Summary of Contents for Orion HCCA 12.4
- Page 1 subwoofer HCCA HCCA 10.2 10.4 10.2 10.4 12.2 12.4 12.2 12.4 15.2 15.4 15.2 15.4...
-
Page 2: Table Of Contents
Parallel—One Speaker (dual 2 ohm voice coils) ........ -
Page 3: Introduction
Authorized Orion Dealer for technical assistance. Orion dealers are trained professionals dedicated to extracting the maximum performance out of your Orion system. If you decide to install this speaker system yourself, please read the entire section on sealed and vented enclosures before starting your installation. -
Page 4: Tools Of The Trade
• Jig saw FINDING SPEAKER MOUNTING LOCATIONS Choosing the correct speaker locations will have the greatest effect on the sound quality of the system. There are many different considerations needed when choosing the locations that best suit your needs. The locations must be large enough for the speakers to fit. - Page 5 Paper dust cap - moisture and UV resistant. Tall, wide, balanced, NBR Foam (high density expanded polyester foam) surround for linear controlled long excursion using symmetrical edge design optimized on non-linear FEA. Paper cone - moisture and UV resistant. Custom Cast Aluminum frame. Spider ring attachment screws.
-
Page 6: Re-Cone Kit
RE-CONE KIT A re-cone kit is available for these speakers and can be obtained from your dealer. The part number for each model is listed below. Model Description HCCA10.2CK ORION HCCA 10" 2 OHM Re-Cone Kit HCCA10.4CK ORION HCCA 10" 4 OHM Re-Cone Kit HCCA12.2CK ORION HCCA 12"... -
Page 7: Parallel—One Speaker Connections
One dual 2 ohm voice coil woofer with voice coils in parallel results in a 1 ohm load to the amplifier. 1. Connect the speaker in parallel by connecting the two positive (+) terminals together and the two negative (-) terminals together. -
Page 8: Parallel-Two Speakers (Dual 4 Ohm Voice Coils)
Two dual 4 ohm voice coil woofers with voice coils in parallel and the two woofers in parallel results in a 1 ohm load to the amplifier. 1. Connect the speaker in parallel by connecting the four positive (+) terminals together and the four negative (-) terminals together. -
Page 9: Parallel-One Speaker (Dual 4 Ohm Voice Coils)
One dual 4 ohm voice coil woofer with voice coils in parallel results in a 2 ohm load to the amplifier. 1. Connect the speaker in parallel by connecting the two positive (+) terminals together and the two negative (-) terminals together. -
Page 10: Series-Parallel-Two Speakers (Dual 2 Ohm Voice Coils)
Series-Parallel—Two Speakers (dual 2 ohm voice coils) Note: Verify and ensure that the woofer wiring is connected as shown with the negative connection from the first woofer coil connected to the positive connection of the second woofer coil. Two dual 2 ohm voice coil woofers with voice coils in series and then parallel the two series woofers results in a 2 ohm load to the amplifier. -
Page 11: Series-Parallel-Three Speakers (Dual 4 Ohm Voice Coils)
Series-Parallel—Three Speakers (dual 4 ohm voice coils) Note: Verify and ensure that the woofer wiring is connected as shown with the negative connection from the first woofer coil connected to the positive connection of the second woofer coil. Three dual 4 ohm voice coil woofer with voice coils of each woofer wired in series and then parallel the three woofers for a resulting 2.67 ohms.load to the amplifier. -
Page 12: Series-One Speaker (Dual 2 Ohm Voice Coils)
Series—One Speaker (dual 2 ohm voice coils) One dual 2 ohm voice coil woofer with voice coils in connected in series results in a 4 ohm load to the amplifier. 1. Connect the woofer in series by connecting the negative (-) of one terminal to the positive (+) terminal of the other coil. -
Page 13: Series-Parallel-Four Speakers (Dual 4 Ohm Voice Coils)
Series-Parallel—Four Speakers (dual 4 ohm voice coils) Note: Verify and ensure that the woofer wiring is connected as shown with the negative connection from the first woofer coil connected to the positive connection of the second woofer coil. Four dual 4 ohm voice coil woofers should be wired with the voice coils on each woofer in series and then parallel the four woofers for a resulting 2 ohm load to the amplifier. -
Page 14: Series-Parallel-Four Speakers (Dual 2 Ohm Voice Coils)
Series-Parallel—Four Speakers (dual 2 ohm voice coils) Note: Verify and ensure that the woofer wiring is connected as shown with the negative connection from the first woofer coil connected to the positive connection of the second woofer coil. Four dual 2 ohm voice coil woofers should be wired with the voice coils on each woofer in series and then parallel the four woofers for a resulting 1 ohm load to the amplifier. -
Page 15: Amplifiers-One Speaker (Dual 2 Ohm Voice Coils)
One dual 2 ohm voice coil woofer with each voice coil connected to an individual amplifier, resulting in a 2 ohm load to each amplifier. 1. Connect one of the speaker’s voice coils to the first amplifier by connecting the positive (+) terminal and the negative (-) terminal from the speaker to the respective positive (+) terminal and the negative (-) terminal from the first amplifier. -
Page 16: Amplifiers-One Speaker (Dual 4 Ohm Voice Coils)
One dual 4 ohm voice coil woofer with each voice coil connected to an individual amplifier, resulting in a 4 ohm load to each amplifier. 1. Connect one of the speaker’s voice coils to the first amplifier by connecting the positive (+) terminal and the negative (-) terminal from the speaker to the respective positive (+) terminal and the negative (-) terminal from the first amplifier. -
Page 17: Enclosure Design
ENCLOSURE DESIGN This section gives the basic description for a sealed enclosure. Orion HCCA woofers are designed for sealed enclosures and vented enclosures. Sealed enclosures are generally considered the most versatile for all music types and are the easiest to build. -
Page 18: Hcca 10.2 & 10.4 Sealed Enclosure Recommendations
HCCA 10.2 & 10.4 Sealed Enclosure Recommendations Top & Bottom Front & Back —External Dimensions— A = 13 in. B = 13.5 in. C = 14.5 in. —Internal Dimensions— A = 11 in. B = 11.5 in. C = 12.5 in. —Wall Thickness—... -
Page 19: Hcca 10.2 & 10.4 Vented Enclosure Recommendations
HCCA 12.2 & 12.4 Sealed Enclosure Recommendations Top & Bottom Front & Back —External Dimensions— A = 16.5 in. B = 16 in. C = 16 in. —Internal Dimensions— A = 14 in. B = 14 in. C = 14 in. —Wall Thickness—... -
Page 20: Hcca 12.2 & 12.4 Sealed Enclosure Recommendations
HCCA 15.2 & 15.4 Sealed Enclosure Recommendations Top & Bottom Front & Back —External Dimensions— A = 17.5 in. B = 18 in. C = 20 in. —Internal Dimensions— A = 15.5 in. B = 16 in. C = 18 in. —Wall Thickness—... -
Page 21: Hcca 12.2 & 12.4 Vented Enclosure Recommendations
1. Parameters listed are for conventional applications only, for further help please call Tech Audio Support 2. 1" MDF is recommended. 3. Recommended enclosures are NET Box Volumes, speaker and port displacement are calculated into the volume of the enclosure, you will not need to add these volumes to calculate GROSS volume for the enclosure. -
Page 22: Specifications (Cont'd)
Sd (effective radiating area, sq. m.) Sd (effective radiating area, sq. in.) Frequency range (Hz) Energy Bandwidth Product (EBP) Driver Physical Dimension Speaker Displacement (cu ft.) Mounting hole diameter (mm) Mounting hole diameter (inches) Mounting depth (mm) Mounting depth (inches) -
Page 23: Hcca 15.2 & 15.4 Vented Enclosure Recommendations
NO WARRANTY THIS PRODUCT IS SOLD "AS-IS" DIRECTED ELECTRONICS (hereinafter "SELLER") MAKES NO WARRANTY of any kind (express, implied or otherwise) in connection with this Product. THIS PRODUCT IS SOLD AS-IS, AND YOU THE PURCHASER ASSUME THE ENTIRE RISK AS TO ITS QUALITY AND PERFORMANCE.
