IGW 400 - 4 BURNER STAINLESS STEEL GAS GRILL (BB10514A)
ASSEMBLY AND OPERATING INSTRUCTIONS
Igloo® is a trademark of Igloo Products Corp. Registered in the United States Patent and Trademark Office. All Rights Reserved.
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open hood.
4. If odor continues, immediately call
your gas supplier or your fire
department.
WARNING
CONTACT 1-866-NAO-GRILL (1-866-626-4745) FOR ASSISTANCE
DO NOT RETURN TO PLACE OF PURCHASE
For outdoor use only. Not for commercial use.
Read instructions before using the appliance. Failure to
follow instructions could result in death, serious bodily
injury, and/or property loss.
Warning: accessible parts may be very hot. Keep young
children away.
Do not move the appliance during use.
Turn off the gas supply at the gas cylinder after use.
Any modification of the appliance may be dangerous.
This grill can NOT be converted to natural gas.
Installer to leave instructions with the consumer and
consumer to retain them for future reference.
FOR YOUR SAFETY
1. Do not store or use gasoline or
other flammable vapors or liquids
in the vicinity of this or any other
appliance.
2. An LP cylinder not connected for
use shall not be stored in the
vicinity of this or any other
appliance.
1
50,000 BTUs with
10,000 BTUs Side Burner
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Igloo IGW 400
Summary of Contents for Igloo IGW 400
- Page 1 ASSEMBLY AND OPERATING INSTRUCTIONS 50,000 BTUs with 10,000 BTUs Side Burner Igloo® is a trademark of Igloo Products Corp. Registered in the United States Patent and Trademark Office. All Rights Reserved. FOR YOUR SAFETY FOR YOUR SAFETY If you smell gas: 1.
- Page 2 WARNINGS PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE ASSEMBLY AND USE. FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN DEATH, SERIOUS BODILY INJURY, AND/OR PROPERTY LOSS. READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY BEFORE ASSEMBLY OR USE OF THIS OUTDOOR GAS GRILL. *WARNING! Read and follow all instructions.
- Page 3 The cylinder must be arranged for vapor withdrawal. It must also include a collar to protect the cylinder valve. A safety relief device having direct communication with the vapor space of cylinder must be provided. This will expel high-pressure gas if the cylinder is overfilled or overheated which could result in fire or explosion.
-
Page 4: Item Description
Parts List For Grill -- BB10514A For parts please call us at 1-866-626-4745 M-F, 8:30am to 5:30pm EST Replacement ITEM DESCRIPTION PART INCLUDED Part # G200 Frame --preassembled Brass Burners G233 --preassembled Cross Support G202 Back Panel G203 Left Door G204 Right Door G205... - Page 5 Side burner knob G128 Knob base G129 G210 Cooking Grids Flame Diffusers G211 Cylinder lock line G127 Drip pan G212 Cylinder Support G213 S Hooks G214 Rotisserie Motor G215 Motor Pole A G216 (Handle Side) Motor Pole B G217 (Motor Side) G218 Motor Support Forks...
- Page 6 Motor Pole Handle (Plastic) G221 --preassembled Motor Pole Coupling G222 --preassembled Pole Restrictor G223 --preassembled Snap-In Thermostat G130 --preassembled Side Shelf Handle -- G131 preassembled Door Handle – G132 preassembled Door Spring Latch G133 --preassembled Tank Support Shelf G134 Lock --preassembled Burner Insect Cover G135 --preassembled...
- Page 7 Side Burner Trivet G230 --preassembled Hood Pin & Cotter Pin G231 --preassembled Door Magnet w/ G140 screws --preassembled Igniter Cover G141 --preassembled Rear Cross Support w/ G232 screws --preassembled Fixed Castors G201 Swivel Castors G234 Hardware Pack H240 H610 M6x10 Bolts M6x12 Bolts H612 M6x16 Bolts...
-
Page 8: Before You Start
D5 Washers H415 H425 D5 Spring Washers D4 Washers H411 H515 M5 Nuts H011 Battery ASSEMBLY INSTRUCTIONS Before You Start When you are ready to start, make sure that you have the right tools at hand, plenty of space and a clean dry area for assembly. - Page 9 STEP – 1: Unpack and inspect all parts listed. If you believe you have missing parts, please check all boxes parts of the grill. Some parts are shipped in place or pre-assembled. If you have damaged or missing parts, do not return to the store.
- Page 10 STEP – 3: Attach Back Panel (4) to Frame (1) with Bolts (C), Washers (G), as shown. STEP – 4: Attach Cylinder Support (17) to frame (1) with Bolts (C), as shown. C H G STEP – 5: Attach Cross Support (3) to Frame (1) with Bolts (C), Spring Washers (H) and Washers (G), as shown.
- Page 11 46 Rear Cross Support STEP – 6: Fit the Doors (5) & (6) into Frame (1) in the positions show by first inserting the post on the bottom corner of the door into the hole on the bottom of the Frame (1) and then while pressing down on to the Door Spring Latch (31), move the door into position as shown.
- Page 12 STEP – 8: a. Remove two bolts from the side of the grill. (These bolts are the two bolts that attach the FRONT PANEL to the body.) b. Partially screw two bolts (C) to the Body (8) at the top, as shown. c.
- Page 13 STEP – 10: a. Thread the Side Burner Valve (36) into the hole p rovided on the Right Side Burner Shelf (10), as shown in Fig. 10.1. Using the screw (F) and washer (K), install the Knob Base (12) into the Right Fig.
- Page 14 STEP – 11: Remove Drip Pam (16) from Grill Body (8). Remove any packing material and then slide back into grill as shown. STEP – 12 : Mount Motor Support (21) to the Grill Body (8) with two Bolts (E), two Washers (I), two Spring Washers (J), &...
- Page 15 STEP – 14 : Install Warming Rack (7) by inserting the extensions into the holes under the Fig. 14.1 Motor Support (22) and into the holes on the Hood (38), as shown in Fig. 14.1. Un-screw the Igniter Cover (45), insert the Battery (M), and replace the Igniter Cover (45), as shown in Fig.
- Page 16 STEP – 16: Install the cylinder (not included) on the cylinder support as shown and slide into the frame. Secure the cylinder lock line onto the surface of the cylinder as show. Slowly push cylinder support into frame Note: Ensure the grill is on level ground before you place the cylinder.
-
Page 17: Rotisserie Assembly
Rotisserie Assembly Assembling the Motor Pole (Spit) Identify the Motor Pole A (20) and Motor Pole B (21). Slide one Fork (23) onto Motor Pole A (20), as shown. Attach Motor Pole Coupling (26) to Motor Pole A (20). Attach Motor Pole B (21) to Motor Pole Coupling (26). -
Page 18: Connecting The Gas
MAIN BURNER AND SIDE BURNER WITH RESPECT TO PROPER LOCATION: WARNING – ALWAYS CHECK TO ENSURE BURNERS ARE POSITIONED CORRECTLY BEFORE EACH USE Burner pipe Valve Valve Burner Main valve orifice with burner properly positioned Side valve orifice with burner properly positioned [Internal connection] [Internal connection] CONNECTING THE GAS... -
Page 19: Lighting The Grill
including valve connections, hose connections, and regulator connections. Step 4- If bubbles form over any of the joints there is a leak Turn off the gas Retighten all joints Repeat test If bubbles form again, do not use the grill and contact your gas supplier or fire department for assistance. Main Burner Valve&Manifold Assembly... -
Page 20: Manual Lighting Instructions
MANUAL LIGHTING INSTRUCTIONS Main burner-To light with match, insert long stick match in Match Holder (26). Light match and place through the match-lighting hole in the left hand side of the body until the lit end is alongside the left hand burner. Push and turn the left hand control knob counterclockwise to the high position taking care t o protect yourself from flames. -
Page 21: Essential Information
ESSENTIAL INFORMATION Please read all instructions before using your grill. BEFORE YOU USE YOUR GRILL (also see installation) Perform a leak test before each use. This is the only safe and sure way to detect any gas leaking from joints and connections of the grill after assembly. -
Page 22: Gas, Regulator And Hose
WHEN YOU HAVE FINISHED COOKING (also see care and maintenance) Turn all the main burners to the high position for 3 to 5 minutes to burn off any food residue from the cooking surfaces and burners. When the grill has cooled, the burnt residue can be easily removed using a damp, non abrasive cloth on the cooking surfaces and a wire brush on the burners. -
Page 23: Operation
applicable; and shall be provided with a listed overfilling prevention device. The LP gas cylinder must have a Type 1 compatible cylinder with a Type 1 cylinder valve that has a back-check valve, which does not permit gas flow, until a positive seal has been obtained. The cylinder must be arranged for vapor withdrawal. -
Page 24: Care And Maintenance
Roasting (hooded grills only) A roasting hood allows you to roast or bake in a similar way as in a conventional gas oven. For best results place the food you wish the bake or roast in a metal baking tray and set it on one side of the cooking grill. Turn the burners directly under the food to the ‘OFF’... - Page 25 General Regularly clean your grill between uses and especially after extended periods of storage. Do not leave the grill uncovered and exposed to the elements when not in use. Even when stored outside or inside with a cover it is possible for mold to grow on any fat remaining on parts of the grill. This should be cleaned off smooth surfaces with hot soapy water.
-
Page 26: Troubleshooting
TROUBLESHOOTING Problem Solution 1. Make sure propane tank is connected and its valve is in the “open” position. 2. Make sure propane tank has fuel. 3. There may be debris in or around the burners. The grill should be cleaned after each use.
