Orion XTRPR0102D Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
XTRpro102D
XTRpro122D
xtrpro152D
Subwoofers
XTRpro104D
XTRpro124D
XTRpro154D

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XTRPR0102D and is the answer not in the manual?

Questions and answers

Related Manuals for Orion XTRPR0102D

Summary of Contents for Orion XTRPR0102D

  • Page 1 XTRpro102D XTRpro104D XTRpro122D XTRpro124D xtrpro152D XTRpro154D Subwoofers...
  • Page 2 This manual contains important information about installation, set-up procedures and integrating your new Orion product into your vehicle. With proper care and installation, your new product will provide you with many years of high performance listening enjoyment.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS TABLE OF CONTENTS....................2 FEATURES......................3 SPECIFICATION..................4 WIRING CONFIGURATION..................5-14 BUILDING AN ENCLOSURE..................15 ENCLOSURE DETAILS..................16-17 ENCLOSURE RECOMMENDATION..............18-23 WARNING & DISCLAIMER..................24 TROUBLESHOOTING.....................25 WARRANTY......................26 WHAT’S IN THE BOX 1 x XTRPRO Subwoofer 1 x Trim Ring 1 x Mounting Template 1 x Owner’s Manual 1 x Window Sticker...

  • Page 4: Features

    FEATURES Polypropylene dust cap - moisture and UV resistant. Oversized Santoprene surround for linear controlled long excursion. Vented paper cone - moisture and UV resistant. Custom stamped aluminum frame. Spider ring attachment screws.Part of re-cone feature (8 hex screws) Vented Kapton voice coil former (10” uses 2.5" voice coil former, 12” & 15" use a 3" voice coil former).

  • Page 5: Specification

    SPECIFICATIONS Fs (free-air resonance, Hz) 45.1 34.6 35.7 29.8 30.5 Vas (equivalent compliance, cu. ft.) 0.4157 0.4193 1.0932 1.114 3.029 3.000 Vas (equivalent compliance, liters) 11.7715 11.8737 30.9584 31.5591 85.7935 84.9616 Qms (Q, mechanical) 13.508 14.074 15.168 14.569 15.029 14.963 Qes (Q, electrical) 0.559 0.609...

  • Page 6: Wiring Configuration

    WIRING CONFIGURATION...
  • Page 7 WIRING CONFIGURATION...
  • Page 8 WIRING CONFIGURATION Figure 5 Figura 5 Abbildung 5...
  • Page 9 WIRING CONFIGURATION Figure 6 Figura 6 Abbildung 6...
  • Page 10 WIRING CONFIGURATION Figure 7 Figura 7 Abbildung 7...
  • Page 11 WIRING CONFIGURATION Figure 8 Figura 8 Abbildung 8...
  • Page 12 WIRING CONFIGURATION Figure 9 Figura 9 Abbildung 9...
  • Page 13 WIRING CONFIGURATION Figure 10 Figura 10 Abbildung 10...
  • Page 14 WIRING CONFIGURATION Figure 11 Figura 11 Abbildung 11...
  • Page 15 WIRING CONFIGURATION Figure 12 Figura 12 Abbildung 12...

  • Page 16: Building An Enclosure

    BUILDING AN ENCLOSURE If you’re planning to build your own enclosure and are confused in what type of enclosure best suits your needs this page will help you choose what enclosure best fits your needs. There are many different types of enclosures. The two most common used enclosures are sealed and vented enclosure.

  • Page 17: Enclosure Details

    ENCLOSURE DETAILS ENCLOSURE DETAILS 1. Parameters listed are for conventional applications only, for further help please call Sound Pros Tech Support. 2. At least 0.75” MDF (Medium Density Fiberboard) is recommended for any XTR enclosure. 3. Recommended enclosures are NET box volumes, speaker and port displacement are calculated into the volume of the enclosure, you will need to add these volumes to calculate GROSS volume for the enclosure.
  • Page 18 ENCLOSURE DETAILS Driver Physical Dimension 0.1204 0.1204 0.1674 0.1674 0.2703 0.2703 Speaker Displacement (cu ft) Mounting hole diameter (inches/mm) 9.25/235 9.25/235 11.18/284 11.18/284 14.33/364 14.33/364 Mounting depth (inches/mm) 7.27/185 7.27/185 7.70/196 7.70/196 9.59/244 9.59/244 Magnet Weight (Oz) Basket diameter (inches/mm) Recommended Enclosures Typical sealed enclosure (cu ft) 0.75...

  • Page 19: Enclosure Recommendation

    ENCLOSURE RECOMMENDATION Enclosure Details 1. External dimensions calculated for 3/4” building material 2. Includes speaker displacement 3. Volumes given are net tuning volume 4. Enclosures include a minimal amount of damping material. Just enough material to line the inside of the enclosure is required. XTRPRO102D &...
  • Page 20 ENCLOSURE RECOMMENDATION XTRPRO102 & 104 Vented Enclosure Recommendations Box Properties — Description — — Box Parameters — — Vents — 0.75 cu.ft No. of Vents Type: Vented Box Shape: Prism, Square V(total) = 0.841 cu.ft Vent shape = round 44 Hz Vent ends = one flush = 3 in.
  • Page 21 ENCLOSURE RECOMMENDATION XTRPRO122 & 124 Sealed Enclosure Recommendations Box Properties — Box Parameters — — Description — 1.5 cu.ft Type: Closed Box V(total) = 1.55 cu.ft Shape: Prism, Square 0.717 6.886 43.09 Hz Fill none External Dimensions A = 16 in. (406 mm) B = 16 in.
  • Page 22 ENCLOSURE RECOMMENDATION XTRPRO122 & 124 Vented Enclosure Recommendations Box Properties — Box Parameters — Vb — Vents — — Description — Type: Vented Box 1.5 cu.ft No. of Vents V(total) = 1.637 cu.ft Vent shape = round Shape: Prism, Square 40 Hz Vent ends = one flush...
  • Page 23 ENCLOSURE RECOMMENDATION XTRPRO152 & 154 Sealed Enclosure Recommendations Box Properties — Box Parameters — Vb — Description — 2 cu.ft Type: Closed Box V(total) = 2.078 cu.ft Shape: Prism, Square 0.963 5.281 37.55 Hz Fill none External Dimensions A = 17.5 in. (445 mm) B = 17.5 in.
  • Page 24 ENCLOSURE RECOMMENDATION XTRPRO152 & 154 Vented Enclosure Recommendations Box Properties — Box Parameters — Vb — Vents — — Description — Type: Vented Box 3 cu.ft No. of Vents V(total) = 3.116 cu.ft Vent shape = round Shape: Prism, Square 36 Hz Vent ends = one flush...

  • Page 25: Warning & Disclaimer

    IMPORTANT: Never cut any metal that is an integral part of the vehicle’s safety or structural support system. If you are unsure, it is best to have the product professionally installed by an Authorized ORION Dealer. Never sacrif ice your safety for sound.

  • Page 26: Troubleshooting

    TROUBLESHOOTING Symptom Check Point Remedy No Sound Is the amplifier power LED 1. Check fuses in amplifier illuminated? 2. Check turn-on lead 3. Check signal lead 4. Check gain control 5. Check source unit volume 6. Clean contacts on fuse holders Is the amplifier overload LED Check speaker for short or illuminated?

  • Page 27: Warranty

    5. The sole responsibility of Orion under this warranty shall be limited to the repair or replacement thereof, at the sole discretion of Orion. 6. If it becomes necessary to send the product or any defective part to Orion or an authorized service station, the product must be shipped in its original or equivalent carton, fully insured, with shipping charges prepaid.
  • Page 28 3130 WEST 15TH AVENUE HIALEAH, FLORIDA 33012 TEL: 786.464.0247 EMAIL: SUPPORT@ORIONCARAUDIO.COM ORIONCARAUDIO.COM PROUD SPONSOR OF Copyright ORION All rights reserved. Any unauthorized reproduction or use of any Orion logos, images or design elements is strictly prohibited by law. Specifications subject to change without notice. REV. 24.5...
