American-Lincoln
Operator's Manual
Beginning with Serial No. 692003
READ THIS BOOK
This book has important information for the use and safe operation of this machine. Failure
to read this book prior to operating or attempting any service or maintenance procedure to
your machine could result in injury to you or to other personnel. Damage to the machine or to
other property could occur as well. You must have training in the operation of this machine
before using it. If you or your operator (s) cannot read English, have this manual explained
fully before attempting to operate this machine.
All directions given in this book are as seen from the operator's position at the rear of the machine.
For new books, write to:
Part No. 2-86-00321
AMERICAN-LINCOLN
SMART
American-Lincoln, 1100 Haskins Road, Bowling Green, Ohio 43402
2003
American-Lincoln®
®
SMART
Sweeper/Scrubber
ISO 9001
U L
®
#
FILE A2287
Printed in the
USA
1-1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for American-Lincoln SMART Sweeper/Scrubber 692003
Summary of Contents for American-Lincoln SMART Sweeper/Scrubber 692003
- Page 1 American-Lincoln Operator's Manual Beginning with Serial No. 692003 READ THIS BOOK This book has important information for the use and safe operation of this machine. Failure to read this book prior to operating or attempting any service or maintenance procedure to your machine could result in injury to you or to other personnel.
- Page 2 NOTES AMERICAN-LINCOLN SMART...
-
Page 3: Table Of Contents
CONTROLS 20-32 DECIMAL - METRIC CONVERSION TABLE 5 DISCLAIMER 4 HARDWARE ABREVIATIONS 6 HYDRAULIC TORQUE REQUIREMENTS 8 MACHINE PREPARATION 17, 18, 19 MAINTENANCE 44-58 OPERATING INSTRUCTIONS 33-43 ORDERING PARTS 10 SAFETY PRECAUTIONS 11, 12 SPECIFICATIONS 14, 15, 16 STANDARD HARDWARE & TORQUE VALUES 7 SYMBOLS 9 TROUBLESHOOTING 59, 60 AMERICAN-LINCOLN... -
Page 4: Disclaimer
DISCLAIMER DISCLAIMER The information contained in this manual is believed correct at the time of publication. American Lincoln assumes no responsibility or liability for unauthorized changes made to this manual or pages removed, causing indirect or consequential damages resulting from the use of the information appearing herein. WARNING! In the event that machinery or controls described herein are modified in any way, or in the event that such machinery or controls are not maintained in a proper manner, the instructional material contained herein may... -
Page 5: Decimal - Metric Conversion Table
DECIMAL - METRIC CONVERSION TABLE DECIMAL DECIMAL FRACTION MILLIMETER FRACTION MILLIMETER C-2001/9907 AMERICAN-LINCOLN SMART... -
Page 6: Hardware Abreviations
HARDWARE ABREVIATIONS ADJ.SP CAPT.SL CAPT.WG FIL.HM HIHD HSHC HSFHC MHHC SHTB WELD ABBREVIATIONS-SCREWS = Adjusting Screw = Adjusting Plunger Screw = Binding Head Machine Screw = Button Head Socket Screw = Captivated Slotted Screw = Captivated Wing Screw = Flat Head Machine Screw = Filister Head Machine Screw = Hexagon Head Cap Screw = Hexagon Head Machine Screw... -
Page 7: Standard Hardware & Torque Values
SAE - Grade 5 Grade Screw Size Plated *1/4 5/16 7/16 9/16 C = Coarse Thread F = Fine Thread * = Torque values for #6 through 1/4 are lb./in. All others are lb./ft. Decrease the torque by 20% when using thread lubricant The torque tolerance is ±... -
Page 8: Hydraulic Torque Requirements
HYDRAULIC TORQUE REQUIREMENTS HYDRAULIC TORQUE REQUIREMENTS Refer to the following chart for torque values on all hydraulic hoses & fittings Nominal O-Ring Face Seal End Thread Dash Size Size Inch 9/16-18 11/16-16 13/16-16 1-14 1 3/16-12 1 3/16-12 1 7/16-12 1 11/16-12 2-12 -Ring face-seal-type end not defined for this tube size... -
Page 9: Symbols
THESE SYMBOLS IDENTIFY CONTROLS, DISPLAYS/FEATURES, AND SAFETY SYMBOLS ON THE MACHINE. Battery Charger Choke Fan On Filter Shaker On Forward/Reverse Headlights Hopper Dump Hopper Return Horn Main Broom & Side Broom Up Main Broom & Side Broom Down No Step Power Recovery Tank High Scrub Brush Down &... -
Page 10: Ordering Parts
ORDERING PARTS Parts may be ordered from ALTO distributors: INTERNET http://www.alto-online.com ALTO HEADQUARTERS Incentive International A/S Kongens Nytorv 28 P.O. Box 2064 1013 Copenhagen K Tel.: +45 72 18 10 00 Fax: +45 72 18 11 64 E-mail: incentive@incentive-dk.com AUSTRIA ALTO Osterreich GmbH Metzgerstr. -
Page 11: Safety Precautions
The following safety labels are mounted on the machine in the locations indicated. If the labels become damaged or illegible replace with identical label. Dust Control Motor presents hazard for shearing and cutting AMERICAN-LINCOLN SMART SAFETY PRECAUTIONS ELECTRICAL HAZARD - Shocks can cause serious personal injury Disconnect battery before working in this area... -
Page 12: Safety Precautions
SAFETY PRECAUTIONS Signal words (DANGER, WARNING and CAUTION) are used to identify levels of hazard seriousness. The degree of severity is based on the likely consequences of human interaction with the hazard. To warn of immediate hazards which will result in severe personal injury or death. To warn of hazard or unsafe practices which could result in severe personal injury. - Page 13 Be careful when operating the machine on a ramp or incline. Do not operate machine on incline greater than 8° or longer than 100’. Always move slowly on a ramp. Do not turn this machine on a ramp. Do not stop and leave this machine on a ramp. Always stop the machine on a level surface, put the power switch in the on position.
-
Page 14: Specifications
SPECIFICATIONS CLEANING PATH Scrubbing Sweeping Edge Cleaning TRANSPORT SPEED OPERATING SPEED POWER SUPPLY For machine to operate properly, voltage reading should fall within 32-40 vdc. Guaranteed power sound level: L (Operator) Sound Pressure Level = 84.8 CHARGER STEERING TURNING RADIUS Left Right Aisle “U”... -
Page 15: Warranty
INSTRUMENTS AND CONTROLS Main/Side Broom Switch Headlight/Taillight Switch (option) Squeegee Switch 3 Position Scrub Deck Switch Horn Button Solution Control Knob Hopper Up/Down Switch Hopper Open Light SCRUBBING SYSTEM Brush Size-46” (116.84 cm) Brush Size-40” (101.4 cm) Brush Lift Scrub Pressure SQUEEGEE Rear Side... -
Page 16: Specifications
SPECIFICATIONS MACHINE DATA MODEL WEIGHT 1-16 MACHINE NAME DATE / SERIAL NUMBER RATED POWER IP X3 MAX OPERATING SLOPE AMERICAN-LINCOLN SMART... -
Page 17: Machine Preparation
Your SMART battery machine has been shipped complete, but do not attempt to operate without reading the following instructions: UNPACKING AND ASSEMBLING MACHINE The SMART is shipped on a pallet and held in place with wooden block to stop the machine from moving. 1) Remove wooden blocks holding machine in place. - Page 18 MACHINE PREPARATION 3) Push machine down the ramp onto a flat surface. 4) Install battery. -Turn the key to the “O” position -Lift the hood up and pull the battery lever up to the right. -Use a battery lifting device with a 2000 LB. (907KG) capacity to place the battery into the battery tray. -Push battery lever down to the left to lock the battery into place.
-
Page 19: Battery Installation
BATTERY LEVER Fig 5 Fig 7 BATTERY INSTALLATION 1. Lift the machine front cover. 2. Rotate the battery lever to the right. 3. Lower the battery into place using a 2000 LB. (907 KG) capacity lifting device. 4. Rotate the battery lever to the left to lock the battery into place. 5. -
Page 20: Controls
CONTROLS 7 8 9 10 High recovery light. Low solution light Hopper open light. Light switch. ESP switch. Spray Vac Wand switch. Scrub brush switch. Squeegee switch. Main side broom switch. Filter shaker/Dust control switch. Hopper switch. Battery condition meter/Hour meter. Circuit breakers. -
Page 21: Key Switch
KEY SWITCH The keyed ignition switch is located on the ioperator’s console as shown in figure 10. The “OFF” position (O position) will shut off the machine. The IGN/ON position (I position) provides power to all machine systems and accessories. FORWARD / REVERSE SWITCH The forward/reverse switch is located on the operator’s console as shown in figure 11. -
Page 22: Battery Condition Meter
CONTROLS BATTERY CONDITION METER The battery condition meter is located on the instrument panel as shown in figure 12. The condition meter indicates the level of charge in the batteries. The batteries are sufficiently charged when all of the LED’s are illuminated amber as shown on the ramp illustration. - Page 23 HEADLIGHT/TAILIGHT SWITCH (Optional) The light switch is located on the instrument panel as shown in figure 14. By pressing on the lower half of the switch the headlights and taillights will be activated. Pressing the upper half of the switch will turn off the lights. HOPPER OPEN LIGHT WARNING The hopper open light switch is located on the instrument panel as shown in figure 15.
-
Page 24: Dust Control Switch
CONTROLS FILTER SHAKER SWITCH (Only models with dust control) The filter shaker switch is located on the instrument panel as shown in figure 16. By pressing and holding in the upper half of the switch, it will activate the filter shaker motors for 20 to 30 seconds. Releasing the switch, returns to the off position. -
Page 25: Scrub Brush Switch
SCRUB BRUSH SWITCH The scrub brush switch is located on the left of the instrument panel as shown in figure 18. Pressing the top half of the switch raises the scrub deck and turns off the brushes. The middle switch position lowers the brushes to the normal down position for scrubbing. - Page 26 CONTROLS LOW SOLUTION LIGHT Figure 20 LOW SOLUTION LIGHT The low solution warning light is located on the instrument panel as shown in figure 20. The low solution warning light illuminates when the solution tank is empty, marking the end of the scrubbing cycle. HIGH RECOVERY LIGHT Figure 21 HIGH RECOVERY LIGHT...
-
Page 27: Hopper Lift Switch
HOPPER LIFT SWITCH The hopper lift switch is located on the instrument panel as shown in figure 22. The switch controls the operation of the hopper lift system. To raise the hopper for dumping, press and hold the lower half of the switch until the hopper reaches the desired height, then release. - Page 28 CONTROLS SPRAY AND VAC WAND SWITCH (Optional) The spray and vac wand switch is located on the instrument panel as shown in figure 24. Pressing the bottom half of switch turns on the vacuum motor and the solution pump. Pressing the top half of the switch turns the vacuum motor and solution pump off.
-
Page 29: Side Broom Adjustment
SIDE BROOM ADJUSTMENT KNOB SIDE BROOM ADJUSTMENT The side broom adjustment knob for changing the sweep height to compensate for broom wear, is located in front of the machine to the right of the dust control filter as shown in figure 26. Turning the knob to the left (counterclockwise) will lower the side broom. -
Page 30: Solution Flow Knob
CONTROLS SOLUTION FLOW KNOB The solution flow knob is located on the instrument panel as shown in figure 28. Turning the knob clockwise will increase the flow of solution and water. The farther the solution control knob is turned the heavier the flow of water and solution will be. -
Page 31: Foot Throttle
FOOT THROTTLE The foot throttle is located to the right of the brake pedal on the floor of the operator’s compartment as shown in figure 30. This pedal controls the machine travel speed. Press the forward/reverse switch to chose the travel direction, and then press down on the foot throttle to move set the machine in motion. -
Page 32: Controls
CONTROLS SEAT ADJUSTMENT LEVER Figure 34 SEAT POSITION ADJUSTMENT The seat position adjustment lever is located on the front of the seat to the left as seen in figure 34. The lever is spring loaded to the lock position. To adjust the seat, push the lever to the left and move the seat to the desired position and then release the lever to lock the seat into place. -
Page 33: Operating Instructions
Before starting the engine, perform the pre-start checklist.Before starting the engine, perform the pre-start PRE-START CHECKLIST Check hydraulic fluid level. Check all systems for leaks. Check brakes and controls for proper operation. Check broom patterns. Check hydraulic fluid level. Check hydraulic connections for leaks. Check brakes and controls for proper operation. -
Page 34: To Start Machine
OPERATING INSTRUCTIONS TO START MACHINE Turn key to “I” position. TO TRANSPORT MACHINE 1. Make sure the brushes and squeegees are in the up or raised position with all other controls in the off position. 2. Release the parking brake. 3. - Page 35 TO BEGIN THE CLEANING OPERATION 1. Select the operating mode NORMAL = ESP 2. Lower brushes to the desired position. SCRUB DECK = NORMAL RANGE OR HEAVY 3. Place the squeegee switch in the lower position. SQUEEGEE BLADE = LOWER 4.
- Page 36 OPERATING INSTRUCTIONS SOLUTION TANK STRAINER SOLUTION SOLUTION CONTROL CONTROL VALVE VALVE SCRUB BRUSH THE NON-RECYCLING OR STANDARD SCRUBBING MODE During the scrubbing process, detergent solution water from the solution tank is fed to the solution line. There it is fed to the floor where three disc scrubbing brushes work to dislodge soil. After scrubbing, the dirty solution is vacuumed from the floor and discharged into the containment chamber in the forward portion of the recovery tank, where a system of baffles helps to clarify the solution.
- Page 37 SOLUTION TANK STRAINER SOLUTION CONTROL VALVE SCRUB BRUSH ESP OPERATING MODE During the scrubbing process, filtered water from the solution tank is fed to the solution line, where it combines with detergent. This mixture is then fed to the floor where two or three disc scrubbing brushes work to dislodge soil.
-
Page 38: To Stop The Cleaning Operation
OPERATING INSTRUCTIONS P4134/0001 SCRUBBING PATH · Scrub in straight paths. Do not bump posts. Do not scrape the sides of the machine. · When the machine is in motion, do not push the directional/speed control pedal all the way forward. This is the same as starting in “high”... -
Page 39: Post Operation Checklist
OPERATING INSTRUCTIONS POST OPERATION CHECKLIST Check Battery Condition and recharge, if necessary. 1. Check all flaps for wear, damage and adjustment. 2. Drain and clean recovery tank. 3. Clean recovery tank screen and float. 4. Check scrub brushes for wear or damage. 5. - Page 40 OPERATING INSTRUCTIONS RECOVERY TANK HOSE RECOVERY TANK SCREEN RECOVERY TANK HOSE RECOVERY TANK Fig. 47 Fig. 46 DRAIN HOSE PLUG RECOVERY TANK CLEAN OUT DOOR OPEN DRAIN HOSE RECOVERY TANK KNOB CLEAN OUT DOOR Fig. 49 Fig. 48 When the draining operation is complete, open the recovery tank clean out door as shown in figure 49 and flush the recovery drain hose as shown in figure 46.
- Page 41 OPERATING INSTRUCTIONS DISK SCRUB BRUSHES DISK SCRUB BRUSH Fig. 50 Fig. 51 Inspect the disk scrub brushes and replace when the bristles are reduced to ¾ in length as shown in figure 50 and 51. To order replacement brushes, see scrub brush options in this manual. SIDE BROOM MAIN BROOM Fig.
- Page 42 OPERATING INSTRUCTIONS TOP OR REAR SQUEEGEE REAR SQUEEGEE BOTTOM OF REAR SQUEEGEE Fig. 54 Fig. 55 SIDE SQUEEGEE Fig. 56 Inspect the rear and side squeegee blades for wear. If the wiping edge becomes rounded, remove and reinstall so the unworn edge is now the wiping edge. This process can be repeated until all four edges are worn. If the squeegee blade has become rippled, it will need to be replaced.
-
Page 43: Hydraulic Reservoir Level Sight Gauge
Fig. 57 DUST CONTROL KNOB The dust control knob is used to hold the dust control filter cover down as shown in figure 57. The dust control filter is located under the front cover and will need to be removed periodically for cleaning or replacement. Removal of the filter panel requires no tools. -
Page 44: Maintenance
MAINTENANCE SERVICE CHART Check items for proper operation. If service is required, please contact an authorized American-Lincoln Technology distributor. For best performance, replace worn parts with genuine American-Lincoln parts. EVERY eight (8) HOURS or DAILY check and clean/adjust if necessary: Inspect panel filter for damage and clean them. - Page 45 MAINTENANCE 5, 19 5, 6 4, 8, 26, 27 11, 12, 25 3, 13, 14 9, 17 1, 20 21, 24 22, 23 AMERICAN-LINCOLN 1-45 SMART...
- Page 46 MAINTENANCE For safety, read and follow the service precautions below. Know the hazards associated with the equipment you are working on to prevent personal injury or damage to equipment. For service assistance, consult your nearest American-Lincoln dealer. For best performance replace worn parts with genuine American-Lincoln parts.
-
Page 47: Battery Charging Instructions
LIFT MACHINE FRONT COVER TO ACCESS BATTERY Fig. 60 BATTERY CHARGING INSTRUCTIONS When the battery conditioning meter is illuminated with one red LED light, the battery needs to be recharged. To prevent interruption of the cleaning cycle, charge the battery after using. 1. -
Page 48: Battery Removal
MAINTENANCE Do not remove the battery from the machine if there is waste in the solution tank. Hydrogen gas is formed during the charging operation and is explosive! Only charge batteries in a well-ventilated area with the lid open. Avoid any open flame or electrical sparks. - Page 49 BATTERY REMOVAL WITH THE BATTERY ROLLOUT OPTION When removing batteries 1. Lift the machine front cover to access battery compartment. 2. Unplug the battery power connector from the machine power connector. 3. Line up battery cart locator pins with slots in frame and lock in place. 4.
- Page 50 MAINTENANCE DISK SCRUB BRUSHES Fig. 71 REPLACING SCRUB BRUSHES 1. Raise the scrub brush deck by pressing the “Scrub Brush” switch on the instrument panel. 2. Press the brush latches in to release the scrub brush. 3. Remove the old scrub brush. 4.
- Page 51 LOOSEN KNOB Fig. 73 REPLACING REAR SQUEEGEE The squeegee will require service when the inner edge of the blades become round with wear, impairing the wiping action or water pick up. 1. Loosen the four aluminum knobs. 2. Remove the squeegee tool and turn upside down to service the blades or the caster wheels. The squeegee blades are designed to rotate to use an unworn edge.
-
Page 52: Draining The Recovery Tank
MAINTENANCE DRAINING THE RECOVERY TANK Drive the machine to a draining area. Loosen the knobs on the recovery clean out door and pivot the door to the left as shown in figure 76. With the water hose flush out the bottom of the recovery tank clean out door to remove larger particles of debris. -
Page 53: Adjusting The Main Broom Height
MAIN BROOM To prevent the broom from setting in one direction and to provide the maximum life of the broom it is recommended that the broom be turned end over end periodically. ADJUSTING THE MAIN BROOM HEIGHT The main broom adjustment knob for changing the sweep height to compensate for broom wear is located in front of the machine as shown in figure 80. -
Page 54: Replacing The Main Broom
MAINTENANCE MAIN BROOM ACCESS DOOR The main broom access door is located in front of the left side tire of the machine as shown in figure 81. The door provides access to the main broom for service or inspection. The hopper must be raised to access. Engage hopper safety arm while accessing the main broom BROOM LIFT ARM KNOBS Fig. - Page 55 REMOVE BROOM LIFT ARM Fig. 84 BROOM IDLER Fig. 86 INSTALLED BROOM Remove broom lift arm as shown in figure 84 and 85. Remove the main broom from the from the broom idler exposing the main broom compartment as shown in figure 86. Check and clean out the main broom compartment before installing the new main broom.
-
Page 56: Adjusting The Side Broom Height
MAINTENANCE Fig. 89 SIDE BROOM ADJUSTMENT KNOB Fig. 90 Fig. 91 1-56 SIDE BROOM The side broom (Fig. 89) sweeping angle is not adjustable. However, the height of the side broom can be adjusted to compensate as the broom becomes worn from use. Always check and adjust the sweep pattern after changing the side broom. - Page 57 Fig. 92 HOPPER The hopper (Fig. 92) houses the debris compartment, the dust control filter and the removable dust baffle. For maximum performance and service life, keep the hopper clean and inspect the seals and flaps daily. Clean the hopper prior to parking the sweeper at the end of the day. A clean hopper will make inspecting the flaps and seals much easier and will prevent premature deterioration of hopper components.
- Page 58 MAINTENANCE DUST FLAPS The dust flaps are very important to sweeping and dust control and are susceptible to damage and should be inspected daily and maintained in good condition. CHECKING THE DUST FLAPS The dust flaps are used on the wheel well, broom chamber and broom door. Inspect the flaps daily and replace any flap that shows signs of wear or deterioration.
-
Page 59: Troubleshooting
PROBLEM Machine moves slowly or 1. Battery charge low erratically 2. Brakes dragging 3. Loose connection at foot pedal 4. Drive circuit overloaded Machine does not move 1. Blown fuse 2. Battery unplugged 1. Recovery tank full 2. Squeegee is worn or damaged 3. - Page 60 TROUBLESHOOTING PROBLEM 1. Worn scrubbing brushes 2. Incorrect method of operation Poor scrubbing action 3. Wrong cleaning agent or mixture 4. Poor solution distribution 5. Brushes won’t turn Water splashes from sides 1. Scrub deck bumpers, poor contact with floor of scrub deck 2.
