Summary of Contents for Orion XTRPRO102
- Page 1 S u b w o o f e r MODE L XTRPRO102 XTRPRO104 XTRPRO122 XTRPRO124 XTRPRO152 XTRPRO154 OWNER'S MANUAL...
- Page 2 FEATURES Figure 1 Figura 1 Abbildung 1 Polypropylene dust cap - moisture and UV resistant. Oversized NBR (Nitrile-butadiene Rubber) surround for linear controlled long excursion. Paper cone - moisture and UV resistant. Custom cast aluminum frame. Vented Aluminum voice coil former (2.5" voice coil former). 8mm steel front plate.
-
Page 3: Wiring Configurations
WIRING CONFIGURATIONS Series - One Speaker (dual 2 ohm voice coils) One dual 2 ohm voice coil woofer with voice coils in connected in series results in a 4 ohm load to the amplifier. Figure 2 Figura 2 Abbildung 2 1. - Page 4 Parallel — One Speaker (dual 4 ohm voice coils) One dual 4 ohm voice coil woofer with voice coils in parallel results in a 2 ohm load to the amplifier. Figure 4 Figura 4 Abbildung 4 1. Connect the speaker in parallel by connecting the two positive (+) terminals together and the two negative (-) terminals together.
- Page 5 Parallel - Two Speaker (dual 4 ohm voice coils) Two dual 4 ohm voice coil woofers with voice coils in parallel and the two woofers in parallel results in a 1 ohm load to the amplifier. Figure 5 Figura 5 Abbildung 5 1.
- Page 6 Series/Parallel - Two Speakers (dual 2 ohm voice coils) Note: Verify and ensure that the woofer wiring is connected as shown with the negative connection from the first woofer coil connected to the positive connection of the second woofer coil. Two dual 2 ohm voice coil woofers with voice coils in series and then parallel the two series woofers results in a 2 ohm load to the amplifier.
- Page 7 Series/Parallel - Three Speakers (dual 4 ohm voice coils) Note: Verify and ensure that the woofer wiring is connected as shown with the negative connection from the first woofer coil connected to the positive connection of the second woofer coil. Three dual 4 ohm voice coil woofer with voice coils of each woofer wired in series and then parallel the three woofers for a resulting 2.67 ohm load to the amplifier.
- Page 8 Series/Parallel - Three Speakers (dual 2 ohm voice coils) Note: Verify and ensure that the woofer wiring is connected as shown with the negative connection from the first woofer coil connected to the positive connection of the second woofer coil. Three dual 2 ohm voice coil woofer with voice coils of each woofer wired in series and then parallel the three woofers for a resulting 1.33 ohm load to the amplifier.
- Page 9 Series/Parallel - Four Speakers (dual 4 ohm voice coils) Note: Verify and ensure that the woofer wiring is connected as shown with the negative connection from the first woofer coil connected to the positive connection of the second woofer coil. Four dual 4 ohm voice coil woofers should be wired with the voice coils on each woofer in series and then parallel the four woofers for a resulting 2 ohm load to the amplifier.
- Page 10 Series/Parallel - Four Speakers (dual 2 ohm voice coils) Note: Verify and ensure that the woofer wiring is connected as shown with the negative connection from the first woofer coil connected to the positive connection of the second woofer coil. Four dual 2 ohm voice coil woofers should be wired with the voice coils on each woofer in series and then parallel the four woofers for a resulting 1 ohm load to the amplifier...
- Page 11 2 Amplifiers - One Speaker (dual 2 ohm voice coils) One dual 2 ohm voice coil woofer with each voice coil connected to an individual amplifier, resulting in a 2 ohm load to each amplifier. Figure 11 Figura 11 Abbildung 11 1.
- Page 12 2 Amplifiers - One Speaker (dual 4 ohm voice coils) One dual 4 ohm voice coil woofer with each voice coil connected to an individual amplifier, resulting in a 4 ohm load to each amplifier. Figure 12 Figura 12 Abbildung 12 1.
-
Page 13: Specifications Are Subject To Change Without Notice
SPECIFICATIONS Model/Part Number XTRPRO102 XTRPRO104 XTRPRO122 Thiele/Small Parameters Fs (free-air resonance, Hz) 33.2 32.2 30.5 Vas (equivalent compliance, cu. ft.) 0.507 0.586 1.198 Vas (equivalent compliance, liters) 14.37 16.61 33.950 Qms (Q, mechanical) 5.42 5.17 6.02 Qes (Q, electrical) 0.48 0.52... - Page 14 SPECIFICATIONS Model/Part Number XTRPRO124 XTRPRO152 XTRPRO154 Thiele/Small Parameters Fs (free-air resonance, Hz) 32.3 23.4 28.7 Vas (equivalent compliance, cu. ft.) 1.256 3.464 3.207 Vas (equivalent compliance, liters) 35.590 98.130 90.860 Qms (Q, mechanical) 5.89 5.49 5.93 Qes (Q, electrical) 0.66 0.67 0.84 Qts (total driver Q)
- Page 15 90 and above mean vented Enclosure is recommended. *** Subsonic filter should always be used and adjusted specifically for vented box designs. Figure 13 Figura 13 Abbildung 13 XTRPRO102 XTRPRO104 XTRPRO122 XTRPRO124 XTRPRO152 XTRPRO154 Dimensions inches/mm, Dimensions po/mm, Dimensiones plg./mm, Abmessungen Zoll/mm, Dimensioni pollici/millimetri, Dimensões polegadas/mm...
-
Page 16: Enclosure Recommendations
3. Volumes given are net tuning volume 4. Enclosures include a minimal amount of damping material. Just enough material to line the inside of the enclosure is required. XTRPRO102 & 104 Sealed Enclosure Recommendations Box Properties — Description — — Box Parameters —... - Page 17 XTRPRO102 & 104 Vented Enclosure Recommendations Box Properties — Description — — Box Parameters — — Vents — Type: Vented Box 0.75 cu.ft No. of Vents Shape: Prism, Square V(total) = 0.841 cu.ft Vent shape = round Vent ends = one flush 44 Hz = 3 in.
- Page 18 XTRPRO122 & 124 Sealed Enclosure Recommendations Box Properties — Box Parameters — — Description — 1.5 cu.ft Type: Closed Box Shape: Prism, Square V(total) = 1.55 cu.ft 0.717 6.886 43.09 Hz Fill none External Dimensions A = 16 in. (406 mm) B = 16 in.
- Page 19 XTRPRO122 & 124 Vented Enclosure Recommendations Box Properties — Description — — Box Parameters — Vb — Vents — 1.5 cu.ft No. of Vents Type: Vented Box V(total) = 1.637 cu.ft Vent shape = round Shape: Prism, Square 40 Hz Vent ends = one flush 6.886...
- Page 20 XTRPRO152 & 154 Sealed Enclosure Recommendations Box Properties — Description — — Box Parameters — Vb 2 cu.ft Type: Closed Box V(total) = 2.078 cu.ft Shape: Prism, Square 0.963 5.281 37.55 Hz Fill none External Dimensions A = 17.5 in. (445 mm) B = 17.5 in.
- Page 21 = 0.75 in. (19 mm) —Driver Mounting— Mounting: Front Vent Parts --- Square 1 Duct: outside diameter (e) = 4.25 in. (108 mm) inside diameter (g) = 4 in. (102 mm) length (h) = 5.422 in. (138 mm) Orion Car Audio Universal Subwoofers...
