- Page 1 NV70*35 Series NV66*35 Series Built-In Oven user manual This manual is made with 100 % recycled paper. imagine the possibilities Thank you for purchasing this Samsung product. GEO Plus_NV70H3583LS_EU_DG68-00553A-00_EN.indb 1 2014-03-24 6:03:12...
-
Page 2: Table Of Contents
contents USING THIS MANUAL 03 Using this manual SAFETY INSTRUCTIONS 07 Bulb exchange 08 Door removal 08 Door glass removal 09 Auto energy saving function 09 Correct disposal of this product (Waste electrical & Electronic equipment) INSTALLATION 09 Installation OVEN CONTROLS 11 Oven controls ACCESSORIES 11 Accessories... -
Page 3: Using This Manual
Thank you for choosing SAMSUNG Built - In Oven. This user Manual contains important information on safety and instructions intended to assist you in the operation and maintenance of your appliance. Please take the time to read this Owner’s Manual before using your oven and keep this book for future reference. - Page 4 Appliance should allow to disconnection of the appliance from the supply after installation. The disconnection may be achieved by having the plug accessible or by incorporating a switch in the fixed wiring in accordance with the wiring rules. During use the appliance becomes hot. Care should be taken to avoid touching heating elements inside the oven.
- Page 5 Repairs should be performed by a licensed technician only. Improper repair may result in considerable danger to you and others. If your oven needs repair, contact a SAMSUNG Service Centre or your dealer. Electrical leads and cables should not be allowed to touch the oven.
- Page 6 When the cartridge is cracked or broken, do not use it and contact your nearest service center. (Steam function model only) This oven has been designed only for the cooking of household foods. During use, the oven interior surfaces become hot enough to cause burns. Do not touch heating elements or interior surfaces of the oven until they have had time to cool.
-
Page 7: Bulb Exchange
• Disconnect the oven from the mains. • Protect the oven light bulb and the glass cap by laying a cloth on the bottom of the oven compartment. • Bulbs can be purchased from the SAMSUNG Service Centre. Rear oven light 1. -
Page 8: Door Removal
DOOR REMOVAL For normal use, the oven door must not be removed but if removal is necessary, for example, for cleaning purposes, follow these instructions. CAUTION: The oven door is heavy. 1. Open the door and flip 2. Close the door by 3. -
Page 9: Auto Energy Saving Function
If the oven is connected to the mains with a plug, this plug must remain accessible after the oven is installed. Samsung will take no responsibility for accidents that originate from a missing or faulty earth connection. - Page 10 With built-in furniture, plastic surfaces and adhesive for the oven should be resistant to 90 °C inside of the furniture and to 75 °C for adjacent furniture. Samsung will take no responsibility for damage of plastic surfaces or adhesive from the heat.
-
Page 11: Oven Controls
oven controls 1. Cooking Function Select Dial 2. Window Display 3. Time / Temp Control Dial 4. Clock Button 5. Kitchen Timer Button 6. Cook Time Button 7. End Time Button 8. Auto Cook Button 9. Lamp Button 10. Child Lock Button The Cooking Function Select Dial and the Time / Temp Control Dial are pop - up dial. -
Page 12: Before You Begin
before you begin SETTING THE CLOCK 1. Press the Clock button. The “ ” and “12: ” will blink. 2. Turn the Time / Temp Control Dial to set the hour of the day. Example: To set 1:30 3. Press the Clock button. The “... -
Page 13: Initial Cleaning
INITIAL CLEANING Clean the oven thoroughly before using for the first time. Do not use sharp or abrasive cleaning materials. These could damage the oven surface. For ovens with enamel fronts, use commercially available cleaning agents. To clean the oven 1. -
Page 14: Oven Use
oven use SETTING THE COOKING FUNCTION MODE Turn the Cooking Function Select Dial to select the desired oven function. Oven Modes The following table represents the various oven modes and settings of your oven. Use the cooking guide tables for these modes in the following pages as guidelines for cooking. -
Page 15: Setting The Oven Temperature
Mode Description Bottom Heat + Convection The bottom heating element and back wall heating element provide hot air which is circulated by the fans. This mode is ideal for baking food such as quiches, pizza, bread and cheesecakes. Auto Menu Programmes You can select 25 auto menu programmes for baking, roasting and cooking. -
Page 16: End Time
END TIME You can set the end time during cooking. 1. Press the End Time button. Example: Current time is 12:00 2. Turn the Time / Temp Control Dial to set the desired end time. 3. Press the End Time button. The oven operates with the selected end time automatically unless the End Time button is pressed within 5 seconds. -
Page 17: Delayed Start
DELAYED START Case 1 - Cook time is entered first If the end time is entered after the cook time has already been set, the cook time and the end time are calculated and if necessary the oven sets a delayed start point. 1. -
Page 18: Kitchen Timer
KITCHEN TIMER 1. Press the Kitchen Timer button once. “ ” flashes. 2. Turn the Time / Temp Control Dial to set the desired time. Example: 5 minutes 3. Press the Kitchen Timer button to start the kitchen timer. When the set time has elapsed, an audible signal sounds. -
Page 19: Auto Cook
AUTO COOK 1. Turn the Cooking Function Dial to Auto Cook. 2. Press Auto Cook Button. A-1 ~ A-4 B-1 ~ B-4, C-1 ~ C-4 D-1 ~ D-3, E-1 ~ E-3 F-1 ~ F-7 3. Select the desired recipe by turning the Time/Temp control dial to the right and left. -
Page 20: Oven Lamp On / Off
When it reaches the time for “Turn Over/Around” It beeps to inform the time for “Turn Over/Turn Around”. After “Turn Over/ Turn Around”, stop cooking and wait until Cook Time button is pressed. 6. Press Cook Time button. It stops beeping, and the cooking restarts. -
Page 21: Switching The Beeper Off
SWITCHING THE BEEPER OFF 1. To turn the beeper off, press the Clock and End Time buttons at the same time and hold for 3 seconds. 2. To turn beeper back on, press the Clock and End Time buttons again at the some time and hold for 3 seconds. -
Page 22: Oven Functions
OVEN FUNCTIONS The features of this oven include the following functions. 1. Conventional Suggested temperature: 200 °C The conventional function is ideal for baking and roasting foods arranged on one rack. Both the top and bottom heating elements operate to maintain the oven temperature. - Page 23 2. Top Heat + Convection Suggested temperature: 190 °C The top heating element is in operation and the fan operates to constantly circulate the hot air. We recommend to preheat the oven with Top Heat + Convection mode. Shelf Temperature Time Food Item Accessory...
- Page 24 3. Convection Suggested temperature: 170 °C This function bakes foods placed on up to three shelves and is also appropriate for roasting. Cooking is achieved by the heating element on the rear wall and the fan distributes the heat. We recommend to preheat the oven in convection mode. Shelf Temperature Time...
- Page 25 4. Large Grill Suggested temperature: 240 °C The large grill function grills large quantities of flat foods, such as steaks, schnitzels and fish. It is also suitable for toasting. Both the top heating element and the grill are on in this mode. We recommend to preheat the oven using Large Grill mode.
- Page 26 5. Small Grill Suggested temperature: 240 °C This setting is for grilling smaller amounts of flat foods, such as steaks, schnitzels, fish and toast, placed in the middle of the tray. Only the top element is in operation. We recommend to preheat the oven using Small Grill mode. Put food in the centre of accessory.
- Page 27 6. Bottom Heat + Convection Suggested temperature: 190 °C The Bottom Heat + Convection mode is for recipes calling for a moist topping and a crisp base, as with foods like pizzas, quiches lorraine, German-style open fruit cakes and cheesecakes. We recommend to preheat the oven in Bottom Heat + Convection mode.
- Page 28 7. Auto Menu Programmes The following table presents 25 Auto Programmes for Cooking, Roasting and Baking. It contains its quantities, weight ranges and appropriate recommendations. Cooking Modes and times have been pre-programmed for your convenience. You can refer to these guide lines for cooking. Always insert food in cold oven.
- Page 29 Food Item Weight/kg Accessory Shelf Level 1. 0.5-0.7 Wire grill Chicken Pieces 2. 1.0-1.2 Deep pan Brush chicken pieces with oil and spices. Put chicken pieces side by side on the wire grill. Roast 1. 0.8-1.0 Wire grill Chicken 2. 1.1-1.3 Deep pan Brush chilled chicken with oil and spices and put breast-side-up on the wire grill.
- Page 30 Food Item Weight/kg Accessory Shelf Level 1. 0.4-0.6 Vegetable Gratin Wire grill 2. 0.8-1.0 Prepare vegetable gratin using an ovenproof round dish. Put dish on wire grill in the centre of oven. 1. 0.5-0.6 Marble Cake 2. 0.7-0.8 Wire grill 3.
-
Page 31: Test Dishes
TEST DISHES According to standard EN 60350 1. Baking The recommendations for baking refer to preheated oven. Type of Shelf Cooking Temp. Cooking Dish & Notes Food level Mode (°C) time (min.) Baking tray Conventional 170-190 15-25 Small Cakes Deep pan + Baking tray 1 + 4 Convection 150-170... -
Page 32: Cleaning And Care
cleaning and care CATALYTIC ENAMEL SURFACE (OPTIONAL) The removable cover casing is coated with a dark gray catalytic enamel this can become coated with oil and fat distributed by circulating air during convection heating. These deposits will burn off at oven temperatures of 200 °C and above. 1. -
Page 33: Detaching The Side Runners (Optional)
DETACHING THE SIDE RUNNERS (OPTIONAL) 1. Press central part of 2. Rotate the side runner 3. Pull and remove the the side runner top by approximately 45 º. side runner from portion. bottom two holes. CLEANING THE CEILING (OPTIONAL) 1. You can let down the grill heater to help when cleaning the ceiling of the oven. -
Page 34: Troubleshooting
INFORMATION CODES All information codes are not from the fault of the oven. Please refer to below solution first, if the information codes still occur, please call your local SAMSUNG Customer Care Centre. CODE PROBLEM SOLUTION Safety Shutoff Turn oven off and remove food. - Page 35 Mobilfunk max. 0,60 €/Anruf) ITALIA 800-SAMSUNG (800.7267864) www.samsung.com/it/support CYPRUS 8009 4000 only from landline, toll free www.samsung.com/gr/support 80111-SAMSUNG (80111 726 7864) only from land line GREECE (+30) 210 6897691 from mobile and land line LUXEMBURG 261 03 710 www.samsung.com/support NETHERLANDS 0900-SAMSUNG (0900-7267864) (€...
