Rear Panel - Huawei SmartAX MT882 User Manual

LED
indicator
Steady green
light
USB
Blinking green
light

1.2.2 Rear Panel

All cables are connected to the rear panel of MT882.
The ports and switch on the rear panel of MT882 are shown as
below:
Figure 1-3 Rear panel cable and power connections
The meaning of ports and switch are listed as follows:
ADSL: ADSL port, connecting to the splitter
USB: USB port, connecting to PC or hub
Ethernet: Ethernet port, connecting to PC or hub
Reset: press this button for 3 seconds to restore the
default setting. This operation will let you lose your
customized setting. Please be careful when using Reset
button.
Status
A valid USB connection.
There is traffic over USB.
Huawei Technologies Proprietary
3
Description
