Quick Guide

1. Master– an inhibitive fader that proportionately controls all other faders. This determines
maximum output of all faders at all times. The master is always active.
2. Navigation Keys– these keys allow access to all setup and mode change functions.
Up – the function of this key will be displayed at the bottom center of the LCD screen
to the left of the slash (/). It often allows the cursor to move up any list on the LCD
display.
Down – the function of this key will be displayed at the bottom center of the LCD
screen to the right of the slash (/). It often allows the cursor to move down any list on
the LCD display.
Escape – the function of this key will be displayed at the bottom left of the LCD
screen. It often allows the console to cancel a command.
Confirm - the function of this key will be displayed at the bottom right of the LCD
screen. It often allows the console to accept a command.
3. Channel Faders – a fader that controls the output of the patched dimmer number.
4. Flash Buttons – these change functions according to the mode of the console.
In back up mode – a momentary button that flashes the level of the corresponding
scene to full.
In timed event mode – to enter into event setting.
In manual mode - a momentary button that flashes the level of the corresponding
fader to full.
5. Hold Button– this button will freeze the output of the faders so that the operator can reset
the channel faders for a different look.
6. Page– changes function according to the mode of the console.
In back up mode – changes from page 1 through 12 for playback and recording of
cues.
In timed event mode – the page button is inactive.
In manual mode – the page button is inactive.
