Hardware Connections). The USB device is automatically recognized by the P-2612HNU(L)-FxF and available for sharing. • Enable the file sharing feature. • Browse to your files using the IP address of the P-2612HNU(L)-...
  • Page 15 Browse to the USB File Share 1. In Windows Explorer’s Address bar type a double backslash “\\” followed by the IP address of the P-2612HNU(L)-FxF (192.168.1.1 is the default) and hit [ENTER]. The files on the USB file sharing device connected to the P- 2612HNU(L)-FxF are now part of your file structure and you can manage those files just like any other files on your computer.
  • Page 16 Viewing a Product’s Certifications 1. Go to www.zyxel.com. 2. Select your product from the drop-down list box on the ZyXEL home page to go to that product's page. 3. Select the certification you wish to view from this page. This device has been designed for the WLAN 2.4 GHz and 5 GHz networks throughout the EC region and Switzerland, with restrictions in France.
