Delete All Scenes; Set Buzzer; Set Clock - Strand Lighting 301 Operation Manual

1. Del One Scene
2. Del Page Scene
3. Del All Scene
Quit +/- Confirm

- Set Buzzer

1. Delete Scene
2. Set Buzzer

3. Set Clock

Quit +/- Confirm
Note: When DMX is lost, the buzzer will sound (if enable) and the DMX IN LED will flash until DMX is
restored to the main lighting console. The buzzer will also turn off automatically if any action is taken
on the console subsequent to DMX loss.
- Set Clock
1. Delete Scene
2. Set Buzzer
3. Set Clock
Quit +/- Confirm
Page 16

Delete All Scenes

Delete All Scenes – deletes all scenes on all pages.
Delete All Scene
Are
Quit
Set Buzzer – The buzzer indicates if the back up has lost the
DMX512 signal. The options are Enable and Disable. There is no
other indication of the buzzer's status.
1. Enable Buzzer
2. Disable Buzzer
Quit +/- Confirm
Set Clock – this allows the operator to set the internal clock of the
console. The time is displayed in 24 hour mode. The console will
automatically go back to the main screen after 5 seconds of
inactivity.
Set Clock
TIME:12:00:00
>
You Sure?
Confirm
Buzzer Set
+/- Confirm
Press Confirm
complete the deletion.
Navigate using the up
and down keys to select
the buzzer option. Then
press Confirm.
Navigate using the left
key. Set the time using
the up and down keys.
Then press Confirm.
Strand 301 Console Manual
to
