Controller
Display
Settings
No
Icon
1
Legionella
prevention
2
Heat pump
3
Electric heater
4
Target
temperature
5
OPTION
6
+
7
-
8
9
Information
10
Space heating
mode
11
Domestic hot
water mode
12
Holiday mode
13
14
Current
temperature
11
10
8
9
Description
When this icon is displayed Legionella prevention
mode is active.
'Heat Pump' is running
Defrosting
Emergency heating
When this icon is displayed the electric heaters are in use.
Target flow temperature
Target room temperature
Compensation curve
Pressing the function button below this icon will
display the option screen.
Increase desired temperature.
Decrease desired temperature.
Pressing the function button below this icon
switches between Zone 1 and Zone 2.
Pressing and holding the function button below
this icon displays the information screen.
Heating mode. Zone 1 or Zone 2.
Normal or ECO mode.
When this icon is displayed 'Holiday mode' activated.
Timer
Prohibited
Stop
Operating
Current room temperature
Current water temperature of DHW tank
13
12
1
2
7
6
Stand-by
3
4
5
Page 7
