3366XP / 4366XP
POWER SWEEPER
For American-Lincoln MODELS 579-546, 579-547, 579-548, 579-549, 579-550, 579-551
579-546CE, 579-548CE, 579-550CE, 579-551CE

Instructions for Use

READ THIS BOOK
This book has important information for the use and safe operation of this machine. Failure to read this book prior to operating or attempt-
ing any service or maintenance procedure to your machine could result in injury to you or to other personnel; damage to the machine or to
other property could occur as well. You must have training in the operation of this machine before using it.
All directions given in this book are as seen from the operator's position at the rear of the machine.
Revised 1/07
English
Form Number 56041668

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3366XP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for American-Lincoln 3366XP

Summary of Contents for American-Lincoln 3366XP

  • Page 1: Table Of Contents Revised

    3366XP / 4366XP POWER SWEEPER For American-Lincoln MODELS 579-546, 579-547, 579-548, 579-549, 579-550, 579-551 579-546CE, 579-548CE, 579-550CE, 579-551CE Instructions for Use READ THIS BOOK This book has important information for the use and safe operation of this machine. Failure to read this book prior to operating or attempt- ing any service or maintenance procedure to your machine could result in injury to you or to other personnel;...

  • Page 2: Table Of Contents

    POST-OPERATION CHECK LIST .......................... 15 TO EMPTY DEBRIS HOPPER ..........................15 TOWING INSTRUCTIONS ............................16 DUST FILTERS ..............................16 DUST CONTROL SYSTEM ............................. 16 GENERAL MACHINE MAINTENANCE ........................17-21 TECHNICAL SPECIFICATIONS ............................. 22 2 - FORM NO. 56041668 American-Lincoln Technology 3366XP / 4366XP...

  • Page 3: Introduction

    INTRODUCTION This manual will help you get the most from your Nilfi sk-Alto™ 3366XP / 4366XP. Read it thoroughly before operating the machine. References to “right” and “left” in this manual mean right or left as seen from the driver’s seat.

  • Page 4: Cautions And Warnings

    Turn the key switch off (O) before changing the brushes, and before opening any access panels. • Take precautions to prevent hair, jewelry, or loose clothing from becoming caught in moving parts. SAVE THESE INSTRUCTIONS 4 - FORM NO. 56041668 American-Lincoln Technology 3366XP / 4366XP...

  • Page 5: Consignes De Prudence Et De Sécurite

    Prenez toutes les mesures nécessaires pour éviter que les cheveux, les bijoux ou les vêtements amples ne soient entraînés dans les parties mobiles de la machine. CONSERVEZ SOIGNEUSEMENT CES INSTRUCTIONS American-Lincoln Technology FORM NO. 56041668 - 5 3366XP / 4366XP...

  • Page 6: Operation Of Controls And Gauges

    When the key is in the accessory position the gauge will register approx. 12 volts. The meter will indicate approximately 13 to 14.5 volts when the engine is running. This indicates that the alternator is working correctly. 6 - FORM NO. 56041668 American-Lincoln Technology 3366XP / 4366XP...

  • Page 7: Broom & Fan Switch

    Fluid level must be visible in the sight glass when the hopper is in the down position. If the sight glass is completely full, then there is too much fl uid in the reservoir. HYDRAULIC SIGHT GLASS P4696a FIGURE 3 American-Lincoln Technology FORM NO. 56041668 - 7 3366XP / 4366XP...

  • Page 8: Right Side Broom Lift And Power Control

    The wet-sweep bypass switch is located to the right of the steering wheel under the shaker motor switch. The switch activated will shut off the vacuum motor. This will keep the dust fi lters from being ruined by the water pickup from sweeping water. 8 - FORM NO. 56041668 American-Lincoln Technology 3366XP / 4366XP...

  • Page 9: Turn Signals - 4 Way (Option)

    SEAT ADJUSTMENT (See Figure 2) This lever is located on the right of the seat. This lever allows the seat to be adjusted forward or back when the lever is moved. American-Lincoln Technology FORM NO. 56041668 - 9 3366XP / 4366XP...

  • Page 10: Parking Brake

    When a further attempt is made to start the engine, keep the glow plugs energized while starting and for a few seconds after the engine has fi red until it is running smoothly. 10 - FORM NO. 56041668 American-Lincoln Technology 3366XP / 4366XP...

  • Page 11: Hopper Lift/Side Broom Lever

    Diesel 2150 THROTTLE ENGINE SWITCH LIGHT SYMBOL (1 speed level) THROTTLE SYMBOL THROTTLE SYMBOL SWEEPER Gas/LP 1st 2050 2450 (2 speed levels) Diesel 2150 2550 FIGURE 10 FIGURE 10a P4688ecp American-Lincoln Technology FORM NO. 56041668 - 11 3366XP / 4366XP...

  • Page 12: Check Engine Light

    This engine is equipped with a low oil pressure shutdown. If the engine oil pressure drops too low, the engine will shut down. Add engine oil until the oil is brought up to the correct level. 12 - FORM NO. 56041668 American-Lincoln Technology 3366XP / 4366XP...

  • Page 13: Operating Instructions

    Depress the foot brake. Turn Broom Fan Switch off. Put the broom controls (Side and Main) in the “UP” position. Push engine throttle down. Turn key to “OFF.” Set parking brake. American-Lincoln Technology FORM NO. 56041668 - 13 3366XP / 4366XP...
  • Page 14 Always allow the machine to warm up before operating in cold temperatures. Periodically turn sweeping (main) broom end for end to prevent the bristles from “setting” in one direction. NOTE Replace sweeping broom when bristles are worn to 3-inch (8-cm.) length. 14 - FORM NO. 56041668 American-Lincoln Technology 3366XP / 4366XP...

  • Page 15: Post-Operation Check List

    Pull the hopper rotation and dump lever to the “RETURN” position and the hopper will automatically rotate and lower to its proper position. WARNING! Never turn off the engine with the hopper in the lifted position. American-Lincoln Technology FORM NO. 56041668 - 15 3366XP / 4366XP...

  • Page 16: Towing Instructions

    fi lter shaker switch should be pushed to start the dust shaker cycle. This will extend the life of the fi lter. NOTE The main broom and impellor fan will shut off automatically when the shaker motor is cycling. P4695 FIGURE 13 16 - FORM NO. 56041668 American-Lincoln Technology 3366XP / 4366XP...

  • Page 17: General Machine Maintenance

    These bearings are located inside the broom doors. The carriage bolts on the two end fl anges will have to be loosened. The frame can then be leveled and the bolts tightened. American-Lincoln Technology FORM NO. 56041668 - 17 3366XP / 4366XP...
  • Page 18 fl aps are adjustable and should be maintained even with the fl oor. The rear fl ap must be maintained 1/16” (16 cm.) above the fl oor. All fl aps should be replaced when worn or damaged to such an extent that they cannot perform their normal function. 18 - FORM NO. 56041668 American-Lincoln Technology 3366XP / 4366XP...
  • Page 19 fi tting. Lubricate all other moving joints of the machine with #10 oil. Lubricate the clamp ends of the throttle cable with NAPA #765-1363 or equivalent anti-seize lubricant. American-Lincoln Technology FORM NO. 56041668 - 19 3366XP / 4366XP...
  • Page 20 GENERAL MACHINE MAINTENANCE 1,7,19 4,13,29 3,36,37,38 16,35 16,35 C0260 20 - FORM NO. 56041668 American-Lincoln Technology 3366XP / 4366XP...

  • Page 21: General Machine Maintenance

    Perform recommended engine maintenance (See engine manual) EVERY 500 HOURS 36. Clean hydraulic reservoir 37. Clean hydraulic intake strainer 38. Change hydraulic fl uid Perform recommended engine maintenance (See engine manual) American-Lincoln Technology FORM NO. 56041668 - 21 3366XP / 4366XP...

  • Page 22: Technical Specifications

    0.93 m/s 0.93 m/s Vibrations at the Seat (EN 1032) 0.54 m/s 0.54 m/s Gradeability 21% (11.8°) 21% (11.8°) Model 3366XP LD Petrol 3366XP VD Petrol 3366XP LD Diesel 3366XP VD Diesel Model No. 579-548CE 579-546CE 579-551CE 579-550CE Sound Pressure Level (ISO 11201) dB (A) 92.3...
  • Page 23 Modell/ Modèle/ Model/ Malli/ Modelo/ Μοντέλο/ Modelo/ Modelis/Модель: Floor Treatment Machines Type/ Tyyppi/ Tipo/ Τύπος/ Tüüp/ Tipas/ Tips/ Typ/ Típus/ Тип/ Tip: 6150, MVP60, 3366XP, 5730B, 7730B, 7750, 7760. Der Unterzeichner bestätigt hiermit dass die oben erwähnten Modelle gemäß den folgenden Richtlinien und Normen hergestellt wurden.
  • Page 24 14600 21 Avenue North Plymouth, MN 55447-3408 www.americanlincoln.com Phone: 800-331-7692 Fax: 877-877-2586 ©2007 American-Lincoln...
